Camera
|
|
Image Sensor
|
1/2.7" Progressive
Scan CMOS
|
|
Min. Illumination
|
Color: 0.01 Lux @ (F1.2,
AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR
|
|
Shutter Speed
|
1/3 s to 1/100,000 s
|
|
Slow Shutter
|
Yes
|
|
Day & Night
|
IR Cut Filter
|
|
Digital Noise Reduction
|
3D DNR
|
|
WDR
|
120dB
|
|
3-Axis Adjustment
|
Pan: 0° to 360°, tilt: 0°
to 90°, rotate: 0° to 360°
|
|
Lens
|
|
Focal length
|
2.8
|
|
Aperture
|
F2.0
|
|
FOV
|
2.8 mm, horizontal FOV:
114°, vertical FOV: 62°, diagonal FOV: 135°
|
|
Lens Mount
|
M12
|
|
IR
|
|
IR Range
|
10 m
|
|
Wavelength
|
850nm
|
|
PIR
|
|
Angle
|
Horizontal: 90°, Vertical:
80°
|
|
PIR Range
|
10 m
|
|
Compression
Standard
|
|
Video Compression
|
Main stream: H.265 / H.264
Sub-stream: H.265 / H.264 /
MJPEG
Third stream: H.265 / H.264
|
|
H.264 Type
|
Main Profile / High Profile
|
|
H.264+
|
Main stream supports
|
|
H.265 Type
|
Main Profile
|
|
H.265+
|
Main stream supports
|
|
Video Bit Rate
|
32 Kbps to 16 Mbps
|
|
Audio Compression
|
G722.1 / G711ulaw / G711alaw
/ G726 / MP2L2 / PCM
|
|
Audio Bit Rate
|
64Kbps(G.711) / 16Kbps(G.722.1)
/ 16Kbps(G.726) / 32-160Kbps(MP2L2)
|
|
Smart
Feature-set
|
|
Smart Event
|
Line crossing detection,
intrusion detection, face detection
|
|
Basic Event
|
Motion detection, video
tampering alarm, exception (network disconnected, IP address conflict,
illegal login, HDD full, HDD error)
|
|
Linkage Method
|
Trigger recording: memory card,
network storage, pre-record and post-record Trigger captured pictures
uploading: FTP, HTTP, NAS, Email
Trigger notification: HTTP, ISAPI, Email
|
|
Region of Interest
|
Support 1 fixed region for
main stream and sub-stream separately
|
|
|
|
Max. Resolution
|
1920 × 1080
|
|
Main Stream
|
50Hz: 25fps (1920 × 1080,
1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080,
1280 × 960, 1280 × 720)
|
|
Sub-Stream
|
50Hz: 25fps (640 × 480, 640
× 360, 320 × 240)
60Hz: 30fps (640 × 480, 640
× 360, 320 × 240)
|
|
Third Stream
|
50Hz: 25fps (1920 × 1080,
1280 × 720, 640 × 360, 352 × 288)
60Hz: 30fps (1920 × 1080,
1280 × 720, 640 × 360, 352 × 240)
|
|
Image Setting
|
Rotate mode, saturation,
brightness, contrast, sharpness, AGC, and white balance are adjustable by
client software or web browser
|
|
Image Enhancement
|
BLC / 3D DNR / HLC
|
|
Day / Night Switch
|
Day / Night / Auto / Schedule
|
|
Network
|
|
Network Storage
|
Support MicroSD / SDHC / SDXC
card (128G), local storage and NAS (NFS, SMB / CIFS), ANR
|
|
Protocols
|
TCP/IP, UDP, ICMP, HTTP, HTTPS,
FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X,
QoS, IPv6, UDP, Bonjour, SSL/TLS
|
|
General Function
|
Anti-flicker, three
streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
|
|
Security
|
Password protection,
complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5),
watermark, IP address filter, basic and digest authentication for HTTP/HTTPS,
WSSE and digest authentication for ONVIF, TLS1.2
|
|
API
|
ONVIF (PROFILE S, PROFILE
G, PROFILE T), ISAPI, SDK, Ehome
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
User/Host
|
Up to 32 users
3 levels: Administrator,
Operator and User
|
|
Client
|
iVMS-4200, Hik-Connect,
Hik-Central
|
|
Interface
|
|
Audio
|
1 built-in mic, 1 built-in
speaker, mono sound
|
|
Communication Interface
|
1 RJ45 10M/100M
self-adaptive Ethernet port
|
|
On-board storage
|
Built-in Micro SD / SDHC / SDXC
slot, up to 128G
|
|
SVC
|
Support H.264 and H.265
encoding
|
|
Reset Button
|
Yes
|
|
Wi-Fi
(-W)
|
|
Wireless Standards
|
IEEE 802.11b / g / n
|
|
Frequency Range
|
2.412 GHz to 2.4835 GHz
|
|
Channel Bandwidth
|
20M/40M
|
|
Protocols
|
802.11b: DQPSK, DBPSK, CCK
802.11g/n: OFDM/64-QAM,
16-QAM, QPSK, BPSK
|
|
Security
|
WPA, WPA2
|
|
Transfer Rates
|
11b: 11Mbps, 11g: 54Mbps,
11n: up to 150Mbps
|
|
Wireless Range
|
50 m
|
|
Audio
|
|
Environment Noise Filtering
|
Yes
|
|
Audio Sampling Rate
|
8 kHz / 16 kHz / 32 kHz / 44.1
kHz / 48 kHz
|
|
General
|
|
Operating Conditions
|
-10 °C to +40 °C (14 °F to
+104 °F), Humidity 95% or less (non-condensing)
|
|
Power Supply
|
12 VDC ± 25%, PoE (802.3af,
class 3)
|
Power Consumption and Current
|
12 VDC, 0.5 A, max. 6 W, Φ
5.5 mm coaxial plug power PoE (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max. 7
W
|
Material
|
Plastic
|
Dimensions
|
102.8 mm × 65.2 mm × 32.6
mm (4.1" × 2.6" × 1.3")
|
Weight
|
Camera: Approx. 128 g (0.3
lb.)
|
