Camera
|
|
Sensor
|
1/1.2.7ʺ
Progressive Scan CMOS
|
|
Min.
Illumination
|
Color:
0.005 Lux @ (F1.2, AGC ON), 0.0176 Lux @ (F2.25, AGC ON)
B/W:
0.001 Lux @ (F1.2, AGC ON), 0.0035 Lux @ (F2.2.5, AGC ON)
|
|
Shutter
Speed
|
1/25
s to 1/100,000 s
|
|
Day
& Night
|
IR Cut
Filter
|
|
WDR
|
Digital
WDR
|
|
Lens
|
|
Focal
Length
|
2 mm
fixed lens
|
|
Aperture
|
F2.25
|
|
FOV
|
Horizontal
FOV 104.5°, vertical FOV 70.5°, diagonal FOV 112°
|
|
Lens
Mount
|
M12
|
|
IR
|
|
IR
Range
|
Up to
6 m IR range
|
|
Wavelength
|
850
nm
|
|
Video
|
|
Max.
Resolution
|
1920
× 1080
|
|
Main
Stream
|
50Hz:
25fps (1920 × 1080, 1280 × 720); 60Hz: 30fps (1920 × 1080, 1280 × 720)
|
|
Sub
Stream
|
50Hz:
25fps (704 × 576, 640 × 480)
60Hz:
30fps (704 × 480, 640 × 480)
|
|
Video
Compression
|
Main
stream: H.265+ / H.265 / H.264+ / H.264
Sub
stream: H.265 / H.264 / MJPEG
|
|
H.264
Type
|
Baseline
Profile / Main Profile / High Profile
|
|
H.264+
|
Main
stream supports
|
|
H.265
Type
|
Main
Profile
|
|
H.265+
|
Main
stream supports
|
|
Video
Bit Rate
|
32 Kbps
to 16 Mbps
|
|
SVC
|
H.265
and H.264 support
|
|
Audio
|
|
Audio
Compression
|
G.711
/ G.722.1 / G.726 / MP2L2 / PCM
|
|
Audio
Bit Rate
|
64Kbps
(G.711) / 16Kbps (G.722.1) / 16Kbps (G.726) / 32-160Kbps (MP2L2)
|
|
Environment
Noise Filtering
|
Yes
|
|
Audio
Sampling Rate
|
8kHz
/ 16kHz / 32kHz / 44.1kHz / 48kHz
|
|
Smart Feature-Set
|
|
Basic
Event
|
Motion
detection, video tampering alarm, exception (network disconnected, IP address
conflict, illegal login, HDD full, HDD error)
|
|
People
Counting
|
Counts
people entering and exiting separately
Supports
real-time uploading and uploading by statistic cycle Sends email reports on daily,
weekly, monthly or annually basis
Supports
target filtering by height
|
|
Linkage
Method
|
Upload
to FTP/NAS, notify surveillance center, send email, trigger alarm output, trigger
recording, trigger capture
|
|
Region
of Interest
|
4 fixed
regions for main stream and sub-stream
|
|
|
|
Enhancement
|
HLC,
BLC, 3D DNR, defog
|
|
Setting
|
Saturation,
brightness, contrast, sharpness is adjustable by client software or web browser
|
|
Day/Night
Switch
|
Day
/ Night / Auto / Schedule / Triggered by alarm input (-S)
|
|
Overlay
|
LOGO
picture can be overlaid on video with 128 × 128 24bit bmp format
|
|
Network
|
|
Protocols
|
TCP/IP,
ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP,
SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
|
|
API
|
ONVIF
(PROFILE S, PROFILE G), ISAPI, SDK, Ehome (5.0)
|
|
Security
|
Password
protection, complicated password, HTTPS encryption, 802.1X authentication
(EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS,
WSSE and digest authentication for ONVIF, RTP/RTSP over HTTPS, control timeout
settings, security audit log
|
|
User/Host
|
Up to
32 users. 3 user levels: administrator, operator and user
|
|
Interface
|
|
Communication
Interface
|
1 RJ45
10M/100M Ethernet port,
-S:
1 RS-485 interface (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
|
|
Audio
|
1 Built-in
Mic
-S:
1 input (line in, two-core terminal block), 1 output (two-core terminal block),
mono sound
|
|
Alarm
(-S)
|
1 input,
1 output (max. 24 VDC, 1 A)
|
|
On-board
storage
|
300
M eMMC storage for people counting data
|
|
General
|
|
General
Function
|
Anti-flicker,
heartbeat, mirror, password protection, watermark, IP address filter
|
|
Startup
and Operating Conditions
|
-30
°C to +45 °C (-22 °F to +113 °F), Humidity 95% or less (non-condensing)
|
|
Storage
Conditions
|
-30
°C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
|
|
Power
Supply
|
12 VDC±20%,
reverse polarity protection, Φ5.5mm coaxial power plug
12 VDC,
PoE (36 to 57 VDC, 802.3af), Calss3
|
|
Power
Consumption
|
12 VDC,
0.66 A, max. 8 W, PoE (802.3 af, 36 to 57 VDC), 0.23 A to 0.14 A, max. 8.3 W
|
|
Material
|
Front
cover: plastic, camera body: metal
|
|
Dimensions
|
With
-V: 168 mm × 61 mm × 41 mm (6.6" × 2.4" × 1.6" )
Without
-V: 168 mm × 61 mm × 36 mm (6.6" × 2.4" × 1.4")
With
Package: 235 mm × 120 mm × 125 mm (9.2" × 4.7" × 4.9")
|
|
Weight
|
Camera:
Approx. 435 g (1 lb.)
With
package: 725 g (1.6 lb)
|
|
Approval
|
|
EMC
|
47 CFR
Part 15, Subpart B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013,
EN 50130-4:
2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: Issue 6, 2016; KN 32: 2015, KN
35: 2015
|
|
Safety
|
UL 60950-1,
IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am 1:2009 + Am 2:2013,
IS 13252 (Part 1): 2010+A1: 2013+A2: 2015
|
|
Environment
|
2011/65/EU,
2012/19/EU, Regulation (EC) No 1907/2006
|
