Recording |
Video compression | H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 |
Encoding resolution | When 1080p Lite mode not enabled: 4 MP lite / 3 MP / 1080p / 1080p lite / 720p / WD1 / 4CIF / VGA / CIF When 1080p Lite mode enabled: 4 MP lite / 3 MP / 1080p lite / 720p / 720p lite / WD1 / 4CIF / VGA / CIF |
Frame rate | Main stream: When 1080p Lite mode not enabled: For 4 MP stream access: 4 MP lite@15fps; 1080p lite / 720p / WD1 / 4CIF / VGA / CIF@25fps (P) / 30fps (N) For 3 MP stream access: 3 MP / 1080p / 720p / WD1 / 4CIF / VGA / CIF@15fps For 1080p stream access: 1080p / 720p@15fps; WD1 / 4CIF / VGA / CIF@25fps (P) / 30fps (N) For 720p stream access: 720p / WD1 / 4CIF / VGA / CIF@25fps (P) / 30fps (N) When 1080p Lite mode enabled: For 4 MP stream access: 4 MP lite@15fps; 1080p lite / 720p lite / WD1 / 4CIF / VGA / CIF@25fps (P) / 30fps (N) For 3 MP stream access: 3 MP / 1080p lite / 720p lite / WD1 / 4CIF / VGA / CIF@15fps For 1080p stream access: 1080p lite / 720p lite / WD1 / 4CIF / VGA / CIF@25fps (P) / 30fps (N) For 720p stream access: 720p / WD1 / 4CIF / VGA / CIF@25fps (P) / 30fps (N) |
Sub-stream: WD1 / 4CIF@12fps; CIF@25fps (P) / 30fps (N) |
Video bit rate | 32 Kbps to 6 Mbps |
Dual stream | Support |
Stream type | Video, Video & Audio |
Audio compression | G.711u |
Audio bit rate | 64 Kbps |
Video and Audio |
IP video input | 16-ch (up to 48-ch) |
Up to 6 MP resolution |
Support H.265+ / H.265 / H.264+ / H.264 IP cameras |
Analog video input | 32-ch |
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
HDTVI input | 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60 *: The 3 MP signal input is only available for channel 1 / 2 / 3 / 4. |
AHD input | 4 MP, 1080p25, 1080p30, 720p25, 720p30 |
HDCVI input | 1080p25, 1080p30, 720p25, 720p30 |
CVBS input | PAL / NTSC |
CVBS output | 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
HDMI1 / VGA output | 1-ch, 1920 × 1080 / 60Hz, 1280 × 1024 / 60Hz, 1280 × 720 / 60Hz, 1024 × 768 / 60Hz |
HDMI2 output | 1-ch, 4K (3840 × 2160) / 30Hz, 2K (2560 × 1440) / 60Hz, 1920 × 1080 / 60Hz, 1280 × 1024 / 60Hz, 1280 × 720 / 60Hz, 1024 × 768 / 60Hz |
Audio input | 4-ch, RCA (2.0 Vp-p, 1 KΩ) |
Audio output | 1-ch, RCA (Linear, 1 KΩ) |
Two-way audio | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (independent) |
Synchronous playback | 16-ch |
Network |
Remote connections | 128 |
Network protocols | TCP / IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, SNMP |
Network interface | 1, RJ45 10M / 100M / 1000M self-adaptive Ethernet interface |
Auxiliary interface |
SATA | 4 SATA interfaces |
eSATA | Support |
Capacity | Up to 10 TB capacity for each disk |
Serial interface | RS-232, RS-485 (full-duplex), Keyboard |
Alarm in / out | 16 / 4 |
USB interface | Front panel: 2 × USB 2.0 Rear panel: 1 × USB 3.0 |
General |
Power supply | 100 to 240 VAC |
Consumption (without HDD) | ≤ 45 W |
Working temperature | -10 °C to +55 °C (+14 °F to +131 °F) |
Working humidity | 10% to 90% |
Dimensions (W × D × H) | 440 × 390 × 70 mm (17.3 × 15.4 × 2.8 inch) |
Weights (without HDD) | ≤ 7 kg (15.4 lb) |
