Camera
|
Image Sensor
|
1/2.8" Progressive
Scan CMOS
|
Min. Illumination
|
Color: 0.005 Lux @ (F1.6,
AGC ON), B/W: 0 Lux with IR
|
Shutter Speed
|
1/3 s to 1/100,000 s
|
Slow Shutter
|
Yes
|
P/N
|
P/N
|
Wide Dynamic Range
|
120 dB
|
Day & Night
|
IR cut filter
|
Angle Adjustment
|
Pan: 0° to 360°, tilt: 0°
to 90°, rotate: 0° to 360°
|
Lens
|
Lens Type
|
4mm
|
Focal Length & FOV
|
4 mm, horizontal FOV 87°,
vertical FOV 46°, diagonal FOV 105°
|
Lens Mount
|
M12
|
Iris Type
|
Fixed
|
Aperture
|
F1.6
|
DORI
|
DORI
|
4 mm: D: 108 m, O: 43 m, R:
22 m, I: 11 m
|
Illuminator
|
Supplement Light Type
|
IR
|
Smart Supplement Light
|
Yes
|
IR IR Wavelength
|
850 nm
|
IR Range
|
Up to 40 m
|
Video
|
Max. Resolution
|
3840 × 2160
|
Main Stream
|
50 Hz: 20 fps (3840 × 2160)
25 fps (3200 × 1800, 2688 ×
1520, 1920 × 1080, 1280 × 720)
60 Hz: 20 fps (3840 × 2160)
30 fps (3200 × 1800, 2688 ×
1520, 1920 × 1080, 1280 × 720)
|
Sub-Stream
|
50 Hz: 25 fps (640 × 480,
640 × 360)
60 Hz: 30 fps (640 × 480,
640 × 360)
|
Third Stream
|
50 Hz: 10 fps (1920 × 1080,
1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080,
1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported
under certain settings.
|
Video Compression
|
Main stream: H.265 / H.264 /
H.264+ / H.265+
Sub-stream: H.265 / H.264 / MJPEG
Third stream: H.265 / H.264
|
Video Bit Rate
|
32 Kbps to 16 Mbps
|
H.264 Type
|
Baseline Profile / Main
Profile / High Profile
|
H.265 Type
|
Main Profile
|
H.264+
|
Main stream supports
|
H.265+
|
Main stream supports
|
Bit Rate Control
|
CBR/VBR
|
Scalable Video Coding (SVC)
|
H.264 and H.265 encoding
|
Region of Interest (ROI)
|
1 fixed region for main
stream and sub-stream
|
Network
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS,
FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4,
IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP
|
Simultaneous Live View
|
Up to 6 channels
|
API
|
Open Network Video
Interface (Profile S, Profile G), ISAPI, SDK
|
Security
|
Password protection,
complicated password, HTTPS encryption, IP address filter, Security Audit
Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and
digest authentication for Open Network Video Interface
|
Network Storage
|
NAS (NFS, SMB/CIFS), auto
network replenishment (ANR)
|
Client
|
iVMS-4200, Hik-Connect,
Hik-Central
|
|
Image Parameters Switch
|
Yes
|
Image Settings
|
Rotate, mirror, privacy
mask, saturation, brightness, contrast, sharpness, gain, white balance
adjustable by client software or web browser
|
Day/Night Switch
|
Day, Night, Auto, Schedule
|
Image Enhancement
|
BLC, HLC, 3D DNR
|
SNR
|
≥ 52 dB
|
Interface
|
Ethernet Interface
|
1 RJ45 10 M/100 M
self-adaptive Ethernet port
|
On-Board Storage
|
Built-in memory card slot
|
Microphone
|
Built-in Microphone
|
Event
|
Basic Event
|
Motion detection (human and
vehicle targets classification), video tampering alarm, exception
|
Face Detection
|
Yes
|
Deep
Learning Function
|
Perimeter Protection
|
Line crossing detection,
intrusion detection Supports human and vehicle targets classification
|
General
|
Linkage Method
|
Upload to FTP / memory card
/ NAS, Notify surveillance center, Trigger recording, Trigger capture, send
email
|
Material
|
Aluminum alloy body IR
cover: plastic
|
Dimension
|
Ø70 mm × 161.7 mm
(Ø2.8" × 6.4")
|
Package Dimension
|
216 mm × 121 mm × 118 mm
(8.6" × 4.8" × 4.7")
|
Weight
|
Approx. 495 g (1.1 lb.)
|
With Package Weight
|
Approx. 759 g (1.7 lb.)
|
Storage Conditions
|
-30 °C to 60 °C (-22 °F to
140 °F). Humidity 95% or less (non-condensing)
|
Startup and Operating
Conditions
|
-30 °C to 60 °C (-22 °F to
140 °F). Humidity 95% or less (non-condensing)
|
General Function
|
Anti-flicker, heartbeat,
password reset via email, pixel counter
|
Software Reset
|
Yes
|
Power Consumption and
Current
|
12 VDC, 0.5 A, max. 6 W
PoE (802.3af, 36 V to 57
V), 0.2 A to 0.13 A, max. 7.2 W
|
Power Supply
|
12 VDC ± 25%, reverse
polarity protection PoE: 802.3af, Class 3
|
Power Interface
|
Ø5.5 mm coaxial power plug
|
Approval
|
EMC
|
FCC (47 CFR Part 15,
Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN
61000-3-3: 2013, EN
50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC
(ICES-003: Issue 6, 2016);
KC (KN 32: 2015, KN 35: 2015)
|
Safety
|
UL (UL 60950-1); CB (IEC
60950-1:2005 + Am 1:2009 + Am 2:2013);
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013);
BIS (IS 13252(Part1): 2010+A1: 2013+A2: 2015)
|
Environment
|
CE-RoHS (2011/65/EU); WEEE
(2012/19/EU); Reach (Regulation (EC) No 1907/2006)
|
Protection
|
IP67 (IEC 60529-2013)
|
