Camera
|
|
Image Sensor
|
1/2.8" progressive
scan CMOS
|
|
Min. Illumination
|
Color: 0.01 Lux @(F1.2, AGC
ON), 0.028Lux @ (F2.0, AGC ON)
|
|
Shutter Speed
|
1/3 s to 1/100, 000 s
|
|
Slow Shutter
|
Yes
|
|
Auto-Iris
|
No
|
|
Day & Night
|
IR cut filter
|
|
Digital Noise Reduction
|
3D DNR
|
|
WDR
|
DWDR
|
|
Angle Adjustment (Bracket)
|
Pan: 0° to 360°, tilt: 0°
to 180°, rotation: 0° to 360°
|
|
Lens
|
|
Focal length
|
4 mm
|
|
Aperture
|
F2.0
|
|
Focus
|
Fixed
|
|
FOV
|
4 mm: horizontal FOV 86°, vertical
FOV 46.5°, diagonal FOV 102.5°
|
|
Lens Mount
|
M12
|
|
IR
|
|
IR Range
|
Up to 30 m
|
|
Wavelength
|
850 nm
|
|
Compression
Standard
|
|
Video Compression
|
Main stream: H.265/H.264
Sub stream:
H.265/H.264/MJPEG
|
|
H.264 Type
|
Main Profile/High
Profile/Baseline Profile
|
|
H.265 Type
|
Main Profile
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
Smart
Feature-set
|
|
Region of Interest
|
1 fixed region for main
stream
|
|
|
|
Max. Resolution
|
1920 × 1080
|
|
Main Stream
Max. Frame Rate
|
50Hz: 25fps (1920 × 1080,
1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080,
1280 × 960, 1280 × 720)
|
|
Sub-stream
Max. Frame Rate
|
50Hz: 25fps (640 × 480, 640
× 360, 320 × 240)
60Hz: 30fps (640 × 480, 640
× 360, 320 × 240)
|
|
Image Enhancement
|
BLC, 3D DNR
|
|
Image Settings
|
Saturation, brightness,
contrast, sharpness, AGC, white balance adjustable by client software or web
browser
|
|
Day/Night Switch
|
Auto, scheduled, day, night
|
|
Network
|
|
Alarm Trigger
|
Motion detection, video
tampering alarm, illegal login
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS,
DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP
|
|
General Function
|
Anti-flicker, heartbeat,
mirror, password protection, privacy mask, watermark
|
|
Firmware Version
|
V5.5.70
|
|
API
|
ONVIF (PROFILES), ISAPI
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
User/Host
|
Up to 32 users
3 levels: Administrator,
Operator, and User
|
