Camera
|
|
Sensor
|
1/2.4"
Progressive Scan CMOS
|
|
Max.
Resolution
|
3200
× 1800
|
|
Min.
Illumination
|
Color:
0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
|
|
Shutter
Time
|
1/3
s to 1/100,000 s
|
|
Day
& Night
|
IR cut
filter
|
|
Angle
Adjustment
|
Pan:
-30° to 30°, tilt: 0° to 75°, rotate: 0° to 360°
|
|
Lens
|
|
Lens
Type
|
Fixed
focal lens, 2.8mm
|
|
Focal
Length & FOV
|
2.8
mm, horizontal FOV 105°, vertical FOV 55°, diagonal FOV 127°
|
|
Lens
Mount
|
M12
|
|
Iris
Type
|
Fixed
|
|
Aperture
|
F1.6
|
|
Depth
of Field
|
2.8
mm: 1.8 m to ∞;
|
|
DORI
|
|
DORI
|
2.8
mm: D: 76 m, O: 30 m, R: 15 m, I: 7 m;
|
|
Illuminator
|
|
Supplement
Light Type
|
IR
|
|
Supplement
Light Range
|
Up to
30 m
|
|
Smart
Supplement Light
|
Yes
|
|
IR
Wavelength
|
850
nm
|
|
Video
|
|
Main
Stream
|
50 Hz:
25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
|
|
Sub-Stream
|
50 Hz:
25 fps (1280 x 720, 640 × 480, 640 × 360)
60 Hz:
30 fps (1280 x 720, 640 × 480, 640 × 360)
|
|
Third
Stream
|
50 Hz:
10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz:
10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third
stream is supported under certain settings.
|
|
Video
Compression
|
Main
stream: H.265 / H.264 / H.265+ / H.264+
Sub-stream:
H.265 / H.264
Third
stream: H.265 / H.264
*Third
stream is supported under certain settings.
|
|
Video
Bit Rate
|
32 Kbps
to 16 Mbps
|
|
H.264
Type
|
Baseline
Profile / Main Profile / High Profile
|
|
H.265
Type
|
Main
Profile
|
|
Bit
Rate Control
|
CBR/VBR
|
|
Scalable
Video Coding (SVC)
|
H.264
and H.265 encoding
|
|
Region
of Interest (ROI)
|
1 fixed
region for main stream and sub-stream
|
|
Audio
|
|
Audio
Compression
|
G.711ulaw
/ G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC
|
|
Audio
Bit Rate
|
64 Kbps
(G.711ulaw / G.711alaw) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32 to 192 Kbps
(MP2L2)
/ 8 to 320 Kbps (MP3) / 16 to 64 Kbps (AAC-LC)
|
|
Audio
Sampling Rate
|
8 kHz
/ 16 kHz / 32 kHz / 44.1 kHz / 48 kHz
|
|
Environment
Noise Filtering
|
Yes
|
|
Network
|
|
Protocols
|
TCP/IP,
ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X,
QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP,
SFTP
|
|
Simultaneous
Live View
|
Up to
6 channels
|
|
API
|
Open
Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
|
|
Network
Storage
|
NAS
(NFS, SMB/CIFS), auto network replenishment (ANR)
|
|
|
|
Parameters Switch
|
Yes
|
|
Settings
|
Rotate
mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable
by client software or web browser
|
|
Day/Night
Switch
|
Day,
Night, Auto, Schedule
|
|
Wide
Dynamic Range (WDR)
|
120
dB
|
|
SNR
|
≥ 52 dB
|
|
Enhancement
|
BLC,
HLC, 3D DNR
|
|
Privacy
Mask
|
4 programmable
polygon privacy masks
|
|
Interface
|
|
Ethernet
Interface
|
1 RJ45
10 M/100 M self-adaptive Ethernet port
|
|
On-Board
Storage
|
Built-in
memory card slot, support microSD card, up to 512 GB
|
|
Audio
|
-IS:
1 input
(line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input
impedance: 4.7 KΩ, interface type: non-equilibrium
1 output
(line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output
impedance:
100 Ω, interface type: non-equilibrium
|
|
Alarm
|
-IS:
1 input, 1 output (max. 12 VDC, 30 mA)
|
|
Reset
Key
|
Yes
|
|
Event
|
|
Basic
Event
|
Motion
detection (human and vehicle targets classification), video tampering alarm, exception
|
|
Smart
Event
|
Line
crossing detection, intrusion detection (support alarm triggering by specified
target types (human and vehicle)), Face detection
|
|
Linkage
|
Upload
to FTP / NAS / memory card, notify surveillance center, trigger recording, trigger
capture,
send email, audible warning(-IS), trigger alarm output(-IS)
|
|
General
|
|
Power
|
12 VDC
± 25%, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug, reverse polarity protection
PoE:
IEEE 802.3af, Class 3, max. 7 W
|
|
Material
|
Base:
aluminum, cover: plastic
|
|
Dimension
|
Ø110
mm × 57.4 mm (Ø 4.3" × 2.3")
|
|
Package
Dimension
|
134
mm × 134 mm × 108 mm (5.3" × 5.3" × 4.3")
|
|
Storage
Conditions
|
-30
°C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Startup
and Operating Conditions
|
-30
°C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
General
Function
|
Heartbeat,
mirror, password reset via email, pixel counter, anti-flicker
|
|
Protection
|
IP67
(IEC 60529-2013)
IK8
(IEC 62262:2002)
|
