Camera
|
|
|
Image Sensor
|
1/2.5" Progressive
Scan CMOS
|
|
|
Min. Illumination
|
Color: 0.01 Lux @ (F1.2,
AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR
|
|
|
Shutter Speed
|
1/3 s to 1/100,000 s
|
|
|
Slow Shutter
|
Yes
|
|
|
Auto-Iris
|
No
|
|
|
Day & Night
|
IR Cut Filter
|
|
|
Digital Noise Reduction
|
3D DNR
|
|
|
WDR
|
120dB
|
|
|
3-Axis Adjustment
|
Pan: 0° to 355°, tilt: 0°
to 90°, rotate: 0° to 355°
|
|
|
Lens
|
|
|
Focal Length
|
2.8 to 12 mm
|
|
|
Aperture
|
F1.6
|
|
|
Focus
|
Auto
|
|
|
FOV
|
Horizontal field of view:
105°to 34.5°
Vertical field of view:
55°to 19°
Diagonal field of view:
125°to 40°
|
|
|
Lens Mount
|
Φ14
|
|
|
IR
|
|
|
IR Range
|
Up to 50 m
|
|
|
Wavelength
|
850nm
|
|
|
Compression
Standard
|
|
|
Video Compression
|
Main stream: H.265 / H.264
Sub-stream: H.265 / H.264 /
MJPEG
Third stream: H.265 / H.264
|
|
|
H.264 Type
|
Main Profile / High Profile
|
|
|
H.264+
|
Main stream supports
|
|
|
H.265 Type
|
Main Profile
|
|
|
H.265+
|
Main stream supports
|
|
|
Video Bit Rate
|
256 Kbps to 16 Mbps
|
|
|
Audio Compression
|
G.711 / G.722.1 / G.726 / MP2L2
/ PCM
|
|
|
Audio Bit Rate
|
64Kbps(G.711) / 16Kbps(G.722.1)
/ 16Kbps(G.726) / 32-192Kbps(MP2L2)
|
|
|
Smart
Feature-set
|
|
|
Behavior Analysis
|
Line crossing detection,
intrusion detection
|
|
|
Face Detection
|
Yes
|
|
|
Region of Interest
|
Support 1 fixed region for
main stream and sub-stream
|
|
|
|
|
|
Max. Resolution
|
3072 × 2048
|
|
|
Main Stream
|
50Hz: 12.5 fps (3840 ×
2160), 20fps (3072 × 1728), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60Hz: 15 fps (3840 × 2160), 20fps (3072 × 1728), 30 fps (2560 × 1440, 1920 ×
1080, 1280 × 720)
|
|
|
Sub-Stream
|
50Hz: 25fps (640 × 480, 640
× 360, 320 × 240)
60Hz: 30fps (640 × 480, 640
× 360, 320 × 240)
|
|
|
Third Stream
|
50Hz: 25fps (1280 × 720,
640 × 360, 352 × 288)
60Hz: 30fps (1280 × 720,
640 × 360, 352 × 240)
|
|
Image Enhancement
|
BLC/3D DNR/HLC
|
|
Image Settings
|
Saturation, brightness,
contrast, sharpness adjustable by client software or web browser
|
|
Target Cropping
|
No
|
|
Day / Night Switch
|
Day / Night / Auto / Schedule
/ Triggered by Alarm In
|
|
Network
|
|
Network Storage
|
Support Micro SD / SDHC / SDXC
card (128G), local storage and NAS (NFS, SMB / CIFS), ANR
|
|
Alarm Trigger
|
Motion detection, video
tampering, network disconnected, IP address conflict, illegal login, HDD
full, HDD error
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS,
FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP,
802.1X, QoS, IPv6, Bonjour
|
|
General Function
|
One-key reset,
anti-flicker, three streams, heartbeat, password protection, privacy mask,
watermark, IP address filter
|
|
API
|
ONVIF (PROFILE S, PROFILE
G), ISAPI
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
User/Host
|
Up to 32 users
3 levels: Administrator,
Operator and User
|
|
Client
|
iVMS-4200, Hik-Connect,
iVMS-5200
|
|
Interface
|
|
Audio
|
1 input (line in, 3.5 mm),
1 output (line out, 3.5 mm), mono sound
|
|
Alarm
|
1 input, 1 output
|
|
Communication Interface
|
1 RJ45 10M/100M
self-adaptive Ethernet port
|
|
Video Output
|
1Vp-p composite output (75
Ω/BNC) (For adjustment only)
|
|
On-board storage
|
Built-in Micro SD / SDHC / SDXC
slot, up to 128 GB
|
|
SVC
|
H.264 and H.265 encoding
support
|
|
Reset Button
|
Yes
|
|
Audio
|
|
Environment Noise Filtering
|
Yes
|
|
Audio Sampling Rate
|
8kHz / 16kHz / 32kHz / 44.1kHZ
/ 48kHz
|
|
General
|
|
Operating Conditions
|
-30 °C to +60 °C (-22 °F to
+140 °F), humidity 95% or less (non-condensing)
|
|
Power Supply
|
12 VDC ± 25%, PoE (802.3at,
class 4), Φ 5.5 mm coaxial power plug
|
|
Power Consumption and
Current
|
12 VDC, 1.2A, max. 14.5W
PoE (802.3at, 42.5V to
57V), 0.5A to 0.3A, max. 18W
|
|
Protection Level
|
IP66, IK10
|
|
Material
|
Metal
|
|
Dimensions
|
Φ144.1 × 332.7 mm
(Φ5.7" × 13.1")
|
|
Weight
|
Camera: 1893 g (4.2 lb.)
|
