Camera
Module
|
|
Image Sensor
|
1/2.8" progressive
scan CMOS
|
|
Min. Illumination
|
Color: 0.005 Lux @(F1.6,
AGC ON) B/W: 0.001Lux @(F1.6, AGC ON)
0 Lux with IR
|
|
White Balance
|
Auto / Manual / ATW
(Auto-tracking White Balance) / Indoor / Outdoor / Fluorescent Lamp / Sodium
Lamp
|
|
Gain
|
Auto / Manual
|
|
Shutter Time
|
50Hz: 1/1 s to 1/30,000 s
60Hz: 1/1 s to 1/30,000 s
|
|
Day & Night
|
IR Cut Filter
|
|
Digital Zoom
|
16×
|
|
Privacy Mask
|
24 programmable privacy
masks
|
|
Focus Mode
|
Auto / Semi-automatic / Manual
|
|
WDR
|
120 dB WDR
|
|
Lens
|
|
Focal Length
|
4.8 mm to 153 mm, 32×
optical zoom
|
|
Zoom Speed
|
Approx. 5.6 s (optical
lens, wide-tele)
|
|
Field of View
|
Horizontal field of view:
55.6° to 2.04° (Wide-Tele) Vertical field of view: 32.4° to 1.14° (Wide-Tele)
Diagonal field of view: 63° to 2.34° (Wide-Tele)
|
|
Working Distance
|
10 mm to 1500 mm
(wide-tele)
|
|
Aperture Range
|
F1.2 to F4.4
|
|
IR
|
|
IR Distance
|
150 m
|
|
Smart IR
|
Yes
|
|
PTZ
|
|
Movement Range (Pan)
|
360° endless
|
|
Pan Speed
|
Configurable, from 0.1° / s
to 160° / s, Preset speed: 240° / s
|
|
Movement Range (Tilt)
|
From -15° to 90°
(auto-flip)
|
|
Tilt Speed
|
Configurable, from 0.1° / s
to 120° / s Preset Speed: 200° / s
|
|
Proportional Zoom
|
Yes
|
|
Presets
|
300
|
|
Patrol Scan
|
8 patrols, up to 32 presets
for each patrol
|
|
Pattern Scan
|
4 pattern scans, record
time over 10 minutes for each scan
|
|
Power-off Memory
|
Yes
|
|
Park Action
|
Preset / Pattern Scan / Patrol
Scan / Auto Scan / Tilt Scan / Random Scan / Frame Scan / Panorama Scan
|
|
3D Positioning
|
Yes
|
|
PTZ Position Display
|
Yes
|
|
Preset Freezing
|
Yes
|
|
Scheduled Task
|
Preset / Pattern Scan / Patrol
Scan / Auto Scan / Tilt Scan / Random Scan / Frame Scan / Panorama Scan / Dome
Reboot / Dome Adjust / Aux Output
|
|
Compression
Standard
|
|
Video Compression
|
Main Stream: H.265+ / H.265
/ H.264+ / H.264
Sub-stream: H.265 / H.264 /
MJPEG
Third Stream: H.265 / H.264
/ MJPEG
|
|
H.264 Type
|
Baseline Profile / Main
Profile / High Profile
|
|
H.264+
|
Yes
|
|
H.265 Type
|
Main Profile
|
|
H.265+
|
Yes
|
|
Video Bitrate
|
32 Kbps to 16384 Kbps
|
|
Audio Compression
|
G.711alaw / G.711ulaw / G.722.1
/ G.726 / MP2L2 / PCM
|
|
Audio Bitrate
|
G.711alaw / G.711ulaw: 64
Kbps
G.722.1 / G.726: 16 Kbps
MP212 / PCM: 32 Kbps / 64
Kbps / 128 Kbps
|
|
SVC
|
Yes
|
|
Smart
Features
|
|
Basic Event
|
Motion Detection, Alarm
Input, Alarm Output, Video Tampering Detection, Exception
|
|
Smart Event
|
Face Detection, Intrusion
Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting
Detection, Object Removal Detection, Unattended Baggage Detection, Audio
Exception Detection
|
|
Smart Record
|
ANR (Automatic Network
Replenishment), Dual-VCA
|
|
ROI
|
Main stream, sub-stream,
and third stream respectively support four fixed areas.
|
|
Auto-Tracking
|
Yes
|
|
|
|
Max. Resolution
|
1920 × 1080
|
|
Main Stream
|
50fps (1920 × 1080, 1280 × 960, 1280 × 720) 60fps (1920 × 1080, 1280 × 960, 1280 × 720) |
|
Sub-Stream
|
50Hz: 25fps (704 × 576, 640
× 480, 352 × 288)
60Hz: 30fps (704 × 480, 640
× 480, 352 × 240)
|
|
Third Stream
|
50Hz: 25fps (1920 × 1080,
1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (1920 × 1080,
1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
|
|
Image Enhancement
|
HLC / BLC / 3D DNR / Defog
/ EIS / Regional Exposure / Regional Focus
|
|
Network
|
|
Network Storage
|
Built-in memory card slot,
support Micro SD / SDHC / SDXC, up to 256 GB; NAS (NFS, SMB / CIFS), ANR
|
|
Alarm Linkage
|
Alarm actions, such as
Notify Surveillance Center, Upload to FTP, Send Email, Trigger Recording,
Recording Linkage, and Alarm Input, etc.
|
|
Protocols
|
IPv4/IPv6, HTTP, HTTPS,
802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP,
UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
|
|
API
|
ONVIF (Profile S, Profile
G, Profile T), ISAPI, SDK
|
|
Simultaneous Live View
|
Up to 20 channels
|
|
Security Measures
|
User authentication (ID and
PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x
port-based network access control; IP address filtering
|
|
Client
|
iVMS-4200, iVMS-4500,
iVMS-5200, Hik-Connect
|
|
Interface
|
|
Alarm Interface
|
2-ch alarm input and 1-ch
alarm output
|
|
Audio Interface
|
1-ch audio input and 1-ch
audio output
|
|
Network Interface
|
1 RJ45 10 M/100 M Ethernet,
Hi-PoE
|
|
General
|
|
Power
|
24 VAC and Hi-PoE. Max. 40
W, including max. 14 W for IR and max. 6 W for heater
|
|
Working Temperature
|
-30°C to 65°C (-22°F to
149°F)
|
|
Working Humidity
|
≤ 90%
|
|
Protection Level
|
IP66 Standard, 4000V
Lightning Protection, Surge Protection and Voltage Transient Protection
|
|
Material
|
ADC 12, PC, PC+10%GF
|
|
Dimensions
|
Φ 220 mm × 353.4 mm (Φ
8.66" × 13.91")
|
|
Weight
|
Approx. 4.5 kg (9.92 lb)
|
