Camera
|
|
|
Image Sensor
|
1/2.4" Progressive Scan CMOS
|
|
|
Max. Resolution
|
3200 × 1800
|
|
|
Shutter Time
|
1/3 s to 1/100,000 s
|
|
|
Min. Illumination
|
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
|
|
|
Day & Night
|
IR cut filter
|
|
|
Angle Adjustment
|
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
|
|
|
Lens
|
|
|
Lens Type
|
Fixed focal lens, 2.8 and 4 mm optional
|
|
|
Focal Length & FOV
|
4 mm, horizontal FOV 78°, vertical FOV 38°, diagonal FOV 96°
|
|
|
Lens Mount
|
M12
|
|
|
Iris Type
|
Fixed
|
|
|
Aperture
|
F1.6
|
|
|
DORI
|
|
|
DORI
|
4 mm, D: 115 m, O: 45 m, R: 23 m, I: 11 m
|
|
|
Illuminator
|
|
|
Supplement Light Type
|
IR, White Light
|
|
|
Supplement Light Range
|
Up to 30 m
|
|
|
Smart Supplement Light
|
Yes
|
|
|
IR Wavelength
|
850 nm
|
|
|
Video
|
|
|
Main Stream
|
50 Hz:
20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
|
|
|
Sub-Stream
|
50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
|
|
|
Video Compression
|
Main stream: H.265+ / H.265 / H.264+ / H.264,
Sub-stream: H.265 / H.264 / MJPEG
|
|
|
Video Bit Rate
|
32 Kbps to 16 Mbps
|
|
|
H.264 Type
|
Baseline Profile, Main Profile, High Profile
|
|
|
H.265 Type
|
Main Profile
|
|
|
Bit Rate Control
|
CBR, VBR
|
|
|
Scalable Video Coding (SVC)
|
H.264 and H.265 encoding
|
|
|
Region of Interest (ROI)
|
1 fixed region for main stream
|
|
|
Audio
|
|
|
Audio Type
|
Mono sound
|
|
|
Audio Sampling Rate
|
8 kHz/16 kHz
|
|
|
Environment Noise Filtering
|
Yes
|
|
|
Audio Compression
|
G.711 / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC
|
|
|
Audio Bit Rate
|
64 Kbps (G.711ulaw / G.711alaw) / 16 Kbps (G.722.1) / 16 Kbps
(G.726) / 32 to 160 Kbps (MP2L2) / 16 to 64 Kbps (AAC-LC)
|
|
Network
|
|
Security
|
Password protection, complicated password, watermark, basic
and digest authentication for HTTP, WSSE and digest authentication for Open
Network Video Interface, security audit log, host authentication (MAC
address)
|
|
Protocols
|
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6,
UDP, QoS, FTP, SMTP, UPnP
|
|
User/Host
|
Up to 32 users
3 user levels: administrator, operator, and user
|
|
|
|
Wide Dynamic Range (WDR)
|
120 dB
|
|
SNR
|
≥ 52 dB
|
|
Day/Night Switch
|
Day, Night, Auto, Schedule
|
|
Image Enhancement
|
BLC, HLC, 3D DNR
|
|
Image Settings
|
Rotate mode, saturation, brightness, contrast, sharpness,
gain, white balance, adjustable by client software or web browser
|
|
Privacy Mask
|
4 programmable polygon privacy masks
|
|
Interface
|
|
Ethernet Interface
|
1 RJ45 10 M/100 M self-adaptive Ethernet port
|
|
On-Board Storage
|
Built-in memory card slot, support microSD / microSDHC / microSDXC
card, up to 512 GB
|
|
Built-in Microphone
|
Yes, 1 built-in microphone
|
|
Built-in Speaker
|
Max. power consumption: 1.5 W, max. sound pressure level: 10
cm: 95 dB.
|
|
Reset Key
|
Yes
|
|
Event
|
|
Basic Event
|
Motion detection (support alarm triggering by specified target
types (human and vehicle)), video tampering alarm, exception
|
|
Linkage
|
Upload to FTP / NAS / memory card, notify surveillance center,
send email, trigger recording, trigger capture, audible warning, flashing
light
|
|
General
|
|
Power
|
12 VDC ± 25%, 0.66 A, max. 8 W, Ø5.5 mm coaxial power plug,
reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 9.5 W
|
|
Material
|
Metal & Plastic
|
|
Dimension
|
179 mm × 67.4 mm × 69.1 mm (7.1" × 2.7" × 2.7")
|
|
Package Dimension
|
216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6")
|
|
Weight
|
Approx. 285 g (0.6 lb.)
|
|
Flashing Light
|
Yes
|
