Camera
|
Sensor
|
1/1.8"
progressive scan CMOS
|
Min.
Illumination
|
Color:
0.0005 Lux @ (F1.0, AGC ON); 0 Lux with white light
|
Shutter
Speed
|
1/1
to 1/30,000 s
|
Day
& Night
|
24/7
colorful imaging
|
Zoom
|
16x
digital
|
Max.
Resolution
|
2560
× 1440
|
Lens
|
Focal
Length
|
4
mm
|
FOV
|
Horizontal
field of view: 88.7° Vertical field of view: 46.5° Diagonal field of view:
105.0°
|
Aperture
|
F1.0
|
Illuminator
|
Supplement
Light Type
|
White
Light
|
Supplement
Light Range
|
White
Light Distance: up to 30 m
|
PTZ
|
Movement
Range (Pan)
|
350°
|
Movement
Range (Tilt)
|
0°
to 90°
|
Pan
Speed
|
Pan
speed: configurable from 0.1° to 60°/s; preset speed: 60°/s
|
Tilt
Speed
|
Tilt
speed: configurable from 0.1° to 50°/s, preset speed 50°/s
|
Proportional
Pan
|
Yes
|
Presets
|
300
|
Power-off
Memory
|
Yes
|
Park
Action
|
Preset,
patrol scan
|
3D
Positioning
|
Yes
|
Preset
Freezing
|
Yes
|
Scheduled
Task
|
Preset,
patrol scan, dome reboot, dome adjust, aux output
|
Video
|
Main
Stream
|
50
Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720);
60
Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
|
Sub-Stream
|
50
Hz: 25 fps (704 × 576, 640 × 480, 352 × 288);
60
Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
|
Third
Stream
|
50Hz:
25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 ×
288);
60Hz:
30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
|
Video
Compression
|
Main
stream: H.265+/H.265/H.264+/H.264
Sub-stream:
H.265/H.264/MJPEG
Third
stream: H.265/H.264/MJPEG
|
Scalable
Video Coding (SVC)
|
H.264
and H.265 encoding
|
Region
of Interest (ROI)
|
8
fixed regions for each stream
|
Audio
|
Audio
Compression
|
G.711alaw,
G.711ulaw, G.722.1, G.726, MP2L2, AAC, PCM
|
Environment
Noise Filtering
|
Yes
|
Network
|
Network
Storage
|
NAS
(NFS, SMB/ CIFS)
|
Protocols
|
IPv4/IPv6,
HTTP, HTTPS, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP,
RTP,
TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, Websocket, Websockets
|
Security
|
Authenticated
username and password, MAC address binding, HTTPS encryption, IP address
filter
|
Wireless (Wi-Fi)
|
Wi-Fi
Protocols
|
IEEE802.11b,
802.11g, 802.11n
|
Frequency
Range
|
2.4
GHz -2.4835 GHz
|
Channel
Bandwidth
|
20/40
MHz
|
Modulation
|
802.11b:
CCK, DQPSK, DBPSK
802.11g:
OFDM/64-QAM, 16-QAM, QPSK, BPSK
802.11n:
OFDM/64-QAM, 16-QAM, QPSK, BPSK
|
Encryption
Mode
|
64/128-bit
WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
|
Transfer
Rate
|
11b:
11 Mbps, 11g: 54 Mbps, 11n: up to 150 Mbps
|
Wireless
Range
|
Up
to 50 m
|
|
Day/Night
Switch
|
Day,
night, auto, scheduled-switch
|
Enhancement
|
BLC,
HLC, 3D DNR
|
Wide
Dynamic Range (WDR)
|
120
dB WDR
|
Defog
|
Digital
defog
|
Regional
Exposure
|
Yes
|
Parameters Switch
|
Yes
|
Privacy
Mask
|
Up
to 24 masks (8 masks for each scene)
|
SNR
|
>
52 dB
|
Interface
|
Built-in
Speaker
|
1
built-in speaker
|
Power
Output
|
12
VDC; < 60 mA
|
Ethernet
Interface
|
1
RJ45 10 M/100 M Ethernet interface; PoE (802.3at)
|
On-board
Storage
|
Built-in
memory card slot, support MicroSD/SDHC/SDXC, up to 512 GB
|
Alarm
|
1
input, 1 output
|
Audio
|
1
input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ±
10%; 1 output (line out), line level, output impedance: 600 Ω
|
RS-485
|
1
RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
|
Reset
|
Yes
|
Event
|
Basic
Event
|
Video
tampering alarm, motion detection, alarm input, alarm output, exception
|
Smart
Event
|
Line
crossing detection, region entrance detection, unattended baggage detection,
object removal detection, intrusion detection, region exiting detection,
audio exception detection
|
Alarm
Linkage
|
Preset,
memory card video recording, alarm output, sending email, notify surveillance
center, upload to FTP, audible warning, white light flashing
|
Deep Learning Function
|
Face
Capture
|
Detects
up to 5 faces simultaneously. Supports detecting, capturing, grading,
selecting of face in motion, and outputs the best face picture
|
Perimeter
Protection
|
Line
crossing, intrusion, region entrance, region exiting
Support
alarm triggering by specified target types (human and vehicle)
|
General
|
General
Function
|
Mirror,
password protection, watermark, IP address filter
|
Power
|
12
VDC, 3.33 A & PoE (802.3at), 42.5 to 57 VDC, 0.6 A
Max.
16 W (including max. 4 W for white light)
|
Operating
Condition
|
Humidity:
≤ 90%, temperature: -30°C to 65°C (-22°F
to 149°F)
|
Demist
|
Yes
|
Dimension
|
179.3
mm × 120 mm × 182 mm (7.06" × 4.72" × 7.71")
|
Weight
|
Approx.
1.125 kg (2.48 lb.)
|
Approval
|
Protection
|
IP66;
6000 V Lightning Protection, Surge Protection and Voltage Transient
Protection
|
