Camera
|
|
Image Sensor
|
1/2.5" Progressive
Scan CMOS
|
|
Min. Illumination
|
Color: 0.01 Lux @(F1.2; AGC
ON), 0.028 Lux @(F2.0; AGC ON), 0 lux with IR
|
|
Shutter Speed
|
1/3 s to 1/100,000 s
|
|
Slow Shutter
|
Yes
|
|
Focal length
|
4 mm
|
|
Focus
|
Fixed
|
|
FOV
|
4 mm, horizontal field of
view: 79°
|
|
Lens Mount
|
M12
|
|
Iris
|
F2.0
|
|
Day &Night
|
IR cut filter
|
|
DNR
|
3D DNR
|
|
Wide Dynamic Range
|
120dB
|
|
3-Axis Adjustment (bracket)
|
Pan: 0° to 360°, tilt: 0°
to 100°, rotate: 0° to 360°
|
|
Compression
Standard
|
|
Video Compression
|
Main stream: H.265 / H.264
Sub stream: H.265 / H.264 /
MJPEG
Third stream: H.265 / H.264
|
|
H.264 Type
|
Main Profile / High Profile
|
|
H.264+
|
Main stream supports
|
|
H.265 Type
|
Main Profile
|
|
H.265+
|
Main stream supports
|
|
Video Bit Rate
|
32 Kbps to 16 Mbps
|
|
|
|
Max. Resolution
|
3840 × 2160
|
|
Main Stream
|
50Hz: 20 fps (3840 × 2160),
25 fps (3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
60Hz: 20 fps (3840 × 2160),
30fps (3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
|
|
Sub Stream
|
50Hz: 25fps (640 × 480, 640
× 360, 320 × 240)
60Hz: 30fps (640 × 480, 640
× 360, 320 × 240)
|
|
Third Stream
|
50Hz: 25fps (1280 ×720, 640
× 360, 352 × 288)
60Hz: 30fps (1280 ×720, 640
× 360, 352 × 240)
|
|
Image Enhancement
|
BLC / 3D DNR / HLC
|
|
Image Settings
|
Support rotate mode.
Brightness, contrast, saturation, and sharpness are adjustable via web
browser and client software
|
|
ROI (Region of Interest)
|
Support 1 fixed region for
main stream and sub stream separately
|
|
Day / Night Switch
|
Day / Night / Auto / Schedule
|
|
Network
|
|
Network Storage
|
Support microSD / SDHC / SDXC
card (128G) local storage, NAS (NFS, SMB / CIFS), ANR
|
|
Alarm Trigger
|
Motion Detection, Tampering
Alarm, Network Disconnected, IP Address Conflict, Illegal Login, HDD full,
HDD error
|
|
Protocols
|
TCP / IP, UDP, ICMP, HTTP,
HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP,
RTCP, PPPoE, NTP,
UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
|
|
Standard
|
ONVIF (PROFILE S, PROFILE
G), ISAPI
|
|
General Function
|
One-key Reset, Anti-Flicker,
Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark, IP Address Filter
|
|
API
|
ONVIF (PROFILE S, PROFILE
G), ISAPI
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
User / Host
|
Up to 32 users
3 levels: Administrator,
Operator and User
|
|
Client
|
iVMS-4200, Hik-Connect,
iVMS-5200, iVMS-4500
|
|
Interface
|
|
Communication Interface
|
1 RJ45 10M / 100M
self-adaptive Ethernet port
|
|
On-board Storage
|
Built-in microSD / SDHC / SDXC
slot, up to 128 GB
|
|
Reset Button
|
Yes
|
|
Smart
Feature-set
|
|
Behavior Analysis
|
Line crossing detection,
intrusion detection, unattended baggage detection, object removal detection
|
|
Exception Detection
|
Scene change detection
|
|
Line Crossing Detection
|
Cross a pre-defined virtual
line, up to 1 pre-defined virtual lines supported
|
|
Intrusion Detection
|
Enter and loiter in a
pre-defined virtual region, up to 1 pre-defined virtual regions supported
|
|
Object Removal Detection
|
Objects removed from the
pre-defined region, such as the exhibits on display.
|
|
Unattended Baggage
Detection
|
Objects left over in the
pre-defined region such as the baggage, purse, dangerous materials
|
|
Face Detection
|
Human face appears in the
image can be detected and trigger linkage method
|
|
General
|
|
Operating Conditions
|
-30 °C to +60 °C (-22 °F to
+140 °F), Humidity 95% or less (non-condensing)
|
|
Power Supply
|
12 VDC ± 25%, PoE(802.3af
36 – 57 V, class 3)
|
|
Power Consumption
|
-I5: 12 VDC ± 25%, 7.5W;
PoE, 9.5W
-I8: 12 VDC ± 25%, 10 W;
PoE, 12.5W
|
|
IR Range
|
Up to 80 m
|
|
Protection Level
|
IP67
|
|
Dimensions
|
Camera: Φ104.8 × 299.7 mm
(Φ4.13″ × 11.8″) Package: 386 × 156 × 155 mm (15.2″ × 6.14″ × 6.1″)
|
|
Weight
|
1200 g (2.65 lb.)
|
