Camera |
Image Sensor | 1/2.7" Progressive Scan CMOS |
Max. Resolution | 3840 × 2160 |
Shutter Time | 1/3 s to 1/100,000 s |
Min. Illumination | Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR |
Day & Night | IR cut filter |
Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
Lens |
Lens Type | Fixed focal lens, 4 mm |
Focal Length & FOV | 4 mm, horizontal FOV 90°, vertical FOV 49°, diagonal FOV 108° |
Lens Mount | M12 |
Iris Type | Fixed |
Aperture | F2.0 |
DORI |
DORI | 4 mm, D: 102 m, O: 40 m, R: 20 m, I: 10 m |
Illuminator |
Supplement Light Type | IR, White Light |
Supplement Light Range | Up to 30 m |
Smart Supplement Light | Yes |
IR Wavelength | 850 nm |
Video |
Main Stream | 50 Hz: 12.5 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 15 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
Sub-Stream | 50 Hz: 12.5 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 15 fps (1280 × 720, 640 × 480, 640 × 360) |
Video Compression | Main stream: H.265+ / H.265 / H.264+ / H.264, Sub-stream: H.265 / H.264 / MJPEG |
Video Bit Rate | 32 Kbps to 16 Mbps |
H.264 Type | Baseline Profile, Main Profile, High Profile |
H.265 Type | Main Profile |
Bit Rate Control | CBR, VBR |
Region of Interest (ROI) | 1 fixed region for main stream |
Scalable Video Coding (SVC) | H.264 and H.265 encoding |
Audio |
Audio Type | Mono sound |
Audio Sampling Rate | 8 kHz/16 kHz |
Environment Noise Filtering | Yes |
Audio Compression | G.711 / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC |
Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32 to 160 Kbps (MP2L2) / 16 to 64 Kbps (AAC-LC) |
Network |
Security | Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) |
API | Open Network Video Interface (Profile S, Profile T, Profile G), ISAPI, SDK |
Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP |
User/Host | Up to 32 users 3 user levels: administrator, operator, and user |
Image |
Wide Dynamic Range (WDR) | 120 dB |
SNR | ≥ 52 dB |
Day/Night Switch | Day, Night, Auto, Schedule |
Image Enhancement | BLC, HLC, 3D DNR |
Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
Privacy Mask | 4 programmable polygon privacy masks |
Interface |
Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
On-Board Storage | Built-in memory card slot, support microSD / microSDHC / microSDXC card, up to 512 GB |
Built-in Microphone | Yes, 1 built-in microphone |
Built-in Speaker | Max. power consumption: 1.5 W, max. sound pressure level: 10 cm: 95 dB. |
Reset Key | Yes |
Event |
Basic Event | Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception |
Linkage | Upload to FTP / NAS / memory card, notify surveillance center, send email, trigger recording, trigger capture, audible warning, flashing light |
General |
Power | 12 VDC ± 25%, 0.66 A, max. 8 W, Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 9.5 W |
Material | Metal & Plastic |
Dimension | 179 mm × 67.4 mm × 69.1 mm (7.1" × 2.7" × 2.7") |
Package Dimension | 216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6") |
Weight | Approx. 285 g (0.6 lb.) |
With Package Weight | Approx. 490 g (1.1 lb.) |
General Function | Heartbeat, anti-banding, mirror, password protection, password reset via email |
Flashing Light | Yes |
Approval |
EMC | CE-EMC: EN 55032: 2015+A1: 2020, EN 50130-4: 2011+A1: 2014, EN IEC 61000-3-2: 2019+A1: 2021, EN 61000-3-3: 2013+A1: 2019+A2: 2021, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7 |
Safety | UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005 |
Environment | CE-RoHS: 2011 / 65 / EU, WEEE: 2012 / 19 / EU, Reach: Regulation (EC) No 1907 / 2006 |
Protection | IP67: IEC 60529-2013 |
