Thermal
Imaging
|
|
Sensor
|
Vanadium oxide uncooled
sensor
|
|
Max. Resolution
|
160× 120
|
|
Pixel Interval
|
17μm
|
|
Response Waveband
|
8 to 14μm
|
|
NETD
|
≤ 40mk (@25°C,F#=1.0)
|
|
Lens (Focal Length)
|
3mm
|
|
MRAD
|
9.44
|
|
Field of View
|
50°×37.2°
|
|
Min. Focusing Distance
|
0.5m
|
|
Aperture
|
1.1
|
|
Pseudo Color
|
15, white heat, black heat,fusion1,
rainbow, fusion2, iron oxide red1, iron oxide red2, puce, color1, color2, ice
& fire, rain, red heat, green heat, and dark blue
|
|
Visible
Light
|
|
Sensor
|
4 MP 1/2.7"
Progressive Scan CMOS
|
|
Resolution
|
2688×1520@25fps
|
|
Min. illuminance
|
0.0018Lux @ (F1.6,AGC ON)
,0 Lux with IR
|
|
Shutter speed
|
1/3s to 1/100,000s
|
|
Focal length
|
4mm
|
|
Field angle
|
84.0°×44.8°
|
|
Day/Night switch
|
ICR
|
|
WDR range
|
120dB
|
|
IR distance
|
Max. 15 m
|
|
frame
|
|
Thermal imaging and visible
light
|
Thermal imaging integrated
with visible light frame
|
|
Picture in picture
|
Supports visible light and
thermal imaging frame over lay
|
|
Smart information overlay
|
Supports (only temperature
measurement rule and temperature are supported)
|
|
Smart function
|
|
|
Linkage alarm
|
Linkage of strobe light and
audible alarm
|
|
Temperature
measurement
|
|
Temperature exception
detection
|
Expert mode: 10 pints, 10
frame, 21 rules on each line
|
|
Body temperature
measurement
|
AI face detection,
multi-target detection
|
|
Measurement range
|
30 to 45℃
|
|
Temperature Alarm
|
Alarm triggered when the
temperature is over the threshold
|
|
Measurement accuracy
|
No black body: ±0.5℃
With black body: ±0.3℃
|
|
Compression
|
|
Video compression
|
H.265 / H.264 / MJPEG
|
|
H265:
|
Main Profile
|
|
H264:
|
Baseline Profile / Main
Profile / High Profile
|
|
Video bit rate
|
32 Kbps to 8Mbps
|
|
Video standard
|
G.711 / G.722.1 / G.726 / MP2L2
/ PCM
|
|
Audio bit rate
|
64Kbps(G.711) /
16Kbps(G.722.1) / 16Kbps(G.726) / 32-192Kbps(MP2L2)
|
|
Storage
|
|
SD card storage
|
Micro SD / Micro SDHC / Micro
SDXC card (128GB or 256GB)
|
|
NVR storage
|
(96/86/77/76) I series NVR
Supports live view / playback,
rule display, alarm report, and remote configuration
|
|
Network
|
|
Main
stream
|
Visible light: 50Hz: 25fps
(1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720)
Visible light: 60Hz: 30fps
(1920 × 1080), 30fps (1280 × 960), 30fps (1280 × 720)
Thermal Imaging: 25fps (160
× 120 (output320 × 240))
|
|
Sub stream
|
Visible light: 50Hz: 25fps
(704 × 576), 25fps (640 × 480)
Visible light: 60Hz: 30fps
(704 × 480), 30fps (640 × 480)
Thermal Imaging: 25fps (160
× 120 (output 320 × 240))
|
|
Network protocol
|
IPv4/IPv6, HTTP, HTTPS, 802.1x,
Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP,
DHCP, PPPoE, Bonjour
|
|
Interface protocol
|
ONVIF(PROFILE S, PROFILE G),
ISAPI, SDK, Ehome, GB28181
|
|
Max. live view channel
number
|
20
|
|
User
|
Three level: administrator,
operator, general user
|
|
Safety strategy
|
User and password
authentication, HTTPS encryption, IEEE 802.1x control, IP address filtering
|
|
Interface
|
|
Alarm input
|
1, 0 to 5 V alarm input
|
|
Alarm output
|
1, NO relay output, alarm
type configurable
|
|
Audio input
|
1, 3.5mm Mic in/Line in
interface. Line input: 2-2.4V[p-p]
|
|
Audio output
|
1, 600Ω
|
|
Reset button
|
1
|
|
Network interface
|
1,RJ45 10/100M
self-adaption
|
|
RS-485 interface
|
1
|
|
SD card slot
|
1
|
|
Client
|
iVMS-4200 / HIK-CONNCET
|
|
General
|
|
Power supply
|
110~240VAC，50-60Hz
|
|
Consumption
|
<72W
|
|
Operation temperature and humidity
|
Speed dome: 5℃ to 40℃, ＜95%
RH
Walk-through detector: -20℃ to 85℃, 99%, RH
|
|
Protective level
|
Dome camera: IP66
Walk-through detector: IP53
|
|
Dimension
|
|
Detector dimension(without
dome camera)
|
2200 x 850 x 480mm (H x W x
D)
|
|
Dome camera dimension
|
138.3 mm × 138.3 mm × 123.1
mm(H x W x D)
|
|
Package dimension
|
2270 x 700 x230mm(H x W x
D)
|
|
Weight
|
|
Net weight
|
About 50Kg
|
