Camera
|
|
Sensor
|
1/2.8"
progressive scan CMOS
|
|
Min.
Illumination
|
Color:
0.05 Lux @ (F2.0, AGC ON), B/W: 0.005Lux @ (F2.0, AGC ON)
|
|
Day
& Night
|
IR Cut
Filter
|
|
Focus
Mode
|
Auto
|
|
Shutter
Speed
|
1/1
to 1/10,000s
|
|
Digital
Zoom
|
16×
|
|
White
Balance
|
Auto
/ manual / ATW (auto tracing white balance) / indoor / outdoor / daylight lamp
/ sodium lamp
|
|
AGC
|
Auto/Manual
|
|
Backlight
Compensation
|
Yes
|
|
Wide
Dynamic Range
|
Yes
|
|
DNR
(Digital Noise Reduction)
|
Yes
|
|
Privacy
Mask
|
8 programmable
privacy masks
|
|
Lens
|
|
Focal
Length
|
2.8
to 12mm, 4×
|
|
Field
of View
|
100°
to 25° (wide-tele)
|
|
Working
Distance
|
10 to
1500mm (wide-tele)
|
|
Zoom
Speed
|
Approx.
2s (optical lens, wide-tele)
|
|
Aperture
Range
|
F1.8
to F2.5
|
|
Smart
|
|
Smart
Detection
|
Intrusion
detection, line crossing detection, audio exception detection, motion detection,
and video tampering detection
|
|
Smart
Recording
|
Edge
storage, smart search in smart NVR, and VCA playback
|
|
Smart
Image Enhancement
|
HLC
|
|
Smart
Encoding
|
Low
bitrate, and ROI (Region of Interest) encoding
|
|
Smart
Alarm
|
Alarm
for network disconnection, IP address conflict, HDD full, HDD error, and illegal
login
|
|
Network
|
|
Stream
|
Support
three streams
|
|
Main
Stream
|
50Hz:
25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz:
30fps (1920 × 1080, 1280 × 960, 1280 × 720)
|
|
Sub
Stream
|
50Hz:
25fps (704×576, 640×480, 352×288)
60Hz:
30fps (704×480, 640×480, 352×240)
|
|
Three
Stream
|
50Hz:25fps
(1920×1080, 1280×960, 1280×720, 704×576, 640×480, 352×288)
60Hz:
30fps (1920×1080, 1280×960, 1280×720, 704×480, 640×480, 352×240)
|
|
Video
Compression
|
H.265+
/ H.265 / H.264+ / H.264
|
|
Security
Measures
|
User
authentication (ID and PW), host authentication (MAC address), IP address filtering,
HTTPS encryption and IEEE 802.1x port-based network access control
|
|
Pan and Tilt
|
|
Movement
Range
|
Pan:
350°, Tilt: 0° to 90°
|
|
Movement
Speed
|
Pan:
0.1° to 60°/s, Tilt: 0.1°to 50°/s
|
|
Preset
No.
|
300
|
|
Patrol
|
8 patrols,
up to 32 presets per patrol
|
|
Park
Action
|
Preset
/ patrol / auto scan / tilt scan / random scan / frame scan / panorama scan
|
|
Scheduled
Task
|
Preset
/ patrol / auto scan / tilt scan / random scan / frame scan / panorama scan /
dome reboot / dome adjust / aux output
|
|
Proportional
Zoom
|
Yes
|
|
Power-off
Memory
|
Yes
|
|
Position
Display
|
On/
Off
|
|
IR
|
|
IR
Distance
|
Up to
20m
|
|
Smart
IR
|
Yes
|
|
System Integration
|
|
Alarm
I/O
|
1 alarm
input, 1 alarm output
|
|
Alarm
Linkage
|
Alarm
actions, such as Send Email, Notify Surveillance Center, Upload to FTP / Memory
Card / NAS, Trigger Recording etc.
|
|
Audio
I/O
|
1 audio
input, 1 audio output
|
|
Ethernet
|
1 RJ45
10M/100M Ethernet interface
|
|
Memory
Card
|
Built-in
memory card slot, supporting SD/SDHC/SDXC, up to 128GB
|
|
General
|
|
Power
|
DC 12V,
1.0 A, and PoE (802.3af), 36 to 57 VDC, 0.35 A, Class3
Max.:
9W, including max. 4W for IR
|
|
Working
Temperature
|
-10°C
to 50°C (-14°F to 122°F)
|
|
Working
Humidity
|
≤ 90%
|
|
Protection
Level
|
4,000V
lightning protection, and surge protection
|
|
Dimensions(mm)
|
Φ125mm
× 137.2mm (Φ4.9"×5.4")
|
|
Weight
|
Approx.
0.65kg (1.4lb)
|
