Camera
|
|
Sensor
|
1/3"
Progressive Scan CMOS
|
|
Min.
Illumination
|
Color:
0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR
|
|
Shutter
Speed
|
1/3
s to 1/100,000 s
|
|
Slow
Shutter
|
Yes
|
|
Day
& Night
|
IR
Cut Filter
|
|
Digital
Noise Reduction
|
3D
DNR
|
|
WDR
|
120dB
|
|
3-Axis
Adjustment
|
Pan:
0° to 360°, tilt: 0° to 100°, rotate: 0° to 360°
|
|
Lens
|
|
Focal
length
|
4
mm
|
|
Aperture
|
F1.6
|
|
Focus
|
Fixed
|
|
FOV
|
4
mm, horizontal FOV: 83°, vertical FOV: 45°, diagonal FOV: 99°
|
|
Lens
Mount
|
M12
|
|
IR
|
|
IR
Range
|
-I5:
Up to 50 m
-I8:
Up to 80 m
|
|
Wavelength
|
850nm
|
|
Compression Standard
|
|
Video
Compression
|
Main
stream: H.265 / H.264
Sub-stream:
H.265 / H.264 / MJPEG
Third
stream: H.265 / H.264
|
|
H.264
Type
|
Main
Profile / High Profile
|
|
H.264+
|
Main
stream supports
|
|
H.265
Type
|
Main
Profile
|
|
H.265+
|
Main
stream supports
|
|
Video
Bit Rate
|
32
Kbps to 16 Mbps
|
|
Smart Feature-set
|
|
Smart
Event
|
Line
crossing detection, intrusion detection, face detection
|
|
Basic
Event
|
Motion
detection, video tampering alarm, exception (network disconnected, IP address
conflict, illegal login, HDD full, HDD error)
|
|
Linkage
Method
|
Trigger
recording: memory card, network storage, pre-record and post-record Trigger captured
pictures uploading: FTP, HTTP,NAS, Email Trigger notification: HTTP, ISAPI, Email
|
|
Region
of Interest
|
1
fixed region for main stream and sub-stream
|
|
|
|
Max.
Resolution
|
2688
× 1520
|
|
Main
Stream
|
50Hz:25fps
(2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz:
30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720)
|
|
Sub-Stream
|
50Hz:
25fps (640 × 480, 640 × 360, 320 × 240)
60Hz:
30fps (640 × 480, 640 × 360, 320 × 240)
|
|
Third
Stream
|
50Hz:
25fps (1280 × 720, 640 × 360, 352 × 288)
60Hz:
30fps (1280 × 720, 640 × 360, 352 × 240)
|
|
Enhancement
|
BLC
/ 3D DNR / HLC
|
|
Setting
|
Rotate
mode, saturation, brightness, contrast, sharpness, AGC, and white balance are
adjustable by client software or web browser
|
|
Target
Cropping
|
No
|
|
Day
/ Night Switch
|
Day
/ Night / Auto / Schedule
|
|
Network
|
|
Network
Storage
|
Support
Micro SD / SDHC / SDXC card (128G), local storage and NAS (NFS, SMB / CIFS),
ANR
|
|
Protocols
|
TCP/IP,
UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,
UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
|
|
General
Function
|
Anti-flicker,
three streams, heartbeat, mirror, privacy masks, password reset via
e-mail, pixel counter, HTTP listening
|
|
Security
|
Password
protection, complicated password, HTTPS encryption, 802.1X authentication
(EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest
authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
|
|
API
|
ONVIF
(PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome
|
|
Simultaneous
Live View
|
Up
to 6 channels
|
|
User/Host
|
Up
to 32 users
3
levels: Administrator, Operator and User
|
|
Client
|
iVMS-4200,
Hik-Connect, Hik-Central
|
|
Interface
|
|
Communication
Interface
|
1
RJ45 10M/100M self-adaptive Ethernet port
|
|
Video
Output
|
No
|
|
On-board
storage
|
Built-in
Micro SD / SDHC / SDXC slot, up to 128 GB
|
|
SVC
|
H.264
and H.265 encoding
|
|
Reset
Button
|
Yes
|
|
General
|
|
Operating
Conditions
|
-30
°C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
|
|
Power
Supply
|
12
VDC ± 25%, Φ 5.5 mm coaxial power plug PoE (802.3af, class 3)
|
|
Power
Consumption and Current
|
-I5:
12
VDC, 0.6 A, max. 7.5 W
PoE
(802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max. 9.5 W
-I8:
12
VDC, 0.95 A, max. 11.5 W
PoE
(802.3af, 36 V to 57 V), 0.35 A to 0.1 A, max. 12.5 W
|
|
Protection
Level
|
IP67
|
|
Material
|
Metal
|
|
Dimensions
|
Camera:
Φ 105 × 299.7 mm (Φ 4.1" × 11.8") Package: 386 × 156 × 155 mm
(15.2" × 6.1" × 6.1")
|
|
Weight
|
Camera:
Approx. 1180 g (2.6 lb.)
With
Package: Approx. 1700 g (3.7 lb.)
|
