Camera
Module
|
Image Sensor
|
1/2.8" progressive
scan CMOS
|
Min. Illumination
|
Color: 0.005 Lux @(F1.6,
AGC ON) B/W: 0.001Lux @(F1.6, AGC ON)
0 Lux with IR
|
White Balance
|
Auto / Manual / ATW
(Auto-tracking White Balance) / Indoor / Outdoor / Fluorescent Lamp / Sodium
Lamp
|
Gain
|
Auto / Manual
|
Shutter Time
|
50Hz: 1/1 s to 1/30,000 s
60Hz: 1/1 s to 1/30,000 s
|
Day & Night
|
IR Cut Filter
|
Digital Zoom
|
16×
|
Privacy Mask
|
24 programmable privacy
masks, mask color configurable
|
Focus Mode
|
Auto / Semi-automatic / Manual
|
WDR
|
120 dB WDR
|
Lens
|
Focal Length
|
4.8 mm to 153 mm, 32×
optical zoom
|
Zoom Speed
|
Approx. 5.6 s (optical
lens, wide-tele)
|
Field of View
|
Horizontal field of view:
55.6° to 2.04° (Wide-Tele) Vertical field of view: 32.4° to 1.14° (Wide-Tele)
Diagonal field of view: 63° to 2.34° (Wide-Tele)
|
Working Distance
|
10 mm to 1500 mm
(wide-tele)
|
Aperture Range
|
F1.2 to F4.4
|
IR
|
IR Distance
|
150 m
|
Smart IR
|
Yes
|
PTZ
|
Movement Range (Pan)
|
360° endless
|
Pan Speed
|
Configurable, from 0.1°/s
to 120°/s Preset speed: 120°/s
|
Movement Range (Tilt)
|
From -15° to 90°
(auto-flip)
|
Tilt Speed
|
Configurable, from 0.1°/s
to 80°/s Preset Speed: 80°/s
|
Proportional Zoom
|
Yes
|
Presets
|
300
|
Patrol Scan
|
8 patrols, up to 32 presets
for each patrol
|
Pattern Scan
|
4 pattern scans, record
time over 10 minutes for each scan
|
Power-off Memory
|
Yes
|
Park Action
|
Preset / Pattern Scan / Patrol
Scan / Auto Scan / Tilt Scan / Random Scan / Frame Scan / Panorama Scan
|
3D Positioning
|
Yes
|
PTZ Position Display
|
Yes
|
Preset Freezing
|
Yes
|
Scheduled Task
|
Preset / Pattern Scan / Patrol
Scan / Auto Scan / Tilt Scan / Random Scan / Frame Scan / Panorama Scan / Dome
Reboot / Dome Adjust / Aux Output
|
Compression
Standard
|
Video Compression
|
Main Stream: H.265+ / H.265
/ H.264+ / H.264
Sub-stream: H.265 / H.264 /
MJPEG
Third Stream: H.265 / H.264
/ MJPEG
|
H.264 Type
|
Baseline Profile / Main
Profile / High Profile
|
H.264+
|
Yes
|
H.265 Type
|
Main Profile
|
H.265+
|
Yes
|
Video Bitrate
|
256 Kbps to 16384 Kbps
|
Audio Compression
|
G.711alaw / G.711ulaw / G.722.1
/ G.726 / MP2L2 / PCM
|
Audio Bitrate
|
G.711alaw / G.711ulaw: 64
Kbps
G.722.1 / G.726: 16 Kbps
MP212 / PCM: 32 Kbps to 160
Kbps
|
SVC
|
Yes
|
Smart
Features
|
Basic Event
|
Motion Detection, Video
Tampering Detection, Exception
|
Smart Event
|
Intrusion Detection, Line
Crossing Detection, Region Entrance Detection, Region Exiting Detection,
Object Removal Detection, Unattended Baggage Detection, Audio Exception
Detection
|
Smart Record
|
ANR (Automatic Network
Replenishment), Dual-VCA
|
ROI
|
Main stream, sub-stream,
and third stream respectively support four fixed areas.
|
|
Max. Resolution
|
1920 × 1080
|
Main Stream
|
50Hz: 25fps (1920 × 1080,
1280 × 960, 1280 × 720)
50fps (1280 × 960, 1280 ×
720)
60Hz: 30fps (1920 × 1080,
1280 × 960, 1280 × 720)
60fps (1280 × 960, 1280 ×
720)
|
Sub-Stream
|
50Hz: 25fps (704 × 576, 640
× 480, 352 × 288)
60Hz: 30fps (704 × 480, 640
× 480, 352 × 240)
|
Third Stream
|
50Hz: 25fps (1920 × 1080,
1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (1920 × 1080,
1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
|
Image Enhancement
|
HLC / BLC / 3D DNR / Defog
/ EIS / Regional Exposure / Regional Focus
|
Network
|
Network Storage
|
Built-in memory card slot,
support Micro SD / SDHC / SDXC, up to 256 GB; NAS (NFS, SMB / CIFS), ANR
|
Alarm Linkage
|
Alarm actions, such as
Preset, Patrol Scan, Pattern Scan, Trigger Recording, Trigger Alarm Output,
Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc.
|
Protocols
|
IPv4/IPv6, HTTP, HTTPS,
802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP,
UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
|
API
|
ONVIF (Profile S, Profile
G, Profile T), ISAPI, SDK
|
Security Measures
|
User authentication (ID and
PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x
port-based network access control; IP address filtering
|
Client
|
iVMS-4200, iVMS-4500,
iVMS-5200, Hik-Connect
|
Interface
|
Network Interface
|
1 RJ45 10 M/100 M Ethernet,
Hi-PoE
|
Audio
|
1-ch audio input, 2 to 2.4
V[p-p], 1 KΩ ± 10%
1-ch audio output, line
level, impedance: 600 Ω
|
Alarm
|
2-ch alarm input / 1-ch
alarm output
|
General
|
Power
|
24 VAC, 2.2 A, 50 / 60 Hz
and Hi-PoE, 42.5 to 57 VDC, 1.41 A
Max.: 30 W, including max.
10W for IR
|
Working Temperature
|
-30°C to 65°C (-22°F to
149°F)
|
Working Humidity
|
≤ 90%
|
Protection Level
|
IP66 Standard, 4000V
Lightning Protection, Surge Protection and Voltage Transient Protection
|
Material
|
ADC 12, PC, PC+10% GF
|
Dimensions
|
Φ 208 mm × 345 mm (Φ
8.19" × 13.58")
|
Weight
|
Approx. 3.3 kg (7.28 lb)
|
