Possible-to-speak indication
A white possible‑to‑speak indicator above the
microphone button indicates when the microphone
can be activated.
Long microphone with flexible stem
The fixed microphone with flexible stem can be
easily adjusted to suit the user. For maximum
comfort, a long 480 mm
(18.9 in) microphone stem is available.
GSM immunity
Immunity to mobile phone interference ensures
clear, uninterrupted discussion.
Built-in loudspeaker with volume control
To ensure for optimum intelligibility, the loudspeaker
volume of all Discussion Devices is centrally
controlled from the Control Unit.
Face-to-face meeting feeling
An authentic face‑to‑face meeting feeling is achieved
by allowing the loudspeaker and microphone to be
on at the same time.
Controls and indicators
Microphone button, Color-coded LED indicator above the microphone button that shows the states microphone on and possible‑to‑speak.
Technical Specifications
|
Power consumption (W) |
1.50 W |
|
Frequency response (Hz) |
30Hz - 20,000 Hz |
|
Total harmonic distortion + noise (%) |
< 2% |
|
Minimum signal-to-noise ratio (dBA) |
> 75 dBA |
|
Sample rate (kHz) |
44.10 kHz |
|
Maximum number of flush discussion devices supported per trunk |
35 |
|
Nominal acoustic output level (dB SPL) (loudspeaker) |
72 dB SPL |
|
Nominal acoustic input level (dB SPL) (microphone) |
85 dB SPL |
|
Frequency response (Hz) (participants’ loudspeaker) |
200 Hz – 16,000 Hz |
|
Frequency response (Hz) (participants’ microphone) |
125 Hz ‒ 15,000 Hz |
|
Polar pattern (microphone) |
Cardioid |
|
Dimensions (H x W x D) (mm) (excluding microphone) |
63 mm x 173 mm x 92 mm |
|
Dimensions (H x W x D) (in) (excluding microphone) |
2.48 in x 6.81 in x 3.62 in |
|
Thickness (mm) |
3 mm |
|
Thickness (in) |
0.12 in |
|
Maximum table thickness (mm) |
40 mm |
|
Maximum table thickness (in) |
1.57 in |
|
Microphone stem length (mm) |
480 mm |
|
Microphone stem length (in) |
18.90 in |
|
Mounting type |
Flush-mounted
|
|
Material |
Plastic ABS+PC |
|
Color (RAL) |
RAL 9017 Traffic black |
|
Connector type |
6-pin Connector male |
|
Cable length (m) |
2 m |
|
Cable length (ft) |
6.56 ft |
|
Weight (g) |
560 g |
|
Weight (lb) |
1.23 lb |
|
Operating temperature (°C) |
0 °C – 35 °C |
|
Operating temperature (°F) |
32 °F – 95 °F |
|
Storage temperature (°C) |
-40 °C – 70 °C |
|
Storage temperature (°F) |
-40 °F – 158 °F |
|
Operating relative humidity, noncondensing (%) |
95% |
|
Air pressure (hPa) |
600 hPa – 1,100 hPa |
