Camera
|
|
|
Image Sensor
|
1/2.8" Progressive
Scan CMOS
|
|
|
Min. Illumination
|
Color:
0.025 Lux @(F1.2; AGC ON)
0.07 Lux @(F2.0; AGC ON)
|
|
|
Shutter Speed
|
1/3 s to 1/100,000 s
|
|
|
Slow Shutter
|
Support
|
|
|
Day & Night
|
IR Cut Filter
|
|
|
Digital Noise Reduction
|
3D DNR
|
|
|
Wide Dynamic Range
|
DWDR
|
|
|
3-Axis Adjustment
|
Pan: 0° to 355°, tilt: 0°
to 75°
|
|
|
Lens
|
|
|
Focal length
|
2.8 / 4 / 6 / 8 mm
|
|
|
Aperture
|
F2.0
|
|
|
FOV
|
2.8 mm, Horizontal field of
view: 114° 4 mm, Horizontal field of view: 90°
6 mm, Horizontal field of
view: 54° 8 mm, Horizontal field of view: 43°
|
|
|
Lens Mount
|
M12
|
|
|
IR
|
|
|
|
IR Range
|
10 to 30 m
|
|
|
Compression
Standard
|
|
|
Video Compression
|
Main stream: H.265 / H.264
Sub-stream: H.265 / H.264 /
MJPEG
|
|
|
H.264 Type
|
Baseline Profile / Main
Profile / High Profile
|
|
|
H.264+
|
Support
|
|
|
H.265 Type
|
Main Profile
|
|
|
H.265+
|
Support
|
|
|
Video Bit Rate
|
32 Kbps to 8Mbps
|
|
|
Audio Compression
|
G.711 / G.722.1 / G.726 / MP2L2
/ PCM
|
|
|
Audio Bit Rate
|
64Kbps(G.711) / 16Kbps(G.722.1)
/ 16Kbps(G.726) / 32-160Kbps(MP2L2)
|
|
|
Smart
Feature-set
|
|
|
Region of Interest
|
Support 1 fixed region for
each stream
|
|
|
|
|
|
Max. Resolution
|
1920 × 1080
|
|
|
Main Stream
|
50Hz: 25fps (1920 × 1080,
1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080,
1280 × 960, 1280 × 720)
|
|
|
Sub Stream
|
50Hz: 25fps (704 x 576, 640
x 480, 352 x 288)
60Hz: 30fps (704 x 480, 640
x 480, 352 x 240)
|
|
|
Image Enhancement
|
BLC / 3D DNR
|
|
|
Image Setting
|
Support rotate mode.
Saturation, brightness, contrast and sharpness are adjustable via client
software and web browser
|
|
|
Day / Night Switch
|
Auto / Schedule
|
|
|
Network
|
|
|
Alarm Trigger
|
Motion detection, video
tampering, network disconnected, IP address conflict, illegal login
|
|
|
Protocols
|
TCP / IP, ICMP, HTTP, HTTPS,
FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X,
QoS, IPv6, UDP, Bonjour
|
|
General Function
|
Heartbeat, mirror, password
protection, privacy mask, watermark
|
|
API
|
ONVIF, ISAPI
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
User / Host
|
Up to 32 users
3 levels: Administrator,
Operator and User
|
|
Client
|
iVMS-4200, Hik-Connect,
iVMS-5200
|
|
Interface
|
|
Audio I / O
|
Support (built-in Mic)
|
|
Communication Interface
|
1 RJ45 10M / 100M
self-adaptive Ethernet port
|
|
Reset Button
|
Support
|
|
Wi-Fi
|
|
Wireless Standards
|
IEEE802.11b, 802.11g,
802.11n
|
|
Frequency Range
|
2.4GHz:2.412 to 2.472GHz
|
|
Channel Bandwidth
|
20 / 40MHz Support
|
|
Protocols
|
802.11g/n: OFDM (BPSK, QPSK,
16QAM, 64QAM)
802.11b: CCK 11Mbps,
5.5Mbp, QPSK 2Mbps, BPSK 1Mbps
|
|
Security
|
64 / 128-bit WEP, WPA / WPA2,
WPA-PSK / WPA2-PSK, WPS
|
|
Transfer Rates
|
11b / g:54Mbps, 11n:20MHz,
40MHz. BW: up to 150Mbps
|
|
Wireless Range
|
Standard external Wi-Fi
antenna: 150 meters for an open area 30 meters for transmission through the
wall
|
|
Audio
|
|
Environment Noise Filtering
|
Support
|
|
Audio Sampling Rate
|
Max. 48 kHz
|
|
General
|
|
Operating Conditions
|
-30 °C to +60 °C (-22 °F to
+140 °F), Humidity 95% or less (non-condensing)
|
|
Power Supply
|
12 VDC ± 25%
|
|
Power Consumption and
Current
|
12 VDC, 0.4A, max. 5W
|
|
Protection Level
|
IP66
TVS 1000V Surge Protection
in power interface TVS 4000V Surge Protection in network interface
|
|
Dimensions
|
Φ 121.36 mm × 92.21 mm (Φ
4.78" × 3.63")
|
|
Weight
|
465g (1.03lb)
|
|
Material
|
Plastic
|
|
|
|
|
