Camera
|
|
Image Sensor
|
1/2.5" Progressive
Scan CMOS
|
|
Min. Illumination
|
Color: 0.01 lux @(F1.2, AGC
ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR
|
|
Shutter Speed
|
1/3 s to 1/100,000 s
|
|
Slow Shutter
|
Yes
|
|
Day & Night
|
IR Cut Filter
|
|
Digital Noise Reduction
|
3D DNR
|
|
WDR
|
120dB
|
|
3-Axis Adjustment
|
Pan: 0° to 360°, tilt: 0°
to 100°, rotate: 0° to 360°
|
|
Lens
|
|
Focal Length
|
4 mm
|
|
Aperture
|
F2.0
|
|
Focus
|
Fixed
|
|
FOV
|
4 mm, horizontal FOV: 79°,
vertical FOV: 42°, diagonal FOV: 95°
|
|
Lens Mount
|
M12
|
|
IR
|
|
IR Range
|
I8: up to 80 m
|
|
Wavelength
|
850nm
|
|
Compression
Standard
|
|
Video Compression
|
Main stream: H.265 / H.264
Sub-stream: H.265 / H.264 /
MJPEG
Third stream: H.265 / H.264
|
|
H.264 Type
|
Main Profile / High Profile
|
|
H.264+
|
Main stream supports
|
|
H.265 Type
|
Main Profile
|
|
H.265+
|
Main stream supports
|
|
Video Bit Rate
|
32 Kbps to 16 Mbps
|
|
Smart
Feature-set
|
|
Smart Event
|
Line crossing detection,
intrusion detection, face detection
|
|
Basic Event
|
Motion detection, video
tampering alarm, exception (network disconnected, IP address conflict,
illegal login, HDD full, HDD error)
|
|
Linkage Method
|
Trigger recording: memory
card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger
notification: HTTP, ISAPI, Email
|
|
Region of Interest
|
Support 1 fixed region for
main stream and sub-stream
|
|
|
|
Max. Resolution
|
3840 × 2160
|
|
Main Stream
|
50Hz: 12.5 fps (3840 ×
2160), 20fps (3072 × 1728), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60Hz: 15 fps (3840 × 2160),
20fps (3072 × 1728), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
|
|
Sub-Stream
|
50Hz: 25fps (640 × 480, 640
× 360, 320 × 240)
60Hz: 30fps (640 × 480, 640
× 360, 320 × 240)
|
|
Third Stream
|
50Hz: 25fps (1280 × 720,
640 × 360, 352 × 288)
60Hz: 30fps (1280 × 720,
640 × 360, 352 × 240)
|
|
Image Enhancement
|
BLC / 3D DNR / HLC
|
|
Image Settings
|
Saturation, brightness,
contrast, sharpness, AGC, and white balance adjustable by client software or
web browser
|
|
Target Cropping
|
No
|
|
Day / Night Switch
|
Day / Night / Auto / Schedule
|
|
*Note: When the main stream
resolution is 3840 × 2160, max frame rate is 12.5 fps (50Hz) / 15 fps (60Hz)
for all streams. When the main stream resolution is 3072 × 1728, max frame
rate is 20 fps for all streams.
|
|
Network
|
|
Network Storage
|
Support Micro SD / SDHC / SDXC
card (128G), local storage and NAS (NFS, SMB / CIFS), ANR
|
|
Protocols
|
TCP/IP, UDP, ICMP, HTTP,
HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP,
IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
|
|
General Function
|
Anti-flicker, three
streams, heartbeat, mirror, privacy masks, password reset via e-mail,
pixel counter, HTTP listening
|
|
Security
|
Password protection,
complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5),
watermark, IP address filter, basic and digest authentication for HTTP/HTTPS,
WSSE and digest authentication for ONVIF, TLS1.2
|
|
API
|
ONVIF (PROFILE S, PROFILE
G, PROFILE T), ISAPI, SDK, Ehome
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
User/Host
|
Up to 32 users
3 levels: Administrator,
Operator and User
|
|
Client
|
iVMS-4200, Hik-Connect,
Hik-Central
|
|
Interface
|
|
Video Output
|
No
|
|
Communication Interface
|
1 RJ45 10M/100M
self-adaptive Ethernet port
|
|
On-board Storage
|
Built-in microSD / SDHC / SDXC
slot, up to 128 GB
|
|
SVC
|
H.264 and H.265 encoding
support
|
|
Reset Button
|
Yes
|
|
General
|
|
Operating Conditions
|
-30 °C to +60 °C (-22 °F to
+140 °F), Humidity 95% or less (non-condensing)
|
|
Power Supply
|
12 VDC ± 25%, Φ 5.5mm
PoE(802.3af, class 3)
|
|
Power Consumption and
Current
|
12 VDC, 0.9 A, max. 11 W PoE: (802.3af, 36 V to 57 V), 0.4 A to 0.2 A, max. 12.9 W |
|
Protection Level
|
IP67
|
|
Material
|
Metal
|
|
Dimensions
|
Camera: Φ 104.8 × 299.7 mm
(Φ 4.1" × 11.8") Package: 386 × 156 × 155 mm (15.2" ×
6.1" × 6.1")
|
