Camera
|
|
Sensor
|
2 ×
1/1.8" Progressive Scan CMOS
|
|
Max.
Resolution
|
5120
× 1440
|
|
Min.
Illumination
|
Color:
0.0005 Lux @ (F1.0, AGC ON),0 Lux with light
|
|
Shutter
Time
|
1/3
s to 1/100,000 s
|
|
Angle
Adjustment
|
Pan:
-30° to 30°, tilt: -75° to 75°
|
|
Lens
|
|
Lens
Type
|
Fixed
focal lens, Dual lens: 4 mm
|
|
Focal
Length & FOV
|
4
mm, horizontal FOV: 180°, vertical FOV: 44°
|
|
Lens
Mount
|
M16
|
|
Iris
Type
|
Fixed
|
|
Aperture
|
F1.0
|
|
Depth
of Field
|
3.6
m to ∞
|
|
DORI
|
|
DORI
|
4
mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m
|
|
Illuminator
|
|
Supplement
Light Type
|
White
Light
|
|
Supplement
Light Range
|
Up
to 30 m
|
|
Smart
Supplement Light
|
Yes
|
|
Video
|
|
Main
Stream
|
When
WDR is On:
50
Hz: 12.5 fps (5120 × 1440)
60
Hz: 15 fps (5120 × 1440)
When
WDR is Off:
50
Hz: 20 fps (5120 × 1440)
60
Hz: 20 fps (5120 × 1440)
|
|
Sub-Stream
|
When
WDR is On:
50
Hz: 12.5 fps (1920 × 536, 960 × 272)
60
Hz: 15 fps (1920 × 536, 960 × 272)
When
WDR is Off:
50
Hz: 20 fps (1920 × 536, 960 × 272)
60
Hz: 20 fps (1920 × 536, 960 × 272)
|
|
Video
Compression
|
Main
stream: H.265+ / H.265 / H.264+ / H.264
Sub-stream:
H.265 / H.264 / MJPEG
|
|
Video
Bit Rate
|
32
Kbps to 16 Mbps
|
|
H.264
Type
|
Baseline
Profile, Main Profile, High Profile
|
|
H.265
Type
|
Main
Profile
|
|
Bit
Rate Control
|
CBR,
VBR
|
|
Scalable
Video Coding (SVC)
|
H.264
and H.265 encoding
|
|
Region
of Interest (ROI)
|
1
fixed region(s) for main stream
|
|
Network
|
|
Protocols
|
TCP/IP,
ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,
SMTP, SNMP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, ISUP, ARP, WebSocket,
WebSockets
|
|
Security
|
Password
protection, complicated password, HTTPS encryption, 802.1X authentication
(EAP-MD5), watermark, IP address filter, basic and digest authentication for
HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface,
RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2,
host authentication (MAC address)
|
|
Network
Storage
|
NAS
(NFS, SMB/CIFS), Auto Network Replenishment (ANR), NVR, Together with
high-end Hikvision memory card, memory card encryption and health detection
are supported.
|
|
|
|
Parameters Switch
|
Yes
|
|
Settings
|
saturation,
brightness, contrast, sharpness, gain, white balance, adjustable by client
software or web browser
|
|
Day/Night
Switch
|
Day,
Night, Auto, Schedule
|
|
Wide
Dynamic Range (WDR)
|
130
dB
|
|
SNR
|
≥ 52 dB
|
|
Enhancement
|
BLC,
HLC, 3D DNR
|
|
Interface
|
|
Ethernet
Interface
|
1
RJ45 10 M/100 M self-adaptive Ethernet port
|
|
On-Board
Storage
|
Built-in
memory card slot, support microSD / microSDHC / microSDXC/TF card, up to 512
GB
|
|
Built-in
Microphone
|
Yes
|
|
Built-in
Speaker
|
Max.
power consumption: 1.2 W, max. sound pressure: 10 cm: 95 dB
|
|
Audio
|
1
input (line in), terminal block, max. input amplitude: 3.3 Vpp, input
impedance: 4.7 KΩ, interface type: non-equilibrium,
1
output (line out), terminal block, max. output amplitude: 3.3 Vpp, output
impedance: 100 Ω, interface type: non-equilibrium
|
|
Alarm
|
1
input, 1 output (max. 24 VDC, 1 A)
|
|
Reset
Key
|
Yes
|
|
Event
|
|
Basic
Event
|
Motion
detection (support alarm triggering by specified target types (human and
vehicle)), alarm input and output, flashing alarm light output, audible alarm
output, exception
|
|
Smart
Event
|
Line
crossing detection, intrusion detection, region entrance detection, region
exiting detection (support alarm triggered by specified target types (human
and vehicle)), scene change detection
|
|
Linkage
|
Upload
to FTP / NAS / memory card, notify surveillance center, send email, trigger
alarm output, trigger recording, trigger capture, audible warning, white
light flashing
|
|
Deep Learning Function
|
|
Perimeter
Protection
|
Line
crossing, intrusion, region entrance, region exiting (support alarm
triggering by specified target types (human and vehicle))
|
|
General
|
|
Power
|
12
VDC ± 25%, 0.88 A, max. 10.5 W,Ø 5.5 mm coaxial power plug,
PoE:
IEEE 802.3af, Class 3, 36 V to 57 V, 0.35 A to 0.22 A, max. 12.5 W
|
|
Material
|
Base:
metal, cover: metal
|
|
Dimension
|
Ø155
mm × 155.3 mm (Ø6.1" × 6.1")
|
|
Package
Dimension
|
230
mm × 230 mm × 230 mm (9" × 9" × 9")
|
|
Weight
|
Approx.
1110 g (2.4 lb.)
|
|
General
Function
|
Anti-flicker,
heartbeat, password reset via email, password protection, one-key reset
|
|
Flashing
Light
|
Yes
|
|
Approval
|
|
EMC
|
FCC:
47 CFR Part 15, Subpart B,
CE-EMC:
EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN
50130-4:
2011 +A1: 2014,
RCM:
AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7
|
|
Safety
|
UL:
UL 62368-1,
CB:
IEC 62368-1: 2014+A11,
CE-LVD:
EN 62368-1: 2014/A11: 2017
|
|
Environment
|
CE-RoHS:
2011/65/EU, WEEE: 2012/19/EU,
Reach:
Regulation (EC) No 1907/2006
|
|
Protection
|
IP67:
IEC 60529-2013
|
