Camera
|
|
Image Sensor
|
1/4’’ Progressive Scan CMOS
|
|
Min. Illumination
|
0.01Lux @ (F1.2, AGC ON) , 0.028Lux @ (F2.0, AGC ON) , 0 Lux
with IR
|
|
Shutter Speed
|
1/3 s ~ 1/100,000 s
|
|
Lens
|
2.8mm@ F2.0, Angle of view: 92.5°
|
|
Lens Mount
|
M12
|
|
Day & Night
|
IR cut filter with auto switch
|
|
WDR
|
Digital WDR
|
|
Angle Adjustment
|
Pan:0° - 360°, Tilt: 0° - 75°, Rotation: 0° - 360°
|
|
Compression Standard
|
|
Video Compression
|
H.264 / MJPEG
|
|
H.264 Type
|
Baseline Profile / Main Profile
|
|
Video Bit Rate
|
32 Kbps – 8 Mbps
|
|
|
|
Max. Resolution
|
1280 × 720
|
|
Frame Rate
|
50Hz: 25fps (1280 × 720)
60Hz: 30fps (1280 × 720 )
|
|
Image Enhancement
|
BLC/3D DNR
|
|
Image Setting
|
Rotate Mode, Saturation, Brightness, Contrast, Sharpness
adjustable by client software or web browser
|
|
Network
|
|
Network Storage
|
NAS (Support NFS,SMB/CIFS)
|
|
Alarm Trigger
|
Motion detection, Dynamic analysis, Tampering alarm, Network
disconnect , IP address conflict, Storage exception
|
|
Protocols
|
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP,
RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
|
|
Security
|
Flash-prevention, dual stream, heartbeat, mirror, password
protection, privacy mask, watermark, IP address filtering, anonymous access
|
|
Standard
|
ONVIF, PSIA, CGI, ISAPI
|
|
Interface
|
|
Communication Interface
|
1 RJ45 10M/100M Ethernet interface
|
|
General
|
|
Operating Conditions
|
-10 °C – 40 °C (14 °F – 104 °F)
Humidity 95% or less (non-condensing)
|
|
Power Supply
|
12V DC±10%
|
|
Power Consumption
|
Max. 6W
|
|
IR Range
|
10m
|
|
Dimensions
|
Φ110 × 89.62 mm (4.33” × 3.53”)
|
|
Weight
|
570g (1.26 lbs)
|
