DS-2CD1T47G2-LUF 4mm

DS-2CD1T47G2-LUF 4mm

Hikvision DS-2CD1T47G2-LUF 4MP ColorVu MD 2.0 Fixed Bullet Network Camera, 24/7 Colorful Imaging, Up to 50m White Light Range, 120dB WDR, BLC, HLC, 3D DNR, H.265+ Compression, Supports Human and Vehicle Detection, Built-in microphone for real-time audio, Support on-board storage up to 256GB (SD card slot), Water and Dust resistant (IP67).

DS-2CD1T47G2-LUF

ColorVu Camera

Hikvision DS-2CD1T47G2-LUF 4MP ColorVu MD 2.0 Fixed Bullet Network Camera

Frame Rate

20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720)

IR Range

Up to 50m White Light Range

Motion Detection 2.0

Support Human and Vehicle Detection

Smart Features

120dB WDR, 3D DNR, BLC, HLC, ROI, Day & Night with ICR, Smart IR

Protection Level

Ingress protection: IP67 (IEC 60529-2013)

Camera

Image Sensor

1/3" Progressive Scan CMOS

Max. Resolution

2560 × 1440

Shutter Time

1/3 s to 1/100,000 s

Min. Illumination

Color: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with light

Day & Night

24/7 color imaging

Angle Adjustment

Pan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360°

Lens

Lens Type

Fixed focal lens, 4 mm

Focal Length & FOV

4 mm, horizontal FOV: 75°, vertical FOV: 40°, diagonal FOV: 89°

Lens Mount

M12

Iris Type

Fixed

Aperture

F1.0

Depth of Field

4 mm: 2.7 m to

DORI

DORI

4 mm, D: 82 m, O: 32 m, R: 16 m, I: 8 m

Illuminator

Supplement Light Type

White Light

Supplement Light Range

Up to 50 m

Smart Supplement Light

Yes

Video

Main Stream

50 Hz:

20 fps (2560 × 1440)

25 fps (1920 × 1080, 1280 × 720)

60 Hz:

20 fps (2560 × 1440)

24 fps (1920 × 1080, 1280 × 720)

Sub-Stream

50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)

Video Compression

Main stream: H.265+ / H.265 / H .264+ / H.264

Sub-stream: H.265 / H.264 / MJPEG

Video Bit Rate

32 Kbps to 8 Mbps

H.264 Type

Baseline Profile, Main Profile, High Profile

H.265 Type

Main Profile

Bit Rate Control

CBR, VBR

Region of Interest (ROI)

1 fixed region(s) for main stream

Audio

Audio Type

-U: Mono sound

Environment Noise Filtering

-U: Yes

Audio Sampling Rate

-U: 8 kHz / 16 kHz

Audio Compression

-U: G.711ulaw / G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC

Audio Bit Rate

-U: 64 Kbps (G.711 ulaw) / 64 Kbps (G.711 alaw) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)

Network

Protocols

TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP

Simultaneous Live View

Up to 6 channels

API

Open Network Video Interface (Profile S, Profile T, Profile G (only -U model supports)), ISAPI, SDK

User/Host

Up to 32 users

3 user levels: administrator, operator, and user

 Security

Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)


Wide Dynamic Range (WDR)

120 dB

SNR

52 dB

Day/Night Switch

Day, Night, Auto, Schedule

Image Enhancement

BLC, HLC, 3D DNR

Image Settings

Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser

Privacy Mask

4 programmable polygon privacy masks

Interface

Ethernet Interface

1 RJ45 10 M/100 M self-adaptive Ethernet port

On-Board Storage

Built-in memory card slot, support microSD / microSDHC / microSDXC card, up to 256 GB

Built-in Microphone

-U: Yes

Reset Key

-F: Yes

Event

Basic Event

Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception

Linkage

Upload to FTP/memory card (-F), notify surveillance center, send email, trigger recording (-F), trigger capture

General

Power

12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug

PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W

Material

Front cover: metal, body: plastic, bracket: metal

Dimension

83.7 mm × 80.7 mm × 205.6 mm (3.3" × 3.2" × 8.1")

Package Dimension

260 mm × 125 mm × 125 mm (10.2" × 4.9" × 4.9")

Weight

-L: Approx. 560 g (1.2 lb.)

-LUF: Approx. 580 g (1.3 lb.)

With Package Weight

-L: Approx. 615 g (1.4 lb.)

-LUF: Approx. 635 g (1.4 lb.)

Storage Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Startup and Operating

Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Approval



EMC

FCC: 47 CFR Part 15, Subpart B

CE-EMC: EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN

50130-4: 2011 + A1: 2014

RCM: AS/NZS CISPR 32: 2015

KC: KN32: 2015, KN35: 2015

Safety

UL: UL 62368-1,

CB: IEC 62368-1: 2014+A11

CE-LVD: EN 62368-1: 2014/A11: 2017

BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005

Environment

CE-RoHS: 2011/65/EU WEEE: 2012/19/EU

Reach: Regulation (EC) No 1907/2006

Protection

IP67: IEC 60529-2013
