Camera
|
|
Image Sensor
|
1/3″ Progressive Scan CMOS
|
|
Min. Illumination
|
Color: 0.028 Lux @ (F2.0,
AGC ON), 0 Lux with IR
|
|
Shutter Speed
|
1/3 s to 1/100,000 s
|
|
Slow Shutter
|
Yes
|
|
Wide Dynamic Range
|
120 dB
|
|
Day & Night
|
ICR Cut
|
|
Angle Adjustment
|
Pan: 0° to 360°, tilt: 0°
to 180°, rotate: 0° to 360°
|
|
Lens
|
|
Lens Type & FOV
|
4 mm, horizontal FOV 75°,
vertical FOV 41°, diagonal FOV 88°
|
|
Aperture
|
4 mm F2.0
|
|
Lens Mount
|
M12
|
|
Illuminator
|
|
IR Range
|
50 m
|
|
Wavelength
|
850 nm
|
|
Smart Supplement Light
|
Yes
|
|
Video
|
|
Max. Resolution
|
2560 × 1440
|
|
Main Stream
|
50Hz: 20fps (2560 × 1440),
25fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20fps (2560 × 1440),
30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
|
|
Sub Stream
|
50Hz: 25fps (640 × 480, 640
× 360, 320 × 240)
60Hz: 30fps (640 × 480, 640
× 360, 320 × 240)
|
|
Video Compression
|
Main Stream: H.265 / H.264
/ H.264+ / H.265+
Sub-stream: H.265 / H.264 /
MJPEG
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
H.264 Type
|
Baseline Profile / Main
Profile / High Profile
|
|
H.265 Type
|
Main Profile
|
|
Stream Type
|
Main stream / Sub-stream
|
|
Region of Interest (ROI)
|
1 fixed region for main
stream and sub-stream
|
|
* Note: The frame rate of
the sub-stream cannot exceed the maximum frame rate of the current main
stream.
|
|
Smart
Feature-Set
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
API
|
ONVIF (PROFILE S, PROFILE
G), ISAPI, SDK
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS,
FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X,
QoS, IPv6, UDP, Bonjour, SSL/TLS
|
|
Smooth Streaming
|
Yes
|
|
User/Host
|
Up to 32 users. 3 user
levels: administrator, operator and user
|
|
Security
|
Password protection,
complicated password, HTTPS encryption, watermark, IP address filter, basic
and digest authentication for HTTP/HTTPS, WSSE and digest authentication for
ONVIF, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS
1.2
|
Network Storage
|
NAS (NFS, SMB / CIFS)
|
Client
|
iVMS-4200, Hik-Connect,
Hik-Central
|
|
Smart IR
|
Yes
|
Day/Night Switch
|
Day, Night, Auto, Schedule
|
Image Enhancement
|
BLC, HLC, 3D DNR
|
Image Settings
|
Saturation, brightness,
contrast, sharpness, AGC, white balance adjustable by client software or web
browser
|
SNR
|
≥ 52 dB
|
Interface
|
Communication Interface
|
1 RJ45 10M / 100M
self-adaptive Ethernet port
|
Intelligent
(Traditional Algorithm)
|
Basic Event
|
Motion detection, video
tampering alarm
|
General
|
Linkage Method
|
Upload to FTP, notify
surveillance center, send email, trigger capture
|
General Function
|
Anti-flicker, heartbeat,
mirror, password protection, privacy masks, watermark, IP address filter
|
Storage Conditions
|
-30 °C to 60 °C (-22 °F to
140 °F). Humidity 95% or less (non-condensing)
|
Startup and Operating
Conditions
|
-30 °C to 60 °C (-22 °F to
140 °F). Humidity 95% or less (non-condensing)
|
Power Supply
|
12 VDC ± 25%, PoE: 802.3af,
Type 1 Class 3, reverse polarity protection
|
Power Consumption and
Current
|
12 VDC, 0.50 A, max. 6W
PoE (802.3af, 36 V to 57
V), 0.20 A to 0.10 A, max. 7 W
|
Power Interface
|
Φ5.5 mm coaxial power plug
|
Material
|
Front cover & bracket:
metal
Back cover & sun
shield: plastic
|
Camera Dimension
|
71.67 × 92.87 × 221.49 mm
(2.82" × 3.65" × 8.72")
|
Package Dimension
|
234 × 120 × 117 mm (9.21″ ×
4.72″ × 4.61″)
|
Camera Weight
|
500 g (1.10 lb.)
|
With Package Weight
|
670 g (1.48 lb.)
|
Approval
|
Protection
|
Ingress protection: IP67 (IEC
60529-2013)
|
EMC
|
FCC (47 CFR Part 15,
Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); IC (ICES-003: Issue 6, 2016)
|
Safety
|
UL (UL 60950-1); CB (IEC
60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950- 1:2005 + Am 1:2009 +
Am 2:2013); BIS (IS 13252 (Part 1) : 2010+A1 : 2013+A2:2015)
|
Environment
|
CE-RoHS (2011 / 65 / EU);
WEEE (2012 / 19 / EU); Reach (Regulation (EC) No 1907/2006)
|
