Camera
|
|
|
Image Sensor
|
1/3" Progressive Scan
CMOS
|
|
|
Min. Illumination
|
Color: 0.01 Lux @ (F1.2,
AGC ON), 0.018 lux @(F1.6, AGC ON), 0 lux with IR
|
|
|
Shutter Speed
|
1/3 s to 1/100,000 s
|
|
|
Slow Shutter
|
Yes
|
|
|
Day & Night
|
IR Cut Filter
|
|
|
Digital Noise Reduction
|
3D DNR
|
|
|
WDR
|
120dB
|
|
|
3-Axis Adjustment
|
Pan: -30° to +30°, tilt: 0°
to 75°, rotate: 0° to 360°
|
|
|
Lens
|
|
|
Focal Length
|
2.8, 4, 6 mm
|
|
|
Aperture
|
F1.6
|
|
|
FOV
|
2.8 mm, Horizontal field of
view: 98°, Vertical field of view: 55°, Diagonal field of view: 114°
|
|
|
Lens Mount
|
M12
|
|
|
IR
|
|
|
IR Range
|
Up to 10 m
|
|
|
Wavelength
|
850nm
|
|
|
Compression
Standard
|
|
|
Video Compression
|
Main stream: H.265 / H.264
Sub-stream: H.265 / H.264 /
MJPEG
Third stream: H.265 / H.264
|
|
|
H.264 Type
|
Main Profile / High Profile
|
|
|
H.264+
|
Main stream supports
|
|
|
H.265 Type
|
Main Profile
|
|
|
H.265+
|
Main stream supports
|
|
|
Video Bit Rate
|
32 Kbps to 16 Mbps
|
|
|
Audio Compression (-S)
|
G722.1 / G.711 / G726 / MP2L2
/ PCM / MP3
|
|
|
Audio Bit Rate (-S)
|
64Kbps(G.711) / 16Kbps(G.722.1)
/ 16Kbps(G.726) / 32-192Kbps(MP2L2) / 8Kbps-320Kbps(MP3)
|
|
|
Smart
Feature-set
|
|
|
Smart Event
|
Line crossing detection,
intrusion detection, face detection
|
|
|
Basic Event
|
Motion detection, video
tampering alarm, exception (network disconnected, IP address conflict,
illegal login, HDD full, HDD error)
|
|
|
Linkage Method
|
Trigger recording: memory card,
network storage, pre-record and post-record
Trigger captured pictures uploading
FTP, HTTP, NAS, Email
Trigger notification: HTTP,
ISAPI, alarm output (-S), Email
|
|
|
Region of Interest
|
Support 1 fixed region for
main stream and sub-stream separately
|
|
|
|
|
|
Max. Resolution
|
2688 × 1520
|
|
|
Main Stream
|
50Hz: 25fps (2688 × 1520,
2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 30fps (2688 × 1520,
2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720)
|
|
|
Sub-Stream
|
50Hz: 25fps (640 × 480, 640
× 360, 320 × 240)
60Hz: 30fps (640 × 480, 640
× 360, 320 × 240)
|
|
|
Third Stream
|
50Hz: 25fps (1280 × 720,
640 × 360, 352 × 288)
60Hz: 30fps (1280 × 720,
640 × 360, 352 × 240)
|
|
|
Image Setting
|
Rotate mode, saturation,
brightness, contrast, sharpness, AGC, and white balance adjustable by client
software or web browser
|
|
|
Image Enhancement
|
BLC / 3D DNR / HLC
|
|
|
Day / Night Switch
|
Auto / Schedule / Day / Night
/ Triggered by Alarm In (-S model)
|
|
|
Network
|
|
|
Network Storage
|
Support MicroSD / SDHC / SDXC
card (128G), local storage and NAS (NFS, SMB / CIFS), ANR
|
|
|
Protocols
|
TCP/IP, UDP, ICMP, HTTP, HTTPS,
FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X,
QoS, IPv6, UDP, Bonjour, SSL/TLS
|
|
|
General Function
|
Anti-flicker, three
streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel
counter, HTTP listening
|
|
|
API
|
ONVIF (PROFILE S, PROFILE
G, PROFILE T), ISAPI, SDK, Ehome
|
|
|
Security
|
Password protection,
complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2,
EAP-LEAP, EAP-MD5),
watermark, IP address filter, basic and digest authentication for HTTP/HTTPS,
WSSE and digest authentication for ONVIF, TLS1.2
|
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
|
User/Host
|
Up to 32 users
3 levels: Administrator,
Operator and User
|
|
|
Client
|
iVMS-4200, Hik-Connect,
Hik-Central
|
|
|
Interface
|
|
|
Audio (-S model)
|
2 Inputs: line in, or mic
in (built-in microphone), 1 Output: line out, mono sound, terminal block
|
|
|
Alarm (-S model)
|
1 Input: Alarm in, 1
Output: Alarm out (max. 12 VDC, 30 mA), terminal block
|
|
|
Communication Interface
|
1 RJ45 10M/100M
self-adaptive Ethernet port
|
|
|
On-board storage
|
Built-in Micro SD / SDHC / SDXC
slot, up to 128G
|
|
|
SVC
|
Support H.264 and H.265
encoding
|
|
|
Reset Button
|
Yes
|
|
|
Audio
(-S model)
|
|
|
Environment Noise Filtering
|
Yes
|
|
|
Audio Sampling Rate
|
16 kHz, 32kHz, 44.1kHz,
48kHz
|
|
|
General
|
|
|
Operating Conditions
|
-30 °C to +60 °C (-22 °F to
+140 °F), Humidity 95% or less (non-condensing)
|
|
|
Power Supply
|
12 VDC ± 25%, PoE (802.3af,
class 3)
|
|
Power Consumption and
Current
|
12 VDC, 0.7 A, max. 8.5 W,
Φ 5.5mm coaxial plug power PoE (802.3af, 36 V to 57 V), 0.3 A to 0.1 A, max.
10 W
|
|
Protection Level
|
IK08, IP66
|
|
Material
|
Front cover: plastic,
Bottom base: metal
|
|
Dimensions
|
Φ110 mm × 56.4 mm
(Φ4.3" × 2.2")
|
|
Weight
|
Camera: Approx. 400 g (0.9
lb.)
|
|
|
|
|
