Camera |
Image Sensor | 1/2.5" Progressive Scan CMOS |
Min. Illumination | Color: 0.01Lux @ (F1.2, AGC ON), 0.034Lux @ (F2.2, AGC ON), 0 Lux with IR on |
Shutter Speed | 1/3 s to 1/100,000 s |
Lens | 1.05 mm @ F2.2, horizontal field of view: 180°, vertical field of view: 180° |
Lens Mount | M12 |
Day &Night | IR cult filter with auto switch |
DNR | 3D DNR |
Wide Dynamic Range | 120 dB |
Compression Standard |
Video Compression | Main stream: H.265, H.265+, H.264+, H.264 Sub-stream: H.265 /H.264 /MJPEG |
H.264 Type | Main Profile /High Profile |
H.264+ | Support |
H.265 Type | Main Profile |
H.265+ | Support |
Video Bit Rate | 32 Kbps to 16 Mbps |
Image |
Max. Resolution | 2560 × 1920 |
Main Stream Max. Frame Rate | 50Hz: 25fps (2560 × 1920, 2048 × 1536, 1280 × 960) 60Hz: 30fps (2560 × 1920, 2048 × 1536, 1280 × 960) |
Sub-Stream Max. Frame Rate | 50Hz: 25fps (352× 288, 704 × 576) 60Hz: 30fps (352 × 240, 704 × 576) |
Image Settings | Saturation, brightness, contrast, and sharpness are adjustable via client software or web browser |
Image Enhancement | WDR /3D DNR /Backlight Compensation /Defog |
Region of Interest | Support 1 fixed region for main stream and sub-stream |
Lens Distortion Correction | Support |
Live View Display |
Mount Type | Support table, wall, and ceiling |
Display Mode | Support 14 display modes in total (including display modes of different mount types): Fisheye View, 180 Panorama View, 4PTZ, Fisheye + 3PTZ, 360 Panorama View, 360 Panorama + PTZ, 360 Panorama + 3PTZ, 360 Panorama + 6PTZ, 360 Panorama + 8PTZ, 2PTZ, Fisheye + 8PTZ, Panorama View, Panorama + 3PTZ, Panorama + 8PTZ |
Network |
Network Storage | NAS (Support NFS,SMB/CIFS), built-in microSD /SDHC /SDXC card slot, up to 128 G, ANR |
Detection | Motion detection, dynamic analysis, intrusion detection, line crossing detection |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 |
Standard | ONVIF (PROFILE S, PROFILE G), ISAPI |
General Function | One-key reset, anti-flicker, password protection, privacy mask, IP Address filtering, heartbeat, watermark |
Interface |
Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
On-board Storage | Built-in microSD/ SDHC /SDXC slot, up to 128 G |
General |
Operating Conditions | -10 °C to +50 °C (-14 °F to +122 °F), Humidity 95% or less (non-condensing) |
Power Supply | 12 VDC, 0.5 A, max. 6 W PoE (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max. 7.5 W |
IR Range | Up to 8 m |
Dimensions | Φ 119.9 × 41.2 mm (Φ 4.72″ × 1.62″) |
