Camera
|
|
Image Sensor
|
1/2.8" Progressive Scan
CMOS
|
|
Max. Resolution
|
1920 × 1080
|
|
Min. Illumination
|
Colour: 0.002 Lux @ (F1.4, AGC
ON), B/W: 0 Lux with IR
|
|
Shutter Time
|
1/3 s to 1/100,000 s
|
|
Day & Night
|
IR cut filter
|
|
Angle Adjustment
|
Pan: 0° to 360°, tilt: 0° to
90°, rotate: 0° to 360°
|
|
Lens
|
|
Lens Type
|
Fixed focal lens, 4 mm
|
|
Focal Length & FOV
|
4 mm, horizontal FOV 86°, vertical
FOV 47°, diagonal FOV 102°
|
|
Lens Mount
|
M12
|
|
Iris Type
|
Fixed
|
|
Aperture
|
F1.4
|
|
Depth of Field
|
4 mm: 1.2 m to ∞
|
|
DORI
|
|
DORI
|
4 mm: D: 53 m, O: 21 m, R: 11
m, I: 5 m
|
|
Illuminator
|
|
Supplement Light Type
|
IR
|
|
Supplement Light Range
|
2I: Up to 60 m
|
|
Smart Supplement Light
|
Yes
|
|
IR Wavelength
|
850 nm
|
|
Video
|
|
Main Stream
|
50 Hz: 25 fps (1920 × 1080,
1280 × 720)
60 Hz: 30 fps (1920 × 1080,
1280 × 720)
|
|
Sub-Stream
|
50 Hz: 25 fps (640 × 480, 640
× 360)
60 Hz: 30 fps (640 × 480, 640
× 360)
|
|
Third Stream
|
50 Hz: 10 fps (1920 × 1080,
1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080,
1280 × 720, 640 × 480, 640 × 360),
*Third stream is supported under
certain settings.
|
|
Video Compression
|
Main stream: H.265 / H.264 /
H.264+ / H.265+,
Sub-stream: H.265 / H.264 /
MJPEG,
Third stream: H.265 / H.264,
*Third stream is supported under
certain settings.
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
H.264 Type
|
Baseline Profile, Main Profile,
High Profile
|
|
H.265 Type
|
Main Profile
|
|
Bit Rate Control
|
CBR, VBR
|
|
Scalable Video Coding (SVC)
|
H.264 and H.265 encoding
|
|
Region of Interest (ROI)
|
1 fixed region(s) for main stream
and sub-stream
|
|
Network
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS, FTP,
DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP,
Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
API
|
Open Network Video Interface
(Profile S, Profile G, Profile T), ISAPI, SDK
|
|
Smooth Streaming
|
Yes
|
|
Security
|
Password protection, complicated
password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP,
EAP-MD5), watermark, IP address filter, basic and digest authentication for
HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP
over HTTPS, control timeout settings, security audit log, TLS 1.3, host authentication (MAC address)
|
|
Network Storage
|
NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR),
Together with high-end Hikvision
memory card, memory card encryption and health detection are supported.
|
|
|
|
Image Parameters Switch
|
Yes
|
|
Image Settings
|
Rotate mode, saturation, brightness,
contrast, sharpness, gain, white balance, adjustable by client software or web
browser
|
|
Day/Night Switch
|
Day, Night, Auto, Schedule
|
|
Wide Dynamic Range (WDR)
|
120 dB
|
|
SNR
|
≥ 52 dB
|
|
Image Enhancement
|
BLC, HLC, 3D DNR
|
|
Privacy Mask
|
Yes
|
|
Interface
|
|
Ethernet Interface
|
1 RJ45 10 M/100 M self-adaptive
Ethernet port
|
|
On-Board Storage
|
Built-in memory card slot, support
microSD / microSDHC / microSDXC card, up to 256 GB
|
|
Reset Key
|
Yes
|
|
Event
|
|
Basic Event
|
Motion detection (support alarm
triggering by specified target types (human and vehicle)), video tampering alarm,
exception
|
|
Smart Event
|
Line crossing detection, intrusion
detection, region entrance detection, region exiting detection (support alarm triggered by specified
target types (human and vehicle)), Scene change detection
|
|
Linkage
|
Upload to FTP/NAS/memory card,
notify surveillance centre, send email, trigger recording, trigger capture
|
|
Deep
Learning Function
|
|
Face Capture
|
Yes
|
|
General
|
|
Power
|
2I:
12 VDC ± 25%, 0.63 A, max. 7.6
W, Ø5.5 mm coaxial power plug, reverse polarity protection,
PoE: 802.3af, Class 3, 36 V
to 57 V, 0.25 A to 0.16 A, max. 9 W;
|
|
Material
|
Front cover: metal, back cover:
metal
|
|
Dimension
|
289 mm × 93.1 mm × 91.2 mm (11.4"
× 3.7" × 3.6")
|
|
Package Dimension
|
386 mm × 156 mm × 155 mm (15.2"
× .1" × 6.1")
|
|
Weight
|
Approx. 1020 g (2.2 lb.)
|
|
With Package Weight
|
Approx. 1629 g (3.6 lb.)
|
|
Storage Conditions
|
-30 °C to 60 °C (-22 °F to 140
°F). Humidity 95% or less (non-condensing)
|
|
Startup and Operating Conditions
|
-30 °C to 60 °C (-22 °F to 140
°F). Humidity 95% or less (non-condensing)
|
|
General Function
|
Heartbeat, anti-flicker, mirror,
flash log, password reset via email, pixel counter
|
|
Approval
|
|
EMC
|
FCC: 47 CFR Part 15, Subpart
B,
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019,
EN 61000-3-3: 2013+A1:2019, EN
50130-4: 2011 +A1: 2014,
KC: KN32: 2015, KN35: 2015
|
|
Safety
|
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11:
2017,
LOA: IEC/EN 60950-1
|
|
Environment
|
CE-RoHS: 2011/65/EU, WEEE:
2012/19/EU,
Reach: Regulation (EC) No 1907/2006
|
|
Protection
|
IP67: IEC 60529-2013
|
