Camera
|
|
Image Sensor
|
1/2.9″ Progressive Scan CMOS
|
|
Min. Illumination
|
Color: 0.005 Lux @ (F1.6, AGC ON),0 Lux with light
|
|
Shutter Speed
|
1/3 s to 1/100,000 s
|
|
Slow Shutter
|
Yes
|
|
P/N
|
P/N
|
|
Wide Dynamic Range
|
120 dB
|
|
Day & Night
|
ICR Cut Filter
|
|
Angle Adjustment
|
Pan: 0° to 360°, tilt: 0°
to 90°, rotate: 0° to 360°
|
|
Lens
|
|
Lens Type & FOV
|
4 mm, horizontal FOV 84°, vertical FOV 45°, diagonal FOV 100°
|
|
Aperture
|
F1.6
|
|
Lens Mount
|
M12
|
|
DORI
|
|
DORI
|
4 mm, D: 78 m, O: 31 m, R: 15 m, I: 7 m
|
|
Illuminator
|
|
IR Range
|
Up to 40 m
|
|
Wavelength
|
850 nm
|
|
Video
|
|
Max. Resolution
|
2688 × 1520
|
|
Main Stream
|
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
|
|
Sub Stream
|
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
|
|
Third Stream
|
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.
|
|
Video Compression
|
Main stream: H.265 / H.264 /
H.264+ / H.265+
Sub-stream: H.265 / H.264
Third stream: H.265 / H.264
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
H.264 Type
|
Baseline Profile / Main
Profile / High Profile
|
|
H.265 Type
|
Main Profile
|
|
H.264+
|
Main Stream supports
|
|
H.265+
|
Main Stream supports
|
|
Bit Rate Control
|
CBR/VBR
|
|
Scalable Video Coding (SVC)
|
Yes
|
|
Region of Interest (ROI)
|
1 fixed region for main
stream and sub-stream
|
|
Network
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
API
|
Open Network Video
Interface (Profile S, Profile G), ISAPI, SDK
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS,
FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6,
UDP, Bonjour, SSL/TLS, PPPoE
|
|
User/Host
|
Up to 32 users. 3 user
levels: administrator, operator and user
|
|
Security
|
Password protection,
complicated password, HTTPS encryption, IP address filter, Security Audit
Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and
digest authentication for Open Network Video Interface
|
|
Network Storage
|
MicroSD / SDHC / SDXC card
(256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment
(ANR)
|
|
Client
|
iVMS-4200, Hik-Connect,
Hik-Central
|
|
|
|
Day/Night Switch
|
Day, Night, Auto, Schedule
|
|
Image Enhancement
|
BLC, HLC, 3D DNR
|
|
Image Parameters Switch
|
Yes
|
|
Image Settings
|
Rotate, mirror, privacy
mask, saturation, brightness, contrast, sharpness, gain, white balance
adjustable by client software or web browser
|
|
Interface
|
|
On-board Storage
|
Built-in memory card slot, support microSD / microSDHC / microSDXC card, up to 512 GB
|
|
Built-in Microphone
|
-2U: Arrayed dual-microphone
|
|
Communication Interface
|
1 RJ45 10M/100M
self-adaptive Ethernet port
|
|
Event
|
|
Basic Event
|
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm, exception
|
|
Linkage
|
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture
|
|
Deep
Learning Function
|
|
Perimeter Protection
|
Line crossing, intrusion Support alarm triggering by specified target types (human and vehicle)
|
|
General
|
|
Power
|
12 VDC ± 25%, 0.5 A, max. 6 W, reverse polarity protection,Ø5.5 mm coaxial power plug, PoE: IEEE 802.3af, Class 3, max. 7.5 W
|
|
General Function
|
Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding
|
|
Storage Conditions
|
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Startup and Operating
Conditions
|
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Material
|
Metal
|
|
Dimension
|
Ø74.4 mm × 176.3 mm (Ø2.93" × 6.94")
|
|
Package Dimension
|
234 mm × 120 mm × 117 mm (9.21" × 4.72" × 4.61")
|
|
Weight
|
Approx. 515 g (1.1 lb.)
|
|
With Package Weight
|
Approx. 760 g (1.7 lb.)
|
