Camera |
Image Sensor | 1/2.8" Progressive Scan CMOS |
Min. Illumination | Color: 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR |
Shutter Speed | 1/3 s to 1/100,000 s |
Slow Shutter | Yes |
Day & Night | IR Cut Filter |
WDR | DWDR |
Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
Lens |
Lens Type | Fixed lens, 2.8 mm |
Aperture | F2.0 |
FOV | Horizontal FOV : 114°, Vertical FOV : 62°, Diagonal FOV : 135° |
Lens Mount | M12 |
Illuminator |
IR Range | Up to 30 m |
Wavelength | 850 nm |
Video |
Max. Resolution | 1920 × 1080 |
Main Stream | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
Sub Stream | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
Video Compression | Main stream: H.265+ / H.265 / H.264+ / H.264
Sub-stream: H.265 / H.264 / MJPEG |
H.264 Type | Baseline Profile / Main Profile / High Profile |
H.265 Type | Main Profile |
Video Bit Rate | 32 Kbps to 8Mbps |
Audio (-U) |
Audio Compression | G.711 / G.722.1 / G.726 / MP2L2 / PCM |
Audio Bit Rate | 64Kbps (G.711) / 16Kbps (G.722.1) / 16Kbps (G.726) / 32-192Kbps (MP2L2) |
Smart Feature-Set |
Basic Event | Motion detection, video tampering alarm, exception (illegal login) |
Linkage Method | Upload to FTP, notify surveillance center, send email, trigger capture |
Region of Interest | 1 fixed region for main stream and sub-stream |
Image |
Image Enhancement | BLC, 3D DNR |
Image Setting | Rotate mode, saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser |
Day/Night Switch | Day / Night / Auto / Schedule |
Network |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP |
API | ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
Simultaneous Live View | Up to 6 channels |
User/Host | Up to 32 users, 3 levels: administrator, operator and user |
Interface |
Communication Interface | 1 RJ45 self-adaptive Ethernet port |
Audio | 1 audio input (Built-in Microphone), mono sound |
Interface Style | Digital style interface |
General |
General Function | One-key reset, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
Reset | Reset via web browser and client software |
Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing) |
Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing) |
Power Supply | 12 VDC ± 25%, Φ 5.5 mm coaxial power plug; PoE (802.3af, class 0) |
Power Consumption and Current | 12 VDC, 0.4 A, max. 5 W; PoE (802.3af, 36 V to 57 V), 0.20 A to 0.10 A, max. 6.5 W |
Material | Camera body: metal, bottom base : Plastic |
Dimensions | Camera: 94.4 × Φ110 mm (3.7" × Φ4.3") With package: 150 × 150 × 141 mm (5.9" × 5.9" × 5.6") |
Weight | Camera: Approx. 354 g (0.8 lb.) With package: Approx. 681 g (1.5 lb.) |
Approval |
EMC | 47 CFR Part 15, Subpart B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: Issue 6, 2016; KN 32: 2015, KN 35: 2015 |
Safety | UL 60950-1, IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IS 13252 (Part 1): 2010+A1: 2013+A2: 2015, IEC/EN 60950-1 |
Chemistry | 2011/65/EU, 2012/19/EU, Regulation (EC) No 1907/2006 |
