Camera
|
|
Image Sensor
|
1/3" Progressive
Scan CMOS
|
|
Max. Resolution
|
2560 × 1440
|
|
Shutter Time
|
1/3 s to 1/100,000
s
|
|
Min. Illumination
|
Color: 0.01 Lux @
(F2.0, AGC ON), B/W: 0 Lux with IR
|
|
Day & Night
|
IR cut filter
|
|
Angle Adjustment
|
Pan: 0° to 360°, tilt:
0° to 180°, rotate: 0° to 360°
|
|
Lens
|
|
Lens Type
|
Fixed focal lens,
4mm
|
|
Focal Length &
FOV
|
4 mm, horizontal FOV
76°, vertical FOV 41°, diagonal FOV 90°
|
|
Lens Mount
|
M12
|
|
Iris Type
|
Fixed
|
|
Aperture
|
F2.0
|
|
DORI
|
|
DORI
|
4 mm, D: 79 m, O:
31 m, R: 15 m, I: 7 m
|
|
Illuminator
|
|
Supplement Light Type
|
IR
|
|
Supplement Light Range
|
Up to 50 m
|
|
Smart Supplement Light
|
Yes
|
|
IR Wavelength
|
850 nm
|
|
Video
|
|
Main Stream
|
50 Hz:
20 fps (2560 × 1440)
25 fps (1920 × 1080,
1280 × 720)
60 Hz:
20 fps (2560 × 1440)
24 fps (1920 × 1080,
1280 × 720)
|
|
Sub-Stream
|
50 Hz: 25 fps (1280
× 720, 640 × 480, 640 × 360)
60 Hz: 24 fps (1280
× 720, 640 × 480, 640 × 360)
|
|
Video Compression
|
Main stream: H.265+
/ H.265 / H.264+ / H.264
Sub-stream: H.265
/ H.264 / MJPEG
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
H.264 Type
|
Baseline Profile /
Main Profile / High Profile
|
|
H.265 Type
|
Main Profile
|
|
Bit Rate Control
|
CBR/VBR
|
|
Region of Interest
(ROI)
|
1 fixed region for
main stream
|
|
Audio
|
|
Audio Type
|
-U: Mono sound
|
|
Environment Noise
Filtering
|
-U: Yes
|
|
Audio Sampling Rate
|
-U: 8 kHz/16 kHz
|
|
Audio Compression
|
-U: G.711ulaw / G.711alaw
/ G.722.1 / G.726 / MP2L2 / PCM / AAC-LC
|
|
Audio Bit Rate
|
-U: 64 Kbps (G.711
ulaw) / 64 Kbps (G.711 alaw) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32 to 160
Kbps (MP2L2) / 16 to 64 Kbps (AAC-LC)
|
|
Network
|
|
Security
|
Password protection,
complicated password, watermark, IP address filter, basic and digest
authentication for HTTP, WSSE and digest authentication for Open Network Video
Interface, security audit log, host authentication (MAC address)
|
|
Simultaneous Live
View
|
Up to 6 channels
|
|
Protocols
|
TCP/IP, ICMP, DHCP,
DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
|
|
|
|
Wide Dynamic Range
(WDR)
|
120 dB
|
|
SNR
|
≥ 52 dB
|
|
Day/Night Switch
|
Day, Night, Auto,
Schedule
|
|
Image Enhancement
|
BLC, HLC, 3D DNR
|
|
Image Settings
|
Rotate mode, saturation,
brightness, contrast, sharpness, gain, white balance, adjustable by client software
or web browser
|
|
Privacy Mask
|
4 programmable polygon
privacy masks
|
|
Interface
|
|
Ethernet Interface
|
1 RJ45 10 M/100 M
self-adaptive Ethernet port
|
|
On-Board Storage
|
-F: Built-in memory
card slot, support microSD / microSDHC / microSDXC card, up to 256 GB
|
|
Built-in Microphone
|
-U: Yes
|
|
Reset Key
|
-F: Yes
|
|
Event
|
|
Basic Event
|
Motion detection (support
alarm triggering by specified target types (human and vehicle), video tampering
alarm, exception
|
|
Linkage
|
Upload to FTP/memory
card (-F), notify surveillance center, send email, trigger recording (-F), trigger
capture
|
|
General
|
|
Power
|
12 VDC ± 25%, 0.45
A, max. 5.5 W, Ø5.5 mm coaxial power plug
PoE: 802.3af, Class
3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W
|
|
Material
|
Metal & Plastic
|
|
Dimension
|
83.7 mm × 80.7 mm
× 205.6 mm (3.3" × 3.2"× 8.1")
|
|
Weight
|
-I: Approx. 560 g
(1.2 lb.); -IUF: Approx. 580 g (1.3 lb.)
|
|
General Function
|
Heartbeat, anti-banding,
mirror, password protection, password reset via email
|
