Camera
|
|
Sensor
|
1/2.9"
Progressive Scan CMOS
|
|
Max.
Resolution
|
1920
× 1080
|
|
Min.
Illumination
|
Color:
0.01 Lux @ (F2.2, AGC ON), B/W: 0 Lux with IR
|
|
Shutter
Time
|
1/3
s to 1/100,000 s
|
|
Day
& Night
|
IR
cut filter
|
|
Angle
Adjustment
|
Pan:
0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
|
|
Lens
|
|
Lens
Type
|
Fixed
focal lens, 2.8
|
|
Focal
Length & FOV
|
2.8
mm, horizontal FOV 101°, vertical FOV 56°, diagonal FOV 118°
|
|
Lens
Mount
|
M12
|
|
Iris
Type
|
Fixed
|
|
Aperture
|
F2.2
|
|
DORI
|
|
DORI
|
2.8
mm, D: 44 m, O: 17 m, R: 8 m, I: 4 m
|
|
Illuminator
|
|
Supplement
Light Type
|
IR,
White Light
|
|
Supplement
Light Range
|
Up
to 20 m
|
|
Smart
Supplement Light
|
Yes
|
|
IR
Wavelength
|
850
nm
|
|
Video
|
|
Main
Stream
|
50
Hz: 25 fps (1920 × 1080, 1280 × 720)
60
Hz: 30 fps (1920 × 1080, 1280 × 720)
|
|
Sub-Stream
|
50
Hz: 25 fps (640 × 480, 640 × 360)
60
Hz: 30 fps (640 × 480, 640 × 360)
|
|
Video
Compression
|
Main
stream: H.265+ / H.265 / H.264+ / H.264,
Sub-stream:
H.265 / H.264 / MJPEG
|
|
Video
Bit Rate
|
32
Kbps to 8 Mbps
|
|
H.264
Type
|
Baseline
Profile, Main Profile, High Profile
|
|
H.265
Type
|
Main
Profile
|
|
Bit
Rate Control
|
CBR,
VBR
|
|
Audio
|
|
Audio
Type
|
Mono
sound
|
|
Environment
Noise Filtering
|
Yes
|
|
Audio
Sampling Rate
|
8
kHz/16 kHz
|
|
Audio
Compression
|
G.711ulaw/AAC-LC
|
|
Audio
Bit Rate
|
64
Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC)
|
|
Network
|
|
Security
|
Password
protection, complicated password, watermark, basic and digest authentication
for HTTP, security audit log, host authentication (MAC address)
|
|
API
|
Open
Network Video Interface (Profile S, Profile T), ISAPI, SDK
|
|
Protocols
|
TCP/IP,
ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, IPv4, IPv6, UDP, QoS, SMTP
|
|
|
|
Wide
Dynamic Range (WDR)
|
Digital
WDR
|
|
SNR
|
≥ 52 dB
|
|
Privacy
Mask
|
1
programmable polygon privacy mask
|
|
Day/Night
Switch
|
Day,
Night, Auto, Schedule
|
|
Enhancement
|
BLC,
HLC, 3D DNR
|
|
Settings
|
Saturation,
brightness, contrast, sharpness, gain, white balance, adjustable by client
software or web browser
|
|
Interface
|
|
Ethernet
Interface
|
1
RJ45 10 M/100 M self-adaptive Ethernet port
|
|
Built-in
Microphone
|
Yes,
1 built-in microphone
|
|
Event
|
|
Basic
Event
|
Motion
detection (support alarm triggering by specified target type (human)),
exception
|
|
Linkage
|
Notify
surveillance center, send email, trigger capture
|
|
General
|
|
Power
|
12
VDC ± 25%, 0.41 A, max. 5 W, Ø5.5 mm coaxial power plug, reverse polarity
protection,
PoE:
IEEE 802.3af, Class 3, max. 6.5 W
|
|
Material
|
Plastic
|
|
Dimension
|
Ø109.9
mm × 103.6 mm (Ø4.3" × 4.1")
|
|
Package
Dimension
|
134
mm × 134 mm × 108 mm (5.3" × 5.3" × 4.3")
|
|
Weight
|
Approx.
300 g (0.7 lb.)
|
|
With
Package Weight
|
Approx.
460 g (1.0 lb.)
|
|
Approval
|
|
EMC
|
FCC:
47 CFR Part 15, Subpart B,
CE-EMC:
EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4:
2011 +A1: 2014
|
|
Safety
|
CB:
IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017
|
|
Environment
|
CE-RoHS:
2011/65/EU, WEEE: 2012/19/EU,
Reach:
Regulation (EC) No 1907/2006
|
|
Protection
|
IP67:
IEC 60529-2013
|
