Camera
|
Sensor
|
1/1.2"
Progressive Scan CMOS
|
Max.
Resolution
|
3840
× 2160
|
Min.
Illumination
|
Color:
0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
|
Shutter
Time
|
1/3
s to 1/100,000 s
|
Angle
Adjustment
|
Pan:
0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
|
Day
& Night
|
24/7
color imaging
|
Lens
|
Lens
Type
|
Fixed
focal lens, 4mm
|
Focal
Length & FOV
|
4 mm,
horizontal FOV 88°, vertical FOV 47°, diagonal FOV 104°
|
Iris
Type
|
Fixed
|
Lens
Mount
|
M
mount
|
Aperture
|
F1.0
|
Depth
of Field
|
4
mm: 7 m to ∞
|
DORI
|
DORI
|
4
mm: D: 102 m, O: 40 m, R: 20 m, I: 10 m
|
Illuminator
|
Supplement
Light Type
|
White
Light
|
Supplement
Light Range
|
60 m
|
Smart
Supplement Light
|
Yes
|
Video
|
Main
Stream
|
50 Hz:
25 fps
(3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
24 fps
(3840 × 2160)
30 fps
(3200 x 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
|
Sub-Stream
|
50 Hz:
25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz:
30 fps (1280 × 720, 640 × 480, 640 × 360)
|
Third
Stream
|
50 Hz:
10 fps (1920 x 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz:
10 fps (1920 x 1080, 1280 × 720, 640 × 480, 640 × 360)
|
Video
Compression
|
Main
stream: H.265 / H.264 / H.264+ / H.265+
Sub-stream:
H.265 / H.264
Third
stream: H.265 / H.264
|
Video
Bit Rate
|
32 Kbps
to 16 Mbps
|
H.264
Type
|
Baseline
Profile / Main Profile / High Profile
|
H.265
Type
|
Main
Profile
|
Bit
Rate Control
|
CBR/VBR
|
Scalable
Video Coding (SVC)
|
Yes
|
Region
of Interest (ROI)
|
1 fixed
region for main stream and sub-stream
|
Network
|
Protocols
|
TCP/IP,
ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X,
QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
|
Simultaneous
Live View
|
Up to
6 channels
|
User/Host
|
Up to
32 users. 3 user levels: administrator, operator and user
|
|
Parameters Switch
|
Yes
|
Settings
|
Rotate,
mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white
balance adjustable by client software or web browser
|
Day/Night
Switch
|
Day,
Night, Auto, Schedule
|
Wide
Dynamic Range (WDR)
|
130
dB
|
SNR
|
≥ 52 dB
|
Enhancement
|
BLC,
HLC, 3D DNR
|
Privacy
Mask
|
4 regions
of privacy mask
|
Interface
|
Ethernet
Interface
|
1 RJ45
10 M/100 M self-adaptive Ethernet port
|
On-Board
Storage
|
Built-in
memory card slot, support microSD / microSDHC / microSDXC/TF card, up to 512GB
|
Reset
Key
|
Yes
|
Built-in
Microphone
|
Yes
|
Built-in
Speaker
|
2 W,
10 cm: 97 dB
|
Audio
|
1 input
(line in), max. input amplitude: 3.3 Vpp, input impedance:4.7 KΩ, interface
type: non-equilibrium
1 output
(line out), max.output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface
type: non-equilibrium
|
Alarm
|
1 input,
1 output (max. 24 VDC, 1 A)
|
Event
|
Basic
Event
|
Motion
detection (support alarm triggering by specified target types (human and
vehicle)), video tampering alarm, exception (network disconnected, IP address
conflict, illegal login, HDD full, HDD error)
|
Smart
Event
|
Line
crossing detection, intrusion detection, region entrance detection, region exiting
detection (support alarm triggering by specified target types (human and vehicle)),
scene change detection
|
Linkage
|
Upload
to NAS / memory card / FTP, notify surveillance center, trigger record, trigger
capture, send email
|
Deep Learning Function
|
Face
Capture
|
Yes
|
General
|
Power
|
12
VDC ± 25%, 0.84 A, max. 11.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection
PoE:
802.3af, Class 3, 36 V to 57 V, 0.32 A to 0.21 A
|
Material
|
Front
cover: metal, body: metal, bracket: metal
|
Dimension
|
289.9
mm × 93.5 mm × 91.2 mm (11.4" × 3.7" × 3.6")
|
Package
Dimension
|
386
× 156 × 155 mm (15.2" × 6.1" × 6.1")
|
Weight
|
Approx.
1255 g (2.6 lb.)
|
With
Package Weight
|
Approx.
1769 g (3.7 lb.)
|
Storage
Conditions
|
-30
°C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
Startup
and Operating Conditions
|
-30
°C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
General
Function
|
Anti-flicker,
heartbeat, password reset via e-mail, pixel counter
|
Approval
|
EMC
|
FCC
(47 CFR Part 15, Subpart B);
CE-EMC
(EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN
50130-4:
2011 +A1: 2014);
RCM
(AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 7)
KC (KN32:
2015, KN35: 2015)
|
Safety
|
UL (UL
62368-1);
CB (IEC
62368-1:2014+A11)
CE-LVD
(EN 62368-1:2014/A11:2017)
|
Environment
|
CE-RoHS
(2011/65/EU); WEEE (2012/19/EU);
Reach
(Regulation (EC) No 1907/2006)
|
Protection
|
IP67
(IEC 60529-2013)
|
