Camera
|
|
Image Sensor
|
1/2.8" progressive
scan CMOS
|
|
Min. Illumination
|
Color: 0.01 Lux @(F1.2, AGC
ON), 0.028Lux @ (F2.0, AGC ON)
|
|
Shutter Speed
|
1/3 s to 1/100, 000 s
|
|
Slow Shutter
|
Yes
|
|
Auto-Iris
|
No
|
|
Day &Night
|
IR cut filter
|
|
Digital Noise Reduction
|
3D DNR
|
|
WDR
|
DWDR
|
|
Angle Adjustment
|
Pan: 0° to 360°, tilt: 0°
to 75°, rotation: 0° to 360°
|
|
Lens
|
|
Focal Length
|
2.8 mm
|
|
Aperture
|
F2.0
|
|
Focus
|
Fixed
|
|
FOV
|
horizontal FOV 114°, vertical FOV 62°, diagonal FOV 135°
|
|
Lens Mount
|
M12
|
|
IR
|
|
IR Range
|
Up to 30 m
|
|
Wavelength
|
850 nm
|
|
Compression
Standard
|
|
Video Compression
|
Main stream: H.265/H.264
Sub stream:
H.265/H.264/MJPEG
|
|
H.264 Type
|
Main Profile/High
Profile/Baseline Profile
|
|
H.265 Type
|
Main Profile
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
Smart
Feature-set
|
|
Region of Interest
|
1 fixed region for main
stream
|
|
|
|
Max. Resolution
|
1920 × 1080
|
|
Main Stream
Max. Frame Rate
|
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
|
|
Sub-stream
Max. Frame Rate
|
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
|
|
Image Enhancement
|
BLC, 3D DNR
|
|
Image Settings
|
Saturation, brightness,
contrast, sharpness, AGC, white balance adjustable by client software or web
browser
|
|
Day/Night Switch
|
Auto, scheduled, day, night
|
|
Network
|
|
Alarm Trigger
|
Motion detection, video
tampering alarm, illegal login
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS,
DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS,
UDP
|
|
General Function
|
Anti-flicker, heartbeat,
mirror, password protection, privacy mask, watermark
|
|
Firmware Version
|
V5.5.70
|
|
API
|
ONVIF (PROFILE S), ISAPI
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
User/Host
|
Up to 32 users
3 levels: Administrator,
Operator and User
|
|
General
|
|
Operating Conditions
|
-30 °C to 60 °C (-22 °F to
140 °F), humidity: 95% or less (non-condensing)
|
|
Power Supply
|
12 VDC ± 25%, 5.5 mm
coaxial power plug PoE (802.3af, class 3)
|
|
Power Consumption and
Current
|
12 VDC, 0.3 A, max: 3.5 W
PoE: (802.3af, 36 V to 57
V), 0.2 A to 0.1 A, Max: 4.5 W
|
|
Ingress Protection
|
IP67
|
|
Material
|
Camera body: metal, bottom
base : plastic
|
|
Dimensions
|
Camera: Ø 110 mm × 93.2 mm
(4.3" × 3.7")
With package: 150 mm × 150
mm × 141 mm (5.9" × 5.9" × 5.6")
|
|
Weight
|
Camera: approx. 360 g (0.8
lb.) With package: approx. 610 g (1.3 lb.)
|
