Camera
|
|
Sensor
|
1/2.8"
Progressive Scan CMOS
|
|
Min.
Illumination
|
Color:
0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
|
|
Shutter
Speed
|
1/3
s to 1/100,000 s
|
|
Slow
Shutter
|
Yes
|
|
P/N
|
P/N
|
|
Wide
Dynamic Range
|
120
dB
|
|
Day
& Night
|
IR cut
filter
|
|
Angle
Adjustment
|
Pan:
0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
|
|
Lens
|
|
Lens
Type
|
Fixed
focal length, 2.8 mm
|
|
Focal
Length & FOV
|
2.8
mm, horizontal FOV 107°, vertical FOV 57°, diagonal FOV 128°
|
|
Lens
Mount
|
M12
|
|
Iris
Type
|
Fixed
|
|
Aperture
|
F1.6
|
|
DORI
|
|
DORI
|
2.8
mm: D: 88 m, O: 35 m, R: 17 m, I: 9 m
|
|
Illuminator
|
|
Supplement
Light Type
|
IR
|
|
Smart
Supplement Light
|
Yes
|
|
IR Wavelength
|
850
nm
|
|
IR Range
|
Up to
30 m
|
|
Video
|
|
Max.
Resolution
|
3840
× 2160
|
|
Main
Stream
|
50 Hz:
20 fps (3840 × 2160)
25 fps
(3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
20 fps (3840 × 2160)
30 fps
(3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
|
|
Sub
Stream
|
50 Hz:
25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz:
30 fps (1280 × 720, 640 × 480, 640 × 360)
|
|
Third
Stream
|
50 Hz:
10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz:
10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third
stream is supported under certain settings.
|
|
Video
Compression
|
Main
stream: H.265 / H.264 / H.264+ / H.265+
Sub-stream: H.265 / H.264
Third
stream: H.265 / H.264
*Third
stream is supported under certain settings.
|
|
Video
Bit Rate
|
32 Kbps
to 16 Mbps
|
|
H.264
Type
|
Baseline
Profile / Main Profile / High Profile
|
|
H.265
Type
|
Main
Profile
|
|
H.264+
|
Main
stream supports
|
|
H.265+
|
Main
stream supports
|
|
Bit
Rate Control
|
CBR/VBR
|
|
Scalable
Video Coding (SVC)
|
H.264
and H.265 encoding
|
|
Region
of Interest (ROI)
|
1 fixed
region for main stream and sub-stream
|
|
Audio
|
|
Audio
Compression
|
G.711ulaw
/ G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC
|
|
Audio
Bit Rate
|
64 Kbps
(G.711ulaw / G.711alaw) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 16-64 Kbps (AAC-LC)
/ 32-192 Kbps (MP2L2) / 8-320 Kbps (MP3)
|
|
Audio
Sampling Rate
|
8 kHz
/ 16 kHz / 32 kHz / 44.1 kHz / 48 kHz
|
|
Environment
Noise Filtering
|
Yes
|
|
Network
|
|
Protocols
|
TCP/IP,
ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X,
QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
|
|
Simultaneous
Live View
|
Up to
6 channels
|
|
API
|
Open
Network Video Interface (Profile S, Profile G), ISAPI, SDK
|
|
User/Host
|
Up to
32 users. 3 user levels: administrator, operator and user
|
|
Security
|
Password
protection, complicated password, HTTPS encryption, IP address filter, Security
Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE
and digest authentication for Open Network Video Interface
|
|
Network
Storage
|
NAS
(NFS, SMB/CIFS), auto network replenishment (ANR)
|
|
|
|
Parameters Switch
|
Yes
|
|
Settings
|
Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
|
|
Day/Night
Switch
|
Day,
Night, Auto, Schedule
|
|
Enhancement
|
BLC,
HLC, 3D DNR
|
|
SNR
|
≥ 52 dB
|
|
Interface
|
|
Ethernet
Interface
|
1 RJ45
10 M/100 M self-adaptive Ethernet port
|
|
On-board
Storage
|
Built-in
memory card slot, support microSD / SDHC / SDXC card, up to 512 GB
|
|
Built-in
Microphone
|
Yes
|
|
Hardware
Reset
|
Yes
|
|
Event
|
|
Basic
Event
|
Motion
detection (human and vehicle targets classification), video tampering alarm, exception
|
|
Face
Detection
|
Yes
|
|
Deep Learning Function
|
|
Perimeter
Protection
|
Line
crossing detection, intrusion detection
Supports
human and vehicle targets classification
|
|
General
|
|
Linkage
Method
|
Upload
to FTP / memory card / NAS, notify surveillance center, trigger recording, trigger
capture, send email
|
|
Camera
Material
|
Aluminum
alloy body Bubble: plastic
|
|
Camera
Dimension
|
Ø121.4
mm × 92.2 mm (Ø4.8" × 3.7")
|
|
Package
Dimension
|
150
mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")
|
|
Camera
Weight
|
Approx.
550 g (1.2 lb.)
|
|
With
Package Weight
|
Approx.
800 g (1.8 lb.)
|
|
Storage
Conditions
|
-30
°C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Startup
and Operating Conditions
|
-30
°C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Power
Consumption and Current
|
12 VDC,
0.5 A, max. 6 W
PoE
(802.3af, 36 V to 57 V), 0.25 A to 0.15 A, max. 7.5 W
|
|
Power
Supply
|
12 VDC
± 25%, reverse polarity protection
PoE:
802.3af, Class 3
|
|
Power
Interface
|
Ø5.5
mm coaxial power plug
|
|
Approval
|
|
EMC
|
FCC
(47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3:
2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003:
Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
|
Protection
|
IP67
(IEC 60529-2013), IK10 (IEC 62262: 2002)
|
