Camera
|
|
Image Sensor
|
1/1.8″ Progressive Scan
CMOS
|
|
Min. Illumination
|
Color: 0.002 Lux @ (F1.2,
AGC ON), 0 Lux with IR
|
|
Shutter Speed
|
1 s to 1/100,000 s
|
|
Slow Shutter
|
Yes
|
|
Day & Night
|
IR Cut Filter
|
|
Digital Noise Reduction
|
3D DNR
|
|
WDR
|
140 dB
|
|
Angle Adjustment
|
Bracket, pan: 0° to 355°,
tilt: 0° to 90°, rotate: 0° to 360°
|
|
Lens
|
|
Focal length
|
2.8 to 12 mm
|
|
Aperture
|
2.8 to 12 mm: F1.2
|
|
Focus
|
Auto, semi-auto, manual
|
|
FOV
|
2.8 to 12 mm: horizontal
FOV 103.3° to 38.6°, vertical FOV 54.2° to 21.9°, diagonal FOV 124.2° to
44.3°
|
|
Lens Mount
|
Integrated
|
|
IR
|
|
IR Range
|
2.8 to 12 mm: up to 50 m
|
|
Wavelength
|
850 nm
|
|
Compression
Standard
|
|
|
Video Compression
|
Main stream: H.265 / H.264
/ H.265+ / H.264+
Sub stream / third stream /
fourth stream / fifth stream / custom stream: H.265 / H.264 / MJPEG
|
|
H.264 Type
|
Baseline Profile / Main
Profile / High Profile
|
|
H.264+
|
Main stream supports
|
|
H.265 Type
|
Main Profile
|
|
H.265+
|
Main stream supports
|
|
Video Bit Rate
|
32 Kbps to 16 Mbps
|
|
Audio Compression
|
No
|
|
Audio Bit Rate
|
No
|
|
Smart
Feature-set
|
|
|
Perimeter Protection
|
Line crossing detection,
intrusion detection, region entrance detection, region exiting detection,
unattended baggage detection, object removal detection
|
|
Exception Detection
|
Scene change detection,
defocus detection
|
|
Statistics
|
No
|
|
Face Detection
|
Yes
|
|
Recognition
|
License Plate Recognition
|
|
Region of Interest
|
4 fixed regions for main
stream, sub stream, third stream, fourth stream, and fifth stream, and
dynamic tracking
|
|
Road
Traffic and Vehicle Detection
|
|
Accuracy
(Under recommended
installation and lighting conditions)
|
Capture rate > 98%
Vehicle moving direction
recognition accuracy > 96% Mistaken capture rate < 2% (entrance / exit),
< 5% (checkpoint)
|
|
Blacklist and whitelist
|
Max. 10,000 records
|
|
No License Plate Detection
|
Yes
|
|
Motorcycle LPR
|
Yes (only applicable to
checkpoint)
|
|
|
|
Max. Resolution
|
1920 × 1080
|
|
Main Stream
|
50Hz: 50fps (1920 × 1080,
1280 × 960, 1280 × 720)
60Hz: 60fps (1920 × 1080,
1280 × 960, 1280 × 720)
|
|
Sub Stream
|
50Hz: 25fps (704 × 576, 640
× 480)
60Hz: 30fps (704 × 480, 640
× 480)
|
|
Third Stream
|
50Hz: 25fps (1920 × 1080,
1280 × 960, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080,
1280 × 960, 1280 × 720, 704 × 480, 640 × 480)
|
|
Fourth Stream
|
50Hz: 25fps (1920 × 1080,
1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080,
1280 × 720, 704 × 480, 640 × 480)
|
|
Fifth Stream
|
50Hz: 25fps (704 × 576, 640
× 480)
60Hz: 30fps (704 × 480, 640
× 480)
|
|
Custom Stream
|
50Hz: 25fps (1920 × 1080,
1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080,
1280 × 720, 704 × 480, 640 × 480)
|
|
Image Enhancement
|
BLC, HLC, 3D DNR, Defog,
EIS, lens distortion correction
|
|
Image Setting
|
Rotate mode, saturation,
brightness, contrast, sharpness, AGC, and white balance are adjustable by
client software or web browser
|
|
Target Cropping
|
Yes
|
|
SVC
|
H.264 and H.265 encoding
|
|
Day / Night Switch
|
Day / Night / Auto / Schedule
/ Triggered by Alarm In / Triggered by
video
|
|
Picture Overlay
|
LOGO picture can be
overlaid on video with 128 × 128 24bit bmp format
|
|
Network
|
|
Network Storage
|
microSD / SDHC / SDXC card
(256 GB), local storage and NAS (NFS, SMB / CIFS), ANR
|
|
Alarm Trigger
|
Motion detection, video
tampering alarm, network disconnected, IP address conflict, illegal login,
HDD full, HDD error, alarm for listed license plate in the blacklist and
whitelist
|
|
Protocols
|
TCP / IP, ICMP, HTTP,
HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP,
IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
|
|
Security Measures
|
Password protection, HTTPS
encryption, IEEE 802.1x port-based network access control, IP address filter,
basic and digest authentication for HTTP / HTTPS, WSSE and digest
authentication for ONVIF
|
|
General Function
|
One-key reset,
anti-flicker, five streams and custom stream, heartbeat, password protection,
privacy mask, watermark, IP address filter
|
|
Interface
|
|
|
Audio
|
No
|
|
Communication Interface
|
1 RJ45 10M / 100M / 1000M
Ethernet port,
1 RS-485 interface (half
duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
|
|
Alarm
|
2 inputs, 2 outputs (up to
24 VDC 1A or 110 VAC 500 mA)
|
|
Video Output
|
1Vp-p composite output (75
Ω / CVBS)
|
|
On-board storage
|
Built-in micro SD / SDHC / SDXC
slot, up to 256 GB
|
|
BNC
|
CVBS analog output (4CIF
resolution), internal
|
|
Reset Button
|
Yes
|
|
Audio
|
|
|
Environment Noise Filtering
|
No
|
|
Audio Sampling Rate
|
No
|
|
General
|
|
Operating Conditions
|
-30 °C to 60 °C (-22 °F to
140 °F
Humidity 95% or less
(non-condensing)
|
|
Power Supply
|
12 VDC ± 20%, two-core
terminal block PoE (802.3at, class 4)
|
|
Power Consumption and
Current
|
-IZS: 12 VDC, 1.2 A, max.
14 W; PoE (802.3at, 42.5 V to 57 V), 0.4 A to 0.3 A
|
|
Protection Level
|
IP67, IK10
|
|
Material
|
Aluminum alloy
|
|
Dimensions
|
Camera: Φ140 × 351 mm
(Φ5.5″ × 13.8″)
With package: 405 × 190 ×
180 mm (15.9″ × 7.5″ × 7.1″)
|
|
Weight
|
Camera: approx. 2.5 kg
(5.51 lb.)
With package: approx. 2.75
kg (6.06 lb.)
|
