Camera
|
|
Image Sensor
|
1/2.9" Progressive Scan CMOS
|
|
Max. Resolution
|
2688 × 1520
|
|
Min. Illumination
|
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with light
|
|
Shutter Time
|
1/3 s to 1/100,000 s
|
|
Day & Night
|
IR cut filter
|
|
Angle Adjustment
|
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
|
|
Lens
|
|
Lens Type
|
Fixed focal lens, 2.8, 4, and 6 mm optional
|
|
Focal Length & FOV
|
4 mm, horizontal FOV 84°, vertical FOV 45°, diagonal FOV 100°
|
|
Lens Mount
|
M12
|
|
Iris Type
|
Fixed
|
|
Aperture
|
F1.6
|
|
Depth of Field
|
4 mm: 1.5 m to ∞
|
|
DORI
|
|
DORI
|
4 mm, D: 78 m, O: 31 m, R: 15 m, I: 7 m
|
|
Illuminator
|
|
Supplement Light Type
|
IR, White Light
|
|
Supplement Light Range
|
up to 80 m
|
|
Smart Supplement Light
|
Yes
|
|
IR Wavelength
|
850 nm
|
|
Video
|
|
Main Stream
|
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
|
|
Sub-Stream
|
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
|
|
Third Stream
|
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings.
|
|
Video Compression
|
Main stream: H.265 / H.264 / H.264+ / H.265+,
Sub-stream: H.265 / H.264 / MJPEG,
Third stream: H.265 / H.264,
*Third stream is supported under certain settings.
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
H.264 Type
|
Baseline Profile, Main Profile, High Profile
|
|
H.265 Type
|
Main Profile
|
|
Scalable Video Coding (SVC)
|
H.264 and H.265 encoding
|
|
Bit Rate Control
|
CBR, VBR
|
|
Region of Interest (ROI)
|
1 fixed region for main stream and sub-stream
|
|
Target Cropping
|
Yes
|
|
Network
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
|
|
Security
|
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2/1.3, WSSE and digest authentication for Open Network Video Interface
|
|
Network Storage
|
NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
|
|
|
|
Image Parameters Switch
|
Yes
|
|
Day/Night Switch
|
Day, Night, Auto, Schedule
|
|
Wide Dynamic Range (WDR)
|
120 dB
|
|
SNR
|
≥ 52 dB
|
|
Image Enhancement
|
BLC, HLC, 3D DNR
|
|
Privacy Mask
|
8 programmable polygon privacy masks
|
|
Interface
|
|
Ethernet Interface
|
1 RJ45 10 M/100 M self-adaptive Ethernet port
|
|
On-Board Storage
|
Built-in memory card slot, support microSD / microSDHC / microSDXC card, up to 512 GB
|
|
Reset Key
|
Yes
|
|
Event
|
|
Basic Event
|
Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception
|
|
Linkage
|
Upload to FTP / NAS / memory card, notify surveillance center, send email, trigger recording, trigger capture
|
|
Deep Learning Function
|
|
Perimeter Protection
|
Line crossing, intrusion
Support alarm triggering by specified target types (human and vehicle)
|
|
General
|
|
Power
|
12 VDC ± 25%, 0.83 A, max. 10 W, Ø5.5 mm coaxial power plug, reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max.11 W
|
|
Material
|
Metal
|
|
Dimension
|
88.7 mm × 93.1 mm × 286.7 mm (3.5" × 3.7" × 11.3")
|
|
Package Dimension
|
386 mm × 156 mm × 155 mm (15.2" × 6.1" × 6.1")
|
|
Weight
|
Approx. 1150 g (2.5 lb.)
|
|
With Package Weight
|
Approx. 1640 g (3.6 lb.)
|
|
Storage Conditions
|
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Startup and Operating Conditions
|
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
General Function
|
Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding
|
|
Approval
|
|
EMC
|
CE-EMC: EN 55032:2015+A1: 2020, EN 50130-4:2011+A1: 2014, EN IEC 61000-3-2:2019+A1: 2021,
EN 61000-3-3:2013+A1:2019+A2:2021, RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015
|
|
Safety
|
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,
LOA: IEC/EN 60950-1
|
|
Environment
|
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
|
|
Protection
|
IP67: IEC 60529-2013
|
