Camera
|
|
Image Sensor
|
1/3" Progressive Scan
CMOS
|
|
Min. Illumination
|
Color: 0.01 Lux @(F1.2, AGC
ON), 0.018 Lux @ (F1.6, AGC ON)
|
|
Shutter Speed
|
1/3 s to 1/100, 000 s,
support slow shutter
|
|
Slow Shutter
|
Yes
|
|
Auto-Iris
|
No
|
|
Day & Night
|
IR cut filter
|
|
Digital Noise Reduction
|
3D DNR
|
|
WDR
|
120 dB
|
|
Angle Adjustment
|
Pan: 0° to 360°, tilt: 0°
to 90°, rotation: 0° to 360°
|
|
Lens
|
|
Focal Length
|
2.8 to 12 mm
|
|
Aperture
|
F1.6
|
|
Focus
|
-I: Manual
-IZ: Auto
|
|
FOV
|
Horizontal field of view:
98° to 28° Vertical field of view: 51° to 16° Diagonal field of view: 115° to
32°
|
|
Lens Mount
|
Φ14
|
|
IR
|
|
IR Range
|
Up to 30 m
|
|
Wavelength
|
850 nm
|
|
Compression
Standard
|
|
Video Compression
|
Main stream: H.265 / H.264
Sub-stream: H.265 / H.264 / MJPEG
|
|
H.264 Type
|
Baseline Profile / Main
Profile / High Profile
|
|
H.264+
|
Main stream supports
|
|
H.265 Type
|
Main Profile
|
|
H.265+
|
Main stream supports
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
Smart
Feature-set
|
|
Region of Interest
|
1 fixed region for main
stream and sub-stream
|
|
|
|
Max. Resolution
|
2560 × 1440
|
|
Main Stream Max. Frame Rate
|
50Hz: 20fps (2560 × 1440),
25fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20fps (2560 × 1440),
30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
|
|
Sub-stream
Max. Frame Rate
|
50Hz: 25fps (640 × 480, 640
× 360, 320 × 240)
60Hz: 30fps (640 × 480, 640
× 360, 320 × 240)
|
|
Image Enhancement
|
BLC, 3D DNR
|
|
Image Settings
|
Saturation, brightness,
contrast, sharpness, AGC, white balance adjustable by client software or web
browser
|
|
Day/Night Switch
|
Auto, scheduled
|
|
Network
|
|
Network Storage
|
Support Micro SD/SDHC/SDXC
card (128G ), local storage and NAS (NFS,SMB/CIFS), ANR
|
|
Alarm Trigger
|
Motion detection, video
tampering alarm, network disconnected, IP address conflicted, illegal login
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS,
FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP,
|
|
802.1X, QoS, IPv6, UDP,
Bonjour
|
|
General Function
|
One-key reset,
anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark
|
|
API
|
ONVIF (PROFILE S, PROFILE
G), ISAPI
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
User/Host
|
Up to 32 users
3 levels: Administrator,
Operator and User
|
|
Client
|
iVMS-4200, iVMS-4500,
iVMS-5200
|
|
Interface
|
|
Communication Interface
|
1 RJ45 10M/100M
self-adaptive Ethernet port
|
|
Video Output (Without -Z)
|
1Vp-p composite output (75 Ω/BNC)
|
|
Reset Button
|
Yes
|
|
General
|
|
Operating Conditions
|
-30 °C to 60 °C (-22 °F to
140 °F), humidity: 95% or less (non-condensing)
|
|
Power Supply
|
12 VDC ± 20%, 5.5 mm
coaxial power plug PoE (802.3af, class 3)
|
|
Power Consumption and
Current
|
-IZ: 12 VDC, 0.9 A, max. 11
W; PoE: (802.3af, 36 V to 57 V), 0.4 A to 0.2 A, max. 12.9 W
|
|
Protection Level
|
IP67
TVS 2000V lightning
protection, surge protection and voltage transient protection
|
|
Material
|
Metal
|
|
Dimensions
|
105 mm × 105 mm × 145 mm
(4.1" × 4.1" × 5.7")
|
