Camera
|
|
Sensor
|
1/1.8"
Progressive Scan CMOS
|
|
Max.
Resolution
|
1920
× 1080
|
|
Min.
Illumination
|
Color:
0.0005 Lux @ (F1.2, AGC ON); B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR
|
|
Shutter
Time
|
1 s
to 1/100,000 s
|
|
Day
& Night
|
IR cut
filter
Blue
glass module to reduce ghost phenomenon
|
|
Lens
|
|
Focal
Length & FOV
|
2.8
to 12 mm, horizontal FOV: 114.5° to 41.8°, vertical FOV: 59.3° to 23.6°, diagonal
FOV: 141.1° to 48°
|
|
Focus
|
Auto,
semi-auto, manual
|
|
Iris
Type
|
P-iris
|
|
Aperture
|
2.8
to 12 mm: F1.2 to F2.5
|
|
DORI
|
|
DORI
|
Wide:
2.8
to 12 mm: D: 45 m, O: 17.9 m, R: 9 m, I: 4.5 m
Tele:
2.8
to 12 mm: D: 111.8 m, O: 44.3 m, R: 22.4 m, I: 11.2 m
|
|
Illuminator
|
|
Supplement
Light Type
|
IR
|
|
Supplement
Light Range
|
2.8
to 12 mm: 50 m
|
|
Smart
Supplement Light
|
Yes
|
|
IR
Wavelength
|
850
nm
|
|
Video
|
|
Main
Stream
|
50 Hz:
50 fps (1920 × 1080, 1280 × 960, 1280× 720)
60 Hz:
60 fps (1920 × 1080, 1280 × 960, 1280× 720)
|
|
Sub-Stream
|
50 Hz:
25 fps (704 × 480, 640 × 480)
60 Hz:
30 fps (704 × 480, 640 × 480)
|
|
Third
Stream
|
50 Hz:
25 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
60 Hz:
30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
|
|
Fourth
Stream
|
50 Hz:
25 fps (704 × 480, 640 × 480)
60 Hz:
30 fps (704 × 480, 640 × 480)
|
|
Fifth
Stream
|
50 Hz:
25 fps (704 × 480, 640 × 480)
60 Hz:
30 fps (704 × 480, 640 × 480)
|
|
Video
Bit Rate
|
32 Kbps
to 16 Mbps
|
|
Video
Compression
|
Main
stream: H.265+ / H.265 / H.264+ / H.264,
Sub-stream:
H.265 / H.264 / MJPEG,
Third
stream: H.265 / H.264,
Fourth
stream: H.265 / H.264 / MJPEG, Fifth stream: H.265 / H.264 / MJPEG
|
|
H.264
Type
|
Main
Profile
|
|
H.265
Type
|
Baseline
Profile, Main Profile, High Profile
|
|
Bit
Rate Control
|
CBR,VBR
|
|
Scalable
Video Coding (SVC)
|
H.264
and H.265 encoding
|
|
Region
of Interest (ROI)
|
4 fixed
region(s) for each stream
|
|
Target
Cropping
|
Yes
|
|
Network
|
|
Protocols
|
TCP/IP,
ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP,
SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
|
|
User/Host
|
Up to
32 users
3 user
levels: administrator, operator, and user
|
|
Security
|
Password
protection, complicated password, HTTPS encryption, 802.1X authentication
(EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest
authentication for HTTP/HTTPS, WSSE and digest authentication for Open
Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings,
Security Audit Log, TLS 1.2
|
|
Network
Storage
|
NAS
(NFS, SMB/CIFS), auto network replenishment (ANR)
Together
with high-end Hikvision memory card, memory card encryption and health
detection are supported.
|
|
|
|
Parameters Switch
|
Yes
|
|
Settings
|
Saturation,
brightness, contrast, sharpness, white balance, and AGC adjustable by client software
or web browser
|
|
Day/Night
Switch
|
Day,
Night, Auto, Schedule, Alarm Trigger
|
|
Wide
Dynamic Range (WDR)
|
140
dB
|
|
SNR
|
≥ 52 dB
|
|
Enhancement
|
BLC,
HLC, Defog, 3D DNR
|
|
Privacy
Mask
|
8 programmable
polygon privacy masks, mask color or mosaic configurable
|
|
Stabilization
|
EIS
|
|
Overlay
|
LOGO
picture can be overlaid on video with 128 × 128 24bit bmp format
|
|
Interface
|
|
Video
Output
|
1 Vp-p
Composite Output (75 Ω/CVBS) (Only for debugging)
|
|
Ethernet
Interface
|
1 RJ45
10 M/100 M/1000 M self-adaptive Ethernet port
|
|
On-Board
Storage
|
Built-in
memory card slot, support microSD / microSDHC / microSDXC card, up to 1 TB
|
|
Reset
Key
|
Yes
|
|
Power
Output
|
With
-Y: 12 VDC, max. 100 mA
|
|
Event
|
|
|
Basic
Event
|
Motion
detection, video tampering alarm, exception (network disconnected, IP address
conflict, illegal login, abnormal reboot, HDD full, HDD error), video quality
diagnosis, vibration detection
|
|
Linkage
|
Upload
to FTP / NAS / memory card, notify surveillance center, send email, trigger alarm
output, trigger recording, trigger capture, audible warning
|
|
Smart
Event
|
Line
crossing detection, intrusion detection, region entrance detection, region exiting
detection, audio exception detection, scene change detection, defocus detection
|
|
Deep Learning Function
|
|
Multi-target-type
Detection
|
Supports
simultaneous detection and capture of human body, face and vehicle
Gets 7 face features, 13 human body features and 2 vehicle features
|
|
Face
Capture
|
Detects
up to 60 faces simultaneously
Supports
swing left and right from -60° to 60°, tilt up and down from -30° to 30°
Uploads face with background and closed-up face pictures
|
|
Face
Comparison
|
Up to
10 face libraries. Up to 30,000 faces for each library. 150,000 faces in total.
Supports
face library encryption
|
|
Perimeter
Protection
|
Line
crossing, intrusion, region entrance, region exiting
Support
alarm triggering by specified target types (human and vehicle)
|
|
People
Counting
|
Supports
crossline people counting,
Supports
counting, displaying and exporting the people flow data of entering and
exiting. (The data is stored in the flash.),
The
real-time people flow data is displayed on the screen,
Supports
swing left and right from -60° to 60°, tilt up and down from -30° to 30°.,
Uploads face with background and closed-up face picture.,
Supports
real-time uploading and uploading by statistic cycle
|
|
Queue
Management
|
Supports
up to 8 detection regions, and independent arming schedule and linkage method
Supports
2 detection modes: regional people queuing-up, waiting time detection
Generates reports to compare the efficiency of different queuing-ups and display
the changing status of one queue
Supports
raw data export for further analysis.
Supports
real-time data uploading and scheduled data uploading
Regional
people queuing-up: supports 4 alarm trigger conditions, including greater
than threshold, less than threshold, equal to threshold, not equal to
threshold Waiting time detection: supports 1 alarm trigger condition,
including greater than threshold
|
|
Heat
Map
|
A graphic
description of visits (by calculating amount of people or amount of dwell
time) in a configured area., Two report types are available, space heat map and
time heat map line chart.
|
|
Hard
Hat Detection
|
Detects
up to 30 human targets simultaneously
Supports
up to 4 shield regions
|
|
Metadata
|
Intrusion
detection, line crossing detection, region entrance detection, region exiting
detection, face capture, multi-target-type detection
|
|
Regional
People Counting
|
Supports
up to 8 detection regions, and independent arming schedule and linkage method
Supports
3 detection modes: people density detection, number of people exception
detection, waiting time exception detection
Supports
parameter settings: alarm times per exception, alarm interval, first alarm delay
Supports
searching real-time number of people
People
density detection: supports scheduled uploading, number of people change
uploading, congestion level uploading
Number
of people exception detection: supports 6 alarm trigger conditions, including
greater than threshold A, less than threshold A, equal to threshold A, not
equal to threshold A, greater than threshold A and less than threshold B, less
than threshold A or greater than threshold B (threshold A should be less than
threshold B)
Waiting
time exception detection: supports 3 alarm trigger conditions, including
greater
than threshold A, less than threshold A, greater than threshold A and less than
threshold B (threshold A should be less than threshold B)
|
|
On/Off
Duty Detection
|
Supports
up to 8 detection regions, and independent arming schedule and linkage method
Supports
2 detection modes: absence detection, on/off duty detection
Supports
parameter settings: person on duty, absence duration
|
|
General
|
|
Power
|
12 VDC
± 20%, three-core terminal block, 1.19 A, max. 14.28 W
PoE:
802.3at, Type 2, Class 4, 42.5 V to 57 V), 0.396 A to 0. 295 A, max. 16.8 W
|
|
Material
|
Aluminum
alloy body
|
|
Dimension
|
Without
-Y: Ø144 × 347 mm (Ø5.7" × 13.7")
With
-Y: Ø140 × 351 mm (Ø5.5" × 13.8")
|
|
Package
Dimension
|
405
× 190 × 180 mm (15.9" × 7.5" × 7.1")
|
|
Weight
|
Approx.
1950 g (4.2 lb.)
|
|
With
Package Weight
|
Approx.
3070 g (6.7 lb.)
|
|
Startup
and Operating Conditions
|
-40
°C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Storage
Conditions
|
-30
°C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
General
Function
|
Heartbeat,
mirror, password protection, watermark, privacy mask, IP address filter,
one-key
reset, five streams
|
|
Heater
|
Yes
|
|
Approval
|
|
EMC
|
FCC
(47 CFR Part 15, Subpart B);
CE-EMC
(EN 55032: 2015, EN 61000-3-2:2019, EEN 61000-3-3:2013+A1:2019, EN
50130-4:
2011 +A1: 2014);
RCM
(AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 7);
KC (KN
32: 2015, KN 35: 2015)
|
|
Safety
|
UL (UL
62368-1);
CB (IEC
62368-1:2014+A11);
CE-LVD
(EN 62368-1:2014/A11:2017);
BIS
(IS 13252(Part 1):2010/ IEC 60950-1 : 2005); LOA (IEC/EN 60950-1)
|
|
Environment
|
CE-RoHS
(2011/65/EU); WEEE (2012/19/EU);
Reach
(Regulation (EC) No 1907/2006)
|
|
Protection
|
IK10
(IEC 62262:2002), IP67 (IEC 60529-2013)
|
|
Automotive
and Railway
|
EN50121-4
|
|
Other
|
PVC
FREE
|
