Camera |
Image Sensor | 1 / 2.5" Progressive Scan CMOS |
Min. Illumination | Color: 0.01 lux @(F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR |
Shutter Speed | 1/3 s to 1/100,000 s |
Slow Shutter | Yes |
Day & Night | IR Cut Filter |
Digital Noise Reduction | 3D DNR |
WDR | 120dB |
3-Axis Adjustment | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
Lens |
Focal Length | 4 mm |
Aperture | F2.0 |
Focus | Fixed |
FOV | 4 mm, horizontal FOV: 79°, vertical FOV: 42°, diagonal FOV: 95° |
Lens Mount | M12 |
IR |
IR Range | Up to 30 m |
Wavelength | 850nm |
Compression Standard |
Video Compression | Main stream: H.265 / H.264 Sub-stream: H.265 / H.264 / MJPEG Third stream: H.265 / H.264 |
H.264 Type | Main Profile / High Profile |
H.264+ | Main stream supports |
H.265 Type | Main Profile |
H.265+ | Main stream supports |
Video Bit Rate | 32 Kbps to 16 Mbps |
Smart Feature-set |
Smart Event | Line crossing detection, intrusion detection, face detection |
Basic Event | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
Linkage Method | Trigger recording: memory card, network storage, pre record and post record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, Email |
Region of Interest | Support 1 fixed region for main stream and sub-stream |
Image |
Max. Resolution | 3840 × 2160 |
Main Stream | 50Hz: 12.5 fps (3840 × 2160), 20fps (3072 × 1728), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60Hz: 15 fps (3840 × 2160), 20fps (3072 × 1728), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
Sub-Stream | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
Third Stream | 50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) |
Image Enhancement | BLC / 3D DNR / HLC |
Image Settings | Saturation, brightness, contrast, sharpness, AGC, and white balance adjustable by client software or web browser |
Target Cropping | No |
Day/Night Switch | Day / Night / Auto / Schedule |
Network |
Network Storage | Support Micro SD / SDHC / SDXC card (128G), local storage and NAS (NFS,SMB / CIFS), ANR |
Protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
General Function | Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening |
Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2 |
API | ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome |
Simultaneous Live View | Up to 6 channels |
User/Host | Up to 32 users 3 levels: Administrator, Operator and User |
Interface |
Video Output | No |
Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
On-board Storage | Built-in microSD / SDHC / SDXC slot, up to 128 GB |
SVC | H.264 and H.265 encoding support |
Reset Button | Yes |
General |
Operating Conditions | -30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing) |
Power Consumption and Current | 12 VDC, 0.5 A, max. 6 W PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max. 7.5 W |
Protection Level | IP67 |
Material | Metal |
Dimensions | Camera: Φ 70 mm × 155 mm (Φ 2.8" × 6.1") |
