Camera
|
|
Image Sensor
|
1/3" progressive scan
CMOS
|
|
Min. Illumination
|
Color: 0.01 Lux @(F1.2, AGC
ON), 0.028Lux @ (F2.0, AGC ON)
|
|
Shutter Speed
|
1/3 s to 1/100, 000 s,
support slow shutter
|
|
Slow Shutter
|
Yes
|
|
Auto-Iris
|
No
|
|
Day &Night
|
IR cut filter
|
|
Digital Noise Reduction
|
3D DNR
|
|
WDR
|
Digital WDR
|
|
Angle Adjustment
|
Pan: 0° to 360°, tilt: 0°
to 75°, rotation: 0° to 360°
|
|
Lens
|
|
Focal length
|
2.8 mm
|
|
Aperture
|
F2.0
|
|
Focus
|
No
|
|
FOV
|
horizontal FOV 100°,
vertical FOV 55°, diagonal FOV 117°
|
|
Lens Mount
|
M12
|
|
IR
|
|
IR Range
|
Up to 30 m
|
|
Wavelength
|
850 nm
|
|
Compression
Standard
|
|
Video Compression
|
Main stream: H.265 / H.264
Sub stream: H.265 / H.264 /
MJPEG
|
|
H.264 Type
|
Baseline Profile / Main
Profile / High Profile
|
|
H.264+
|
Main stream supports
|
|
H.265 Type
|
Main Profile
|
|
H.265+
|
Main stream supports
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
Smart
Feature-set
|
|
Region of Interest
|
1 fixed region for main
stream and sub-stream
|
|
|
|
Max. Resolution
|
2560 × 1440
|
|
Main Stream Max. Frame Rate
|
50Hz: 20fps (2560 × 1440,
1920 × 1080, 1280 × 720)
60Hz: 20fps (2560 × 1440,
1920 × 1080, 1280 × 720)
|
|
Sub-stream
Max. Frame Rate
|
50Hz: 20fps (704 × 576, 352
× 288, 640 × 480, 320 × 240)
60Hz: 20fps (704 × 480, 352
× 240, 640 × 480, 320 × 240)
|
|
Image Enhancement
|
BLC, 3D DNR
|
|
Image Setting
|
Saturation, brightness,
contrast, sharpness, AGC, white balance adjustable by client software or web
browser
|
|
Day/Night Switch
|
Auto, scheduled
|
|
Network
|
|
Network Storage
|
NAS (NFS, SMB/CIFS)
|
|
Alarm Trigger
|
Motion detection, video
tampering alarm, illegal login
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS,
FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP,
802.1X, QoS, IPv6, UDP, Bonjour
|
|
General Function
|
Anti-flicker, heartbeat,
mirror, password protection, privacy mask, watermark, IP address filter
|
|
API
|
ONVIF (PROFILE S, PROFILE
G), ISAPI
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
User/Host
|
Up to 32 users
3 levels: Administrator,
Operator and User
|
|
Client
|
iVMS-4200, Hik-Connect,
iVMS-5200
|
|
Interface
|
|
Communication Interface
|
1 RJ45 10M/100M
self-adaptive Ethernet port
|
|
General
|
|
Operating Conditions
|
-30 °C to 50 °C (-22 °F to
122 °F), humidity: 95% or less (non-condensing)
|
|
Power Supply
|
12 VDC ± 25%, 5.5 mm
coaxial power plug PoE (802.3af, class 3)
|
|
Power Consumption and
Current
|
12 VDC, 0.4 A, Max: 5 W
PoE: (802.3af, 37 V to 57
V), 0.2 A to 0.13 A, Max: 7 W
|
|
Ingress Protection
|
IP67
TVS 2000V lightning
protection, surge protection and voltage transient protection
|
|
Material
|
Metal & Plastic
|
|
Dimensions
|
Camera: Ø 110 mm × 93.2 mm
( 4.3" × 3.7")
|
