DS-1600KI

DS-1600KI

Hikvision DS-1600KI Network Keyboard (Detachable 10.1" capacitive touchscreen and joystick), Wired and Wi-Fi network connection, POE power supply, Capable of decoding 2-ch at 1080P decoding, Live view on touch panel, DVI and HDMI output to monitor, Access to Hikvision products including DVR, DVS, NVR, network camera, speed dome, etc., PTZ control, setting and calling preset, patrol and pattern, USB 2.0 × 2, 12V DC /POE.

DS-1600KI is the new generation of fully touch-enabled and detachable network keyboard independently developed by Hikvision. In addition to displaying images, the 10.1" capacitive touchscreen supports DVI and HDMI video output. It runs on Android and has the brand-new UI interaction design. It also supports all series of front-end and back-end devices of Hikvision, as well as control centre devices such as video management platform (VMS). It has open settings of the monitoring point number, and users can arrange the numbers freely as needed. In application, users can call the numbers quickly to display the video on the video wall, or output videos to the touchscreen or external displays. It supports recording, picture capturing and two-way audio, as well as the screen control and scene switch of VMS and decoding device. The 4-axis joystick can be used to the PTZ control to locate the target quickly. The joystick panel is detachable for the convenience of user operation. This keyboard can be widely used in public security and finance and other fields.

Model

DS-1600KI(B)

TFT LCD Screen

10.1" TFT LCD touchscreen

Resolution: 1280 × 800

Joystick

4-axis joystick

Local Decoding

Local live view at 1080P / 720P / HD1 resolution, and up to 16-division window display

Two-way Audio Input

1-ch, 3.5mm connector (2.0Vp-p, >1kΩ)

Audio Output

1-ch, 3.5mm connector (2.0 Vp-p, 600 Ω)

Network Interface

10M/100M/1000M Adaptive Ethernet port

WiFi

Supported

USB Interface

USB 2.0 × 2

Video Interface

HDMI, DVI

Power Supply

12V DC /POE

Consumption

15W

Working Temperature

-10°C --55°C

Working Humidity

10--90

Dimensions (W × D × H)

404 × 180 × 163 mm

Weight

1.7 Kg
