Camera Module
|
|
Sensor
|
1/2.8"
Progressive Scan CMOS
|
|
Max.
Resolution
|
2560
× 1440
|
|
Min.
Illumination
|
Color:
0.005 Lux @ (F1.5, AGC ON), B/W: 0.001 Lux @ (F1.5, AGC ON), 0 Lux with IR
|
|
Shutter
Speed
|
1/1
s to 1/30,000 s
|
|
Day
& Night
|
IR cut
filter
|
|
Zoom
|
4x optical,
16x digital
|
|
Slow
Shutter
|
Yes
|
|
Lens
|
|
Focal
Length
|
2.8
to 12 mm
|
|
FOV
|
Horizontal
FOV 96.7° to 31.6°, vertical FOV 51.1° to 17.7°, diagonal FOV 115.1° to 36.3°
|
|
Focus
|
Auto,
semi-auto, manual
|
|
Aperture
|
Max.
F1.5
|
|
Zoom
Speed
|
Approx.
2 s
|
|
Illuminator
|
|
Supplement
Light Type
|
IR
|
|
Supplement
Light Range
|
IR Distance:
up to 20 m
|
|
Smart
Supplement Light
|
Yes
|
|
IR
Wavelength
|
850
nm
|
|
PTZ
|
|
Movement
Range (Pan)
|
0° to
355°
|
|
Movement
Range (Tilt)
|
0° to
90°
|
|
Pan
Speed
|
Pan
speed: configurable from 0.1° to 100°/s; preset speed: 100°/s
|
|
Tilt
Speed
|
Tilt
speed: configurable from 0.1° to 100°/s, preset speed 100°/s
|
|
Proportional
Zoom
|
Yes
|
|
Presets
|
300
|
|
Preset
Freezing
|
Yes
|
|
Park
Action
|
Preset
|
|
3D Positioning
|
Yes
|
|
PTZ
Status Display
|
Yes
|
|
Scheduled
Task
|
Preset,
dome reboot, dome adjust
|
|
Power-off
Memory
|
Yes
|
|
Video
|
|
Main
Stream
|
50 Hz:
25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720);
60 Hz:
30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
|
|
Sub-Stream
|
50 Hz:
25 fps (704 × 576, 640 × 480, 352 × 288);
60 Hz:
30 fps (704 × 480, 640 × 480, 352 × 240)
|
|
Third
Stream
|
50 Hz:
25 fps (704 × 576, 640 × 480, 352 × 288);
60 Hz:
30 fps (704 × 480, 640 × 480, 352 × 240)
|
|
Video
Compression
|
Main
stream: H.265+ / H.265 / H.264+ / H.264
Sub-stream:
H.265 / H.264 / MJPEG
Third
stream: H.265 / H.264 / MJPEG
|
|
H.264
Type
|
Baseline
Profile / Main Profile / High Profile
|
|
H.265
Type
|
Main
profile
|
|
Scalable
Video Coding (SVC)
|
H.264
and H.265 encoding
|
|
Region
of Interest (ROI)
|
8 fixed
regions for each stream
|
|
Network
|
|
Protocols
|
IPv4/IPv6,
HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP,
TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, Websocket, Websockets
|
|
Security
|
Password
protection, complicated password, HTTPS encryption, 802.1X authentication
(EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest
authentication for HTTP/HTTPS, control timeout settings, security audit log,
TLS 1.2, host authentication (MAC address)
|
|
Network
Storage
|
NAS
(NFS, SMB/CIFS), auto network replenishment (ANR)
|
|
|
|
Parameters Switch
|
Yes
|
|
Settings
|
Saturation,
brightness, contrast, sharpness, gain, and white balance adjustable by client
software or web browser
|
|
Day/Night
Switch
|
Day,
Night, Auto, Schedule
|
|
Wide
Dynamic Range (WDR)
|
120
dB
|
|
SNR
|
>52dB
|
|
Defog
|
Digital
defog
|
|
Enhancement
|
BLC,
HLC, 3D DNR
|
|
Privacy
Mask
|
24 programmable
polygon privacy masks, mask color or mosaic configurable
|
|
Regional
Focus
|
Yes
|
|
Regional
Exposure
|
Yes
|
|
Interface
|
|
Ethernet
Interface
|
1 RJ45
10M/100M self-adaptive Ethernet port
|
|
On-board
Storage
|
Built-in
memory card slot, support microSD / SDHC / SDXC card, up to 256 GB
|
|
Built-in
Microphone
|
1 built-in
microphone, picking up sounds in the radius up to 5 meters
|
|
Audio
|
1 input
(line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%;
1 output
(line out), line level, output impedance: 600 Ω
|
|
Reset
|
Yes
|
|
Power
Output
|
12 VDC,
max. 60 mA
|
|
Event
|
|
Basic
Event
|
Motion
detection, video tampering alarm, exception
|
|
Smart
Event
|
Face
detection, line crossing detection, intrusion detection, region entrance detection,
region exiting detection, unattended baggage detection, object removal detection,
audio exception detection
|
|
Alarm
Linkage
|
Upload
to FTP/NAS/memory card, notify surveillance center, send email, trigger recording,
and PTZ actions (such as preset)
|
|
General
|
|
Power
|
12 VDC,
Max. 9.2 W; PoE (802.3af)
|
|
Dimension
|
Ø 130.7
mm ×101.7 mm (Ø 5.15" × 4.00")
|
|
Weight
|
Approx.
530 g (1.17 lb.)
|
|
Operating
Condition
|
-20
°C to 60 °C (-4 °F to 140 °F). Humidity 90% or less (non-condensing)
|
|
General
Function
|
Mirror,
password protection
|
|
Approval
|
|
Protection
|
IP66
(IEC 60529-2013), IK10, TVS 4000V lightning protection, surge protection and voltage
transient protection
|
