Camera
|
|
Sensor
|
1/2.7"
Progressive Scan CMOS
|
|
Max.
Resolution
|
2560
× 1920
|
|
Shutter
Time
|
1/3
s to 1/100,000 s
|
|
Min.
Illumination
|
Color:
0.017 Lux @ (F2.25, AGC ON), B/W: 0 Lux with IR
|
|
Day
& Night
|
IR
cut filter
|
|
Lens
|
|
Lens
Type
|
Fixed
focal lens, 1.05 mm
|
|
Focal
Length & FOV
|
1.05
mm, horizontal FOV: 180°, vertical FOV: 180°, diagonal FOV: 180°
|
|
Lens
Mount
|
M12
|
|
Focus
|
Fixed
|
|
Iris
Type
|
Fixed
|
|
Aperture
|
F2.25
|
|
Depth
of Field
|
0.1
m to ∞
|
|
DORI
|
|
DORI
|
D:
21 m, O: 8 m, R: 4 m, I: 2 m
|
|
Illuminator
|
|
Supplement
Light Type
|
IR
|
|
Supplement
Light Range
|
Up
to 8 m
|
|
Smart
Supplement Light
|
Yes
|
|
IR
Wavelength
|
850
nm
|
|
Video
|
|
Main
Stream
|
50
Hz: 25 fps（2560
× 1920, 2048 × 1536, 1280 × 960）
60
Hz: 30 fps（2560
× 1920, 2048 × 1536, 1280 × 960）
|
|
Sub-Stream
|
50
Hz: 25 fps (640 × 480)
60
Hz: 30 fps (640 × 480)
|
|
Video
Compression
|
Main
stream: H.265+ / H.265 / H.264+ / H.264,
Sub-stream:
H.265 / H.264 / MJPEG
|
|
Video
Bit Rate
|
32
Kbps to 16 Mbps
|
|
H.264
Type
|
Baseline
Profile, Main Profile, High Profile
|
|
H.265
Type
|
Main
Profile
|
|
Region
of Interest (ROI)
|
1
fixed region for main stream
|
|
Fisheye Display
|
|
Mount
Type
|
Support
wall / table / ceiling mounting
|
|
Audio
|
|
Audio
Type
|
Mono
sound
|
|
Audio
Compression
|
G.711ulaw
/ G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC
|
|
Audio
Sampling Rate
|
8
kHz/16 kHz
|
|
Environment
Noise Filtering
|
Yes
|
|
Network
|
|
Protocols
|
TCP/IP,
ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,
SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
|
|
Client
|
iVMS-4200,
Hik-Connect, Hik-Central
|
|
Network
Storage
|
NAS
(NFS, SMB/CIFS)
|
|
|
|
Settings
|
Rotate
mode, saturation, brightness, contrast, sharpness, white balance, adjustable
by client software or web browser
|
|
Day/Night
Switch
|
Day,
Night, Auto, Schedule
|
|
Enhancement
|
BLC,
3D DNR
|
|
Wide
Dynamic Range (WDR)
|
120
dB
|
|
Interface
|
|
Ethernet
Interface
|
1
RJ45 10 M/100 M self-adaptive Ethernet port
|
|
On-Board
Storage
|
Built-in
memory card slot, support microSD / microSDHC / microSDXC card, up to 256 GB
|
|
Built-in
Microphone
|
-U:
Yes
|
|
Audio
|
1
input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp,
input impedance: 4.7 KΩ, interface type: non-equilibrium,
1
output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp,
output impedance: 100 Ω, interface type: non-equilibrium
|
|
Alarm
|
1
input, 1 output (max. 12 VDC, 30 mA)
|
|
Reset
Key
|
Yes
|
|
Power
Output
|
12
VDC, max. 100 mA
|
|
Event
|
|
Basic
Event
|
Motion
detection, video tampering alarm, exception
|
|
Smart
Event
|
Line
crossing detection, intrusion detection
|
|
Linkage
|
Upload
to FTP/NAS/memory card, notify surveillance center, send email, trigger
recording, trigger capture, trigger alarm output
|
|
General
|
|
Power
|
12
VDC ± 25%, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug, reverse polarity
protection,
PoE:
IEEE 802.3af, Class 3, max. 7.5 W
|
|
Material
|
ADC12
|
|
Dimension
|
Ø119.9
mm × 41.2 mm (Ø4.7" × 1.6")
|
|
Package
Dimension
|
150
mm × 125 mm × 99 mm (5.9" × 4.9" × 3.9")
|
|
Weight
|
Approx.
320 g (0.7 lb.)
|
|
With
Package Weight
|
Approx.
500 g (1.1 lb.)
|
|
Storage
Conditions
|
-10
°C to 50 °C (-14 °F to 122 °F). Humidity 95% or less (non-condensing)
|
|
Approval
|
|
|
EMC
|
CE-EMC:
EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4:
2011 +A1: 2014
RCM:
AS/NZS CISPR 32: 2015 IC: ICES-003: Issue 7
KC:
KN32: 2015, KN35: 2015
|
|
|
Safety
|
UL:
UL 62368-1
CB:
IEC 62368-1: 2014+A11
CE-LVD:
EN 62368-1: 2014/A11: 2017
BIS:
IS 13252 (Part 1): 2010/IEC 60950-1: 2005
LOA:
IEC/EN 60950-1
|
|
|
Environment
|
CE-RoHS:
2011/65/EU
|
|
