Camera |
Image Sensor | 1/3" progressive scan CMOS |
Max. Resolution | 2560 × 1440 |
Min. Illumination | Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR |
Shutter Time | 1/3 s to 1/100,000 s |
Day & Night | IR cut filter |
Angle Adjustment | Pan: 0° to 355°, tilt: 0° to 75° |
Lens |
Focal Length & FOV | 2.8 mm, horizontal FOV 98.0°, vertical FOV 53.1°, diagonal FOV 114.7° |
Lens Mount | M12 |
Iris Type | Fixed |
Aperture | F2.0 |
Illuminator |
Supplement Light Type | IR |
Supplement Light Range | Up to 30 m |
Smart Supplement Light | Yes |
IR Wavelength | 850 nm |
Video |
Main Stream | 50 Hz: 20 fps (2560 × 1440) 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440) 30 fps (1920 × 1080, 1280 × 720) |
Sub-Stream | 50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360) |
Video Compression | Main stream: H.265 / H.264 / H.264+ / H.265+ Sub-stream: H.265 / H.264 / MJPEG |
Video Bit Rate | 32 Kbps to 8 Mbps |
H.264 Type | Baseline Profile / Main Profile / High Profile |
H.265 Type | Main Profile |
Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
Audio |
Audio Compression | G.711ulaw / G.711alaw / G.722.1 / G.726 / MP2L2 / PCM/AAC |
Audio Bit Rate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC) |
Audio Sampling Rate | 8 kHz/16 kHz |
Environment Noise Filtering | Yes |
Network |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
User/Host | Up to 32 users. 3 levels: administrator, operator and user |
Image |
Image Settings | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
Day/Night Switch | Auto, Schedule, Day, Night |
Wide Dynamic Range (WDR) | 120 dB |
SNR | ≥ 52 dB |
Image Enhancement | BLC, 3D DNR |
Interface |
Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
On-Board Storage | Built-in memory card slot, support microSD card, up to 256 GB |
Built-in Microphone | Yes |
Reset Key | Yes |
Event |
Basic Event | Motion detection, video tampering, exception |
Linkage | Upload to FTP/memory card, notify surveillance center, send email, trigger recording,trigger capture |
General |
Power | 12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W |
Dimension | Ø120 mm × 92.2 mm (4.72" × 3.63") |
Package Dimension | 150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6") |
Weight | Approx. 440 g (1.0 lb.) |
With Package Weight | Approx. 680 g (1.5 lb.) |
General Function | Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
