Camera
|
|
Image Sensor
|
1/2.5" Progressive
Scan CMOS
|
|
Min. Illumination
|
Color: 0.009 lux @(F1.2,
AGC ON), 0.016 lux @(F1.6, AGC ON), 0 lux with IR
|
|
Shutter Speed
|
1/3 s to 1/100,000 s
|
|
Slow Shutter
|
Yes
|
|
Auto-Iris
|
No
|
|
Day & Night
|
IR Cut Filter
|
|
Digital Noise Reduction
|
3D DNR
|
|
WDR
|
120dB
|
|
3-Axis Adjustment
|
Pan: 0° to 355°, tilt: 0°
to 75°, rotate: 0° to 355°
|
|
Lens
|
|
Focal Length
|
2.8 to 12 mm
|
|
Aperture
|
F1.2
|
|
Focus
|
Auto
|
|
FOV
|
2.8 mm to 12 mm, horizontal
FOV: 114° to 32°, vertical FOV: 59° to 18°, diagonal FOV: 141° to 36.5°
|
|
Lens Mount
|
Φ14
|
|
IR
|
|
IR Range
|
Up to 30 m
|
|
Wavelength
|
850nm
|
|
Compression
Standard
|
|
Video Compression
|
Main stream: H.265 / H.264
Sub-stream: H.265 / H.264 /
MJPEG
Third stream: H.265 / H.264
|
|
H.264 Type
|
Main Profile / High Profile
|
|
H.264+
|
Yes
|
|
H.265 Type
|
Main Profile
|
|
H.265+
|
Yes
|
|
Video Bit Rate
|
32 Kbps to 16 Mbps
|
|
Audio Compression
|
G.711 / G.722.1 / G.726 / MP2L2
/ PCM
|
|
Audio Bit Rate
|
64Kbps(G.711) / 16Kbps(G.722.1)
/ 16Kbps(G.726) / 32-192Kbps(MP2L2)
|
|
Smart
Feature-set
|
|
Behavior Analysis
|
Line crossing detection,
intrusion detection, object removal detection, unattended baggage detection
|
|
Exception Detection
|
Scene change detection
|
|
Face Detection
|
Yes
|
|
Region of Interest
|
Support 1 fixed region for
main stream and sub-stream
|
|
|
|
Max. Resolution
|
2560 × 1440
|
|
Main Stream
|
50Hz: 25 fps (2560 × 1440,
2304 × 1296, 1920 × 1080)
60Hz:30 fps (2560 × 1440,
2304 × 1296, 1920 × 1080)
|
|
Sub-Stream
|
50Hz: 25 fps (640 × 480,
640 × 360, 320 × 240)
60Hz: 30 fps (640 × 480,
640 × 360, 320 × 240)
|
|
Third Stream
|
50Hz: 25 fps (1280 × 720,
640 × 360, 352 × 288)
60Hz: 30 fps (1280 × 720,
640 × 360, 352 × 240)
|
|
Image Enhancement
|
BLC / 3D DNR
|
|
Image Settings
|
Rotate mode, saturation,
brightness, contrast, sharpness, and white balance adjustable by client
software or web browser
|
|
Target Cropping
|
No
|
|
SVC
|
H.264 and H.265 encoding
support
|
|
Day / Night Switch
|
Day / Night / Auto / Schedule
/ Triggered by alarm in
|
|
Network
|
|
Network Storage
|
Support microSD / SDHC / SDXC
card (128G), local storage and NAS (NFS, SMB / CIFS), ANR
|
|
Alarm Trigger
|
Motion detection, video
tampering, network disconnected, IP address conflict, illegal login, HDD
full, HDD error
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS, FTP,
DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X,
QoS, IPv6, Bonjour
|
|
General Function
|
One-key reset,
anti-flicker, three streams, heartbeat, mirror, password protection, privacy
mask, watermark, IP address filter
|
|
API
|
ONVIF (PROFILE S, PROFILE
G), ISAPI
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
User/Host
|
Up to 32 users
3 Levels: Administrator,
Operator and User
|
|
Client
|
iVMS-4200, Hik-Connect,
iVMS-5200, iVMS-4500
|
|
Web Browser
|
IE8+, Chrome 31.0-44,
Firefox 30.0-51, Safari 8.0+
|
|
Interface
|
|
Audio
|
1 input (line in, 3.5 mm),
1 output (line out, 3.5 mm), mono sound
|
|
Alarm
|
1 input, 1 output
|
|
Video Output
|
1Vp-p Composite Output(75Ω)
(For adjustment only)
|
|
Communication Interface
|
1 RJ45 10M/100M
self-adaptive Ethernet port
|
|
On-board storage
|
Built-in microSD / SDHC / SDXC
slot, up to 128 GB
|
|
Reset Button
|
Yes
|
|
Audio
|
|
Environment Noise Filtering
|
Yes
|
|
Audio Sampling Rate
|
8kHz / 16kHz / 32kHz / 44.1kHZ
/ 48kHz
|
|
General
|
|
Operating Conditions
|
-30 °C to +60 °C (-22 °F to
+140 °F), humidity 95% or less (non-condensing)
|
|
Power Supply
|
12 VDC ± 25%, terminal
block for DC input PoE(802.3af, class 3)
|
|
Power Consumption and
Current
|
12 VDC, 1 A, max. 11 W
PoE (802.3af, 36V to 57V),
0.4 A to 0.2 A, max. 12.5 W
|
|
Protection Level
|
IP67, IK10
|
|
Material
|
Metal
|
|
Dimensions
|
Φ153.4 × 133.1 mm (Φ6"
× 5.2")
|
|
Weight
|
Camera: 1287 g (2.8 lb.)
|
