Camera
|
Sensor
|
1/2.8"
Progressive Scan CMOS
|
Min.
Illumination
|
Color: 0.005 Lux @ (F1.6, AGC ON),0 Lux with light
|
Shutter
Speed
|
1/3
s to 1/100,000 s
|
Slow
Shutter
|
Yes
|
P/N
|
P/N
|
Wide
Dynamic Range
|
120
dB
|
Day
& Night
|
IR cut
filter
|
Angle
Adjustment
|
Pan:
0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
|
Lens
|
Lens
Type
|
Fixed
focal length, 2.8 mm
|
Focal
Length & FOV
|
2.8
mm, horizontal FOV 108°, vertical FOV 59°, diagonal FOV 128°
|
Lens
Mount
|
M12
|
Iris
Type
|
Fixed
|
Aperture
|
F1.6
|
DORI
|
DORI
|
2.8
mm: D: 84 m, O: 33 m, R: 16 m, I: 8 m
|
Illuminator
|
Supplement
Light Type
|
IR
|
Smart
Supplement Light
|
Yes
|
IR Wavelength
|
850
nm
|
IR Range
|
Up to
30 m
|
Video
|
Max.
Resolution
|
3840
× 2160
|
Main
Stream
|
50 Hz: 20 fps (3840 × 2160) 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 20 fps (3840 × 2160) 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
|
Sub
Stream
|
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
|
Third
Stream
|
50 Hz:
10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz:
10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third
stream is supported under certain settings.
|
Video
Compression
|
Main
stream: H.265 / H.264 / H.264+ / H.265+
Sub-stream: H.265 / H.264 Third
stream: H.265 / H.264
*Third
stream is supported under certain settings.
|
Video
Bit Rate
|
32 Kbps
to 16 Mbps
|
H.264
Type
|
Baseline
Profile / Main Profile / High Profile
|
H.265
Type
|
Main
Profile
|
H.264+
|
Main
stream supports
|
H.265+
|
Main
stream supports
|
Bit
Rate Control
|
CBR/VBR
|
Scalable
Video Coding (SVC)
|
H.264
and H.265 encoding
|
Region
of Interest (ROI)
|
1 fixed
region for main stream and sub-stream
|
Audio
|
Audio
Compression
|
-2U: G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC
|
Audio
Bit Rate
|
-2U: 64 Kbps (G.711ulaw / G.711alaw) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32 to 160Kbps (MP2L2) / 8 to 320 Kbps (MP3) / 16 to 64 Kbps (AAC-LC)
|
Audio
Sampling Rate
|
8 kHz
/ 16 kHz / 32 kHz / 44.1 kHz / 48 kHz
|
Environment
Noise Filtering
|
Yes
|
Network
|
Protocols
|
TCP/IP,
ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X,
QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
|
Simultaneous
Live View
|
Up to
6 channels
|
API
|
Open
Network Video Interface (Profile S, Profile G), ISAPI, SDK
|
User/Host
|
Up to
32 users. 3 user levels: administrator, operator and user
|
Security
|
Password
protection, complicated password, HTTPS encryption, IP address filter, Security
Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE
and digest authentication for Open Network Video Interface
|
Network
Storage
|
NAS
(NFS, SMB/CIFS), auto network replenishment (ANR)
|
|
Parameters Switch
|
Yes
|
Settings
|
Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
|
Day/Night
Switch
|
Day,
Night, Auto, Schedule
|
Enhancement
|
BLC,
HLC, 3D DNR
|
SNR
|
≥ 52 dB
|
Interface
|
Ethernet
Interface
|
1 RJ45
10 M/100 M self-adaptive Ethernet port
|
On-board
Storage
|
Built-in
memory card slot, support microSD / SDHC / SDXC card, up to 512 GB
|
Built-in
Microphone
|
Arrayed Dual-microphone
|
Hardware
Reset
|
Yes
|
Event
|
Basic
Event
|
Motion
detection (human and vehicle targets classification), video tampering alarm, exception
|
Linkage
|
Upload to FTP / NAS / memory card, notify surveillance center, send email, trigger recording, trigger capture, -S: trigger alarm output
|
Deep Learning Function
|
Perimeter
Protection
|
Line
crossing detection, intrusion detection
Supports
human and vehicle targets classification
|
General
|
Power
|
12 VDC ± 25%, 0.7 A, max. 8.4 W, Ø 5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 10 W
|
Camera
Material
|
Base: aluminum alloy, cover: aluminum alloy
|
Camera
Dimension
|
Ø121.4
mm × 92.2 mm (Ø4.8" × 3.7")
|
Package
Dimension
|
150
mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")
|
Camera
Weight
|
Approx. 600 g (1.2 lb.)
|
With
Package Weight
|
Approx.
840 g (1.8 lb.)
|
Storage
Conditions
|
-30
°C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
Startup
and Operating Conditions
|
-30
°C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
Power
Consumption and Current
|
12 VDC,
0.5 A, max. 6 W
PoE
(802.3af, 36 V to 57 V), 0.25 A to 0.15 A, max. 7.5 W
|
Power
Supply
|
12 VDC
± 25%, reverse polarity protection
PoE:
802.3af, Class 3
|
Power
Interface
|
Ø5.5
mm coaxial power plug
|
Approval
|
EMC
|
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015
|
Protection
|
IP67
(IEC 60529-2013), IK10 (IEC 62262: 2002)
|
