Camera
|
|
|
Image Sensor
|
1/2.9" Progressive
Scan CMOS
|
|
|
Min. Illumination
|
Color: 0.01 lux @(F1.2, AGC
ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR
|
|
|
Shutter Speed
|
1/3 s to 1/100,000 s
|
|
|
Slow Shutter
|
Yes
|
|
|
Day & Night
|
IR Cut Filter
|
|
|
Digital Noise Reduction
|
3D DNR
|
|
|
WDR
|
120dB
|
|
|
3-Axis Adjustment
|
Pan: 0° to 355°, tilt: 0°
to 75°, rotate: 0° to 355°
|
|
|
Lens
|
|
|
Focal Length
|
2.8 mm
|
|
|
Aperture
|
F2.0
|
|
|
Focus
|
Fixed
|
|
|
FOV
|
2.8 mm, horizontal FOV:
97°, vertical FOV: 63°, diagonal FOV: 120°
|
|
|
Lens Mount
|
M12
|
|
|
IR
|
|
|
IR Range
|
Up to 30 m
|
|
|
Wavelength
|
850nm
|
|
|
Compression
Standard
|
|
|
Video Compression
|
Main stream: H.265 / H.264
Sub-stream: H.265 / H.264 /
MJPEG Third stream: H.265 / H.264
|
|
|
H.264 Type
|
Main Profile / High Profile
|
|
|
H.264+
|
Main stream supports
|
|
|
H.265 Type
|
Main Profile
|
|
|
H.265+
|
Main stream supports
|
|
|
Video Bit Rate
|
32 Kbps to 16 Mbps
|
|
|
Audio Compression (-S)
|
G722.1 / G.711 / G726 / MP2L2
/ PCM / MP3
|
|
|
Audio Bit Rate (-S)
|
64Kbps(G.711) / 16Kbps(G.722.1)
/ 16Kbps(G.726) / 32-192Kbps(MP2L2) / 8Kbps-320Kbps(MP3)
|
|
|
Smart
Feature-set
|
|
|
Smart Event
|
Line crossing detection,
intrusion detection, face detection
|
|
|
Basic Event
|
Motion detection, video
tampering alarm, exception (network disconnected, IP address conflict,
illegal login, HDD full, HDD error)
|
|
|
Linkage Method
|
Trigger recording: memory card,
network storage, pre-record and post-record Trigger captured pictures uploading: FTP,
HTTP, NAS, Email Trigger notification: HTTP, ISAPI,
alarm output (-S), Email
|
|
|
Region of Interest
|
Support 1 fixed region for
main stream and sub-stream
|
|
|
|
|
|
Max. Resolution
|
3072 × 2048
|
|
|
Main Stream
|
50Hz: 20 fps (3072 × 2048,
3072 × 1728, 2944 × 1656), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60Hz: 20 fps (3072 × 2048,
3072 × 1728, 2944 × 1656), 30fps (2560 × 1440, 1920 × 1080, 1280 × 720)
|
|
|
Sub-Stream
|
50Hz: 25fps (640 × 480, 640
× 360, 320 × 240)
60Hz: 30fps (640 × 480, 640
× 360, 320 × 240)
|
|
|
Third Stream
|
50Hz: 25fps (1280 × 720,
640 × 360, 352 × 288)
60Hz: 30fps (1280 × 720,
640 × 360, 352 × 240)
|
|
|
Image Enhancement
|
BLC / 3D DNR / HLC
|
|
|
Image Setting
|
Rotate mode, saturation,
brightness, contrast, sharpness, AGC, and white balance adjustable by client
software or web browser
|
|
|
Target Cropping
|
No
|
|
|
Day / Night Switch
|
Day / Night / Auto / Schedule
/ Triggered by alarm input (-S)
|
|
|
*Note: When the main stream
resolution is 2944 × 1656 and above, max frame rate is 20 fps for all
streams.
|
|
|
Network
|
|
|
Network Storage
|
Support Micro SD / SDHC / SDXC
card (128G), local storage and NAS (NFS,SMB / CIFS), ANR
|
|
|
Protocols
|
TCP/IP, UDP, ICMP, HTTP, HTTPS,
FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X,
QoS, IPv6, UDP, Bonjour, SSL/TLS
|
|
|
General Function
|
Anti-flicker, three
streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel
counter, HTTP listening
|
|
|
API
|
ONVIF (PROFILE S, PROFILE
G, PROFILE T), ISAPI, SDK, Ehome
|
|
|
Security
|
Password protection,
complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2,
EAP-LEAP, EAP-MD5),
watermark, IP address filter, basic and digest authentication for HTTP/HTTPS,
WSSE and digest authentication for ONVIF, TLS1.2
|
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
|
User/Host
|
Up to 32 users
3 levels: Administrator,
Operator and User
|
|
|
Client
|
iVMS-4200, Hik-Connect,
Hik-Central
|
|
|
Interface
|
|
|
Audio (-S)
|
1 input (line in/mic in), 1
output (line out), terminal block, mono sound
|
|
|
Alarm (-S)
|
1 input, 1 output (max. 12
VDC, 30 mA), terminal block
|
|
|
Video Output
|
No
|
|
|
Communication Interface
|
1 RJ45 10M/100M
self-adaptive Ethernet port
|
|
|
On-board Storage
|
Built-in microSD / SDHC / SDXC
slot, up to 128 GB
|
|
|
SVC
|
H.264 and H.265 encoding
support
|
|
|
Reset Button
|
Yes
|
|
|
Audio
|
|
|
Environment Noise Filtering
|
Yes
|
|
|
Audio Sampling Rate
|
8 kHz / 16 kHz / 32 kHz / 44.1
kHz / 48 kHz
|
|
|
General
|
|
|
Operating Conditions
|
-30 °C to +60 °C (-22 °F to
+140 °F), Humidity 95% or less (non-condensing)
|
|
|
Power Supply
|
12 VDC ± 25%, Φ 5.5mm PoE(802.3af,
class 3)
|
|
|
Power Consumption and
Current
|
12 VDC, 0.6 A, max. 7.5 W
PoE: (802.3af, 36 V to 57
V), 0.3 A to 0.2 A, max. 9 W
|
|
|
Protection Level
|
IP67, IK10
|
|
|
Material
|
Camera body: metal, bubble:
plastic
|
|
Dimensions
|
Camera: Φ 111 mm × 82.4 mm
(Φ 4.4" × 3.2")
|
|
Weight
|
Camera: approx. 500 g (1.1
lb.)
|
|
|
|
|
