Camera |
Image Sensor | 1/2.8" progressive scan CMOS |
Min. Illumination | Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @ (F2.0, AGC ON) |
Shutter Speed | 1/3 s to 1/100, 000 s |
Slow Shutter | Yes |
Auto-Iris | No |
Day &Night | IR cut filter |
Digital Noise Reduction | 3D DNR |
WDR | 120dB WDR |
Angle Adjustment | Pan: 0° to 355°, tilt: 0° to 70°, rotate: 0° to 355° |
Lens |
Focal length | 2.8 mm |
Aperture | F2.0 |
Focus | Fixed |
FOV | 2.8 mm, horizontal FOV 100°, vertical FOV 55°, diagonal FOV 117° |
Lens Mount | M12 |
IR |
IR Range | Up to 30 m |
Wavelength | 850 nm |
Compression Standard |
Video Compression | Main stream: H.265 / H.264 Sub stream: H.265 / H.264 / MJPEG |
H.264 Type | Main Profile / High Profile / Baseline Profile |
H.265 Type | Main Profile |
Video Bit Rate | 32 Kbps to 8 Mbps |
Smart Feature-set |
Region of Interest | 1 fixed region for main stream |
Behavior Analysis | Line crossing detection, intrusion detection |
Image |
Max. Resolution | 2560 × 1440 |
Main Stream Max. Frame Rate | 50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720) |
Sub-stream Max. Frame Rate | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
Image Enhancement | BLC, 3D DNR |
Image Setting | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
Day/Night Switch | Auto, scheduled, day, night |
Network |
Alarm Trigger | Motion detection, video tampering alarm, illegal login |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP |
General Function | Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark |
API | ONVIF (PROFILE S), ISAPI |
Simultaneous Live View | Up to 6 channels |
User/Host | Up to 32 users 3 levels: Administrator, Operator, and User |
Client | iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500 |
Interface |
Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
General |
Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing) |
Power Supply | 12 VDC ± 25%, 5.5 mm coaxial power plug PoE (802.3af, class 3) |
Power Consumption and Current | 12 VDC, 0.4 A, Max: 5 W PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, Max: 6.5 W |
Ingress Protection | IP67, IK10 |
Material | Front cover: plastic, back cover & bracket: metal |
Dimensions | Camera: Ø 111 mm × 82.4 mm (4.4" × 3.2") With package: 134 mm × 134 mm × 108 mm (5.3" × 5.3" × 4.3") |
