Camera |
Image Sensor | 1/2.8" Progressive Scan CMOS |
Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR |
Shutter Speed | 1/3 s to 1/100,000 s |
Slow Shutter | Yes |
Day & Night | IR Cut Filter |
WDR | 120 dB |
Angle Adjustment | Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
Lens |
Lens Type | Fixed lens, 2.8mm |
Aperture | F2.0 |
FOV | 2.8mm: horizontal FOV: 114°, vertical FOV: 62°, diagonal FOV: 135° |
Lens Mount | M12 |
Illuminator |
IR Range | Up to 30 m |
Wavelength | 850 nm |
Video |
Max. Resolution | 1920 × 1080 |
Main Stream | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
Sub Stream | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
Third Stream | 50Hz: 25fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 240) |
Video Compression | Main stream / third stream: H.265 / H.264 Sub-stream: H.265 / H.264 / MJPEG |
H.264 Type | Main Profile / High Profile |
H.264+ | Main stream supports |
H.265 Type | Main Profile |
H.265+ | Main stream supports |
Video Bit Rate | 32 Kbps to 16 Mbps |
Scalable Video Coding (SVC) | H.264 and H.265 encoding support |
Smart Feature-Sett |
Smart Event | Line crossing detection, intrusion detection and face detection |
Basic Event | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
Linkage Method | Trigger recording: memory card, network storage, pre record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, Email |
Region of Interest | 1 fixed region for main stream and sub-stream |
Image |
Image Enhancement | BLC, HLC, 3D DNR |
Image Setting | Rotate mode, saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser |
Day/Night Switch | Day / Night / Auto / Schedule |
Network |
Network Storage | microSD / SDHC / SDXC card (128 GB), local storage and NAS (NFS, SMB / CIFS), ANR |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL / TLS |
API | ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome |
Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2 |
Simultaneous Live View | Up to 6 channels |
User/Host | Up to 32 users, 3 levels: administrator, operator and user |
Client | iVMS-4200, Hik-Connect, Hik-Central |
Interface |
Communication Interface | 1 RJ45 100M self-adaptive Ethernet port |
On-board storage | Built-in micro SD / SDHC / SDXC slot, up to 256 GB |
General |
General Function | Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e- mail, pixel counter, HTTP listening |
Reset | Reset via reset button on camera body, web browser and client software |
Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
