Camera |
Image Sensor | 1/2.5" Progressive Scan CMOS |
Min. Illumination | Color: 0.01 lux @(F1.2, AGC ON), 0 lux with IR |
Shutter Speed | 1/3 s to 1/100,000 s |
Slow Shutter | Support |
Lens | 2.8 mm, horizontal field of view: 102° 4 mm, horizontal field of view: 79° 6 mm, horizontal field of view: 50° 8 mm, horizontal field of view: 40° 12 mm, horizontal field of view: 23° |
Lens Mount | M12 |
Iris | F2.0 |
Day &Night | IR cut filter |
DNR | 3D DNR |
Wide Dynamic Range | 120dB |
3-Axis Adjustment (bracket) | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
Compression Standard |
Video Compression | Main stream: H.265 / H.264 Sub stream: H.265 / H.264 / MJPEG Third stream: H.265 / H.264 |
H.264 Type | Main Profile / High Profile |
H.264+ | Support |
H.265 Type | Main Profile |
H.265+ | Support |
Video Bit Rate | 32 Kbps to 16 Mbps |
Image |
Max. Resolution | 3840 × 2160 |
Main Stream | 50Hz: 20 fps (3840 × 2160), 25 fps (2560 × 1920, 2560 × 1440, 1920 × 1080, 1280 × 720) 60Hz: 20 fps (3840 × 2160), 30 fps (2560 × 1920, 2560 × 1440, 1920 × 1080, 1280 × 720) |
Sub Stream | 50Hz: 25fps (640 × 360, 352 × 288) 60Hz: 30fps (640 × 360, 352 × 240) |
Third Stream | 50Hz: 25fps (1280 ×720, 640 × 360, 352 × 288) 60Hz: 30fps (1280 ×720, 640 × 360, 352 × 240) |
Image Enhancement | BLC / 3D DNR |
Image Settings | Support rotate mode. Brightness, contrast, saturation, and sharpness are adjustable via web browser and client software |
ROI (Region of Interest) | Support 1 fixed region for mainstream and sub stream separately |
Day/Night Switch | Auto / Scheduled |
Network |
Network Storage | Support microSD / SDHC / SDXC card (128G) local storage, NAS (NFS,SMB / CIFS), ANR |
Alarm Trigger | Motion Detection, Tampering Alarm, Network Disconnected, IP Address Conflict, Illegal Login, HDD full, HDD error |
Protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 |
Standard | ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
General Function | One-key Reset, Anti-Flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark, IP Address Filter |
Interface |
Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
On-board Storage | Built-in microSD / SDHC / SDXC slot, up to 128 GB |
Smart Feature-set |
Behavior Analysis | Line crossing detection, intrusion detection, unattended baggage detection, object removal detection |
Line Crossing Detection | Cross a pre-defined virtual line, up to 1 pre-defined virtual lines supported |
Intrusion Detection | Enter and loiter in a pre-defined virtual region, up to 1 pre-defined virtual regions supported |
Object Removal Detection | Objects removed from the pre-defined region, such as the exhibits on display. |
Unattended Baggage Detection | Objects left over in the pre-defined region such as the baggage, purse, dangerous materials |
Face Detection | Human face appears in the image can be detected and trigger linkage method |
General |
Operating Conditions | -30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing) |
Power Supply | 12 VDC ± 25%, 7W PoE(802.3af, class 3), 7.5W |
IR Range | Up to 30 m |
Protection Level | IP67 |
Dimensions | Camera: Φ70 × 155.03 mm (Φ2.76″ × 6.1″) Package: 216 × 121 × 118 mm (8.5″ × 4.76″ × 4.65″) |
Weight | Camera: 410 g (0.9 lb.) |
