Camera |
Image Sensor | 1/3" progressive scan CMOS |
Min. Illumination | Color: 0.01 Lux @(F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON) |
Shutter Speed | 1/3 s to 1/100, 000 s |
Slow Shutter | Yes |
Auto-Iris | No |
Day &Night | IR cut filter |
DNR (Digital Noise Reduction) | 3D DNR |
WDR (Wide Dynamic Range) | 120 dB |
Angle Adjustment (Bracket) | Pan: 0° to 360°, tilt: 0° to 180°, rotation: 0° to 360° |
Lens |
Focal Length | 4 mm |
Aperture | F2.0 |
Focus | No |
FOV | 4 mm, horizontal FOV 77°, vertical FOV 42°, diagonal FOV 88° |
Lens Mount | M12 |
IR |
IR Range | Up to 30 m |
Wavelength | 850 nm |
Compression Standard |
Video Compression | Main stream: H.265 / H.264 Sub stream: H.265 / H.264 / MJPEG |
H.264 Type | Baseline Profile / Main Profile / High Profile |
H.264+ | Main stream supports |
H.265 Type | Main Profile |
H.265+ | Main stream supports |
Video Bit Rate | 32 Kbps to 8 Mbps |
Smart Feature-set |
Region of Interest | 1 fixed region for main stream and sub-stream |
Image |
Max. Resolution | 2560 × 1440 |
Main Stream Max. Frame Rate | 50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720) |
Sub-stream Max. Frame Rate | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
Image Enhancement | BLC, 3D DNR |
Image Settings | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
Day/Night Switch | Auto, scheduled |
Network |
Network Storage | NAS (NFS, SMB/CIFS) |
Alarm Trigger | Motion detection, video tampering alarm, illegal login |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 UDP, Bonjour |
General Function | Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
Firmware Version | 5.5.3 |
API | ONVIF (PROFILE S, PROFILE G), ISAPI |
Simultaneous Live View | Up to 6 channels |
User/Host | Up to 32 users 3 levels: Administrator, Operator, and User |
Client | iVMS-4200, Hik-Connect, iVMS-5200 |
Web Browser | IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+ |
Interface |
Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
General |
Operating Conditions | -30 °C to 50 °C (-22 °F to 122 °F), humidity: 95% or less (non-condensing) |
Power Supply | 12 VDC ± 25%, 5.5 mm coaxial power plug PoE (802.3af, class 3) |
Power Consumption and Current | 12 VDC, 0.4 A, Max: 5 W PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.13 A, Max: 7 W |
Protection Level | IP67 TVS 2000V lightning protection, surge protection and voltage transient protection |
Material | Metal & Plastic |
Dimensions | Camera: Ø 70 mm × 172.7mm (2.7" × 6.8") With package: 216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6") |
Weight | Camera: approx. 280 g (0.62 lb.) With package: approx.: 530 g (1.17 lb.) |
